Brainboxes Ethernet to Digital I/O Relay Converter The Brainboxes Ethernet to digital I/O relay converter is a state-of-the-art device with 8 non-isolated digital input channels and 4 digital relay output channels. It offers robust and intelligent control side devices that provide the interface to systems on the 24VDC factory floor environment, commonly referred to as process side. This device can be controlled over TCP/IP using the Modbus TCP protocol or simple ASCII commands. It can be configured and secured from a web browser and can be installed as a COM port on a Windows PC to give complete backward compatibility, essential for legacy applications. Features and Benefits Easy-wire: colour coded and numbered, removable terminal blocks8 Digital inputs and 4 Form A RelaysDrives high current and high voltage loadsFactory floor process control and automationEasy wire feature with removable screw terminal blocksDIN rail mountSupports simple ASCII or industry standard Modbus TCPOperating temperature ranges between -30°C and 80°CSoftware APIs for visual basic, C# and moreNetwork enable your NuDAM/ADAM modulesEasy to use interfaceLED Status indication5VDC to 30VDC power supplyIdeal for inductive, capacitive and resistive loadOnly 22.6mm wide Applications Relays driversPumpsVoltage regulator Certifications CE

The Brainboxes Ethernet to RTD has 4 high precision RTD inputs. This device can be controlled over simple ASCII TCP protocol or ASCII over virtual COM port. Its integral DIN mount and slim design takes up minimal cabinet space. It has powerful ARM 120MHz, 32 bit CPU. The digital output port line are implemented as protected output circuits, providing current overload and short circuit protection, voltage surge, overload and open circuit protection and over temperature protection to allow the widest possible usage and range of devices. Additionally Brainboxes supply a suite of APIs and sample code to communicate with the device using Microsoft .NET framework Visual Basic, C sharp, C++, Java, JavaScript, PHP and more. IP20 ratedOperating temperature range -30°C to +80°CSupports simple ASCII 1 Ethernet portIntegral DIN rail clip with earth

Brainboxes Converter The Brainboxes converter is a USB to serial adapter which has eight RS422/485 serial port. It has data transfer rates up to 921,600 baud rates. The 128byte deep transmit and 256byte receive FIFOS are coupled with 1Mbit line to drivers deliver uncompromising performance on your laptop/PC. This adaptor provides a quick, cost-efficient way to connect your computer to a serial comms enabled device. It also includes drivers for Windows 32bit and 64bit operating systems including Windows XP, Server 2003, Vista, Server 2008, Windows 7, Windows 8 and Windows 10. It also has additional drivers for Raspberry Pi, Mac OS X and Linux. Features and Benefits Metal caseHigh retentionDrivers for all popular operating systemsWorks where many other USB to serial devices do not workUnbreakable connection Applications Remote monitoringIndustrial sitesSoftware

Brainboxes Adapter The Brainboxes adapter is an Ethernet to serial device server provides access to two RS232 serial ports. It has removable screw terminals blocks for easy wiring. This device provides simple instant networked serial ports in demanding environments. It has serial port tunnelling that allows serial cable replacement over any distance. It also has a web interface that allows a secure configuration and control of the serial ports over a local network or the internet using any browser. This adaptor can be accessed via TCP/IP sockets from any networked device like an Android tablet, PC or phone Features and Benefits Maximum baud rate is 1,000,000 (1MBaud )10/100Base TX Ethernet port User-friendly interface, Simple to use and powerful in operation Web configuration and RFC2217 compliant interface for non-Windows usersLED status indication Optional DIN rail mounting kit No software required Power supply included (power input that ranges between 5VDC and 30VDC) Simple operation for each and every operating system Applications Remote monitoringIndustrial sitesSoftware

PW-650 - Power Adapter The PW-650 power supply is for use with any 5 series device.Can use 5 Volt power from any computer USB port via this optional cable PW-650.Useful for configuring the device from a laptop in the field. Power Adapter5V USB to Screw Terminal BlockLength is 1.8 m

Converter USB to Serial RS232 Brainboxes USB to Serial converter adapters come in 1, 2, 4 and 8 ports as RS232 version. USB to RS232 converterBaud rates from 110 to 921,600Simple installationWorks where many USB to serial converters do notBrainboxes proven software drivers, enable the serial port to behave just like a real COM port attached to the PC motherboardRobust software for excellent application compatibilityBrainboxes Lifetime Warranty and SupportUS-701 - 4 Port (stock-no. 688-3337)US-279 - 8 Port (stock-no. 688-3334)

Ethernet to RS-232 + RS-422/485 Ethernet to Serial Device with 1 (ES-511) or 2 (ES-522) port software selectable as RS232, RS422/485 Full duplex or RS422 Half duplex with removable Screw Terminals Blocks for easy wiring, a slim ’end on’ case and integral DIN rail mount. Our Industrial Ethernet to Serial has an operating temperature range of -30 to +80 degrees Celsius and with +5VDC to +30VDC Dual input reverse polarity protected power supply making it perfect for industrial applications. Data transfer rates up to 1,000,000 baud, coupled with 1Mbit/s line drivers deliver uncompromising performance. Our Industrial ES range provides simple instant networked serial ports in demanding environments. Serial Port Tunnelling allows serial cable replacement over any distance, no software required. Suitable to be wired into existing power and network infrastructure or can be used with our PW-600 power supply. Configure options via web interface

Brainboxes Device Server The Brainboxes Ethernet to serial device server provides access to two RS422/485 serial port. It has data transfer rates up to 1,000,000 baud and when it is coupled with 1Mbit/s line drivers, it delivers uncompromising performance. The Power over Ethernet (PoE) uses the IEEE 802.3af standard. The ES range in this device provides simple instant networked serial ports. It also has a web interface, which allows secure configuration and control of the serial ports over a local network or the internet using any browser. This device can be accessed via TCP/IP sockets from any networked devices like an Android tablet, PC or phone. Features and Benefits User-friendly interface, simple to use and powerful in operationSerial port tunnelling allows serial cable replacement over any distance No software requiredPower supply included (power input ranges between 5VDC and 30V DC) Applications ModemsPOSPrintersIndustrial equipment

The Brainboxes PoE+ gigabit Ethernet switch is remove the need for costly electrical installations by enabling the transmission of electrical power over the same cable that carries data. Available with fast and gigabit Ethernet, plus SFP, and in a range of enclosures to perfectly fit your application, PoE switches are simple to install, fully conform to IEEE 802.3af/at Ethernet standards for reliable performance, and offer the flexibility to deploy powered devices at almost any location. Fully compliant to IEEE 802.3af/atcCompact designAllows power and data to be combined on the same Ethernet cableDIN Rail Mountable or Embedded

9 Way Quad RS-232 4 Port RS-232Fits x1, x4, x8 and x16 Express slot256 byte Tx and 256 byte Rx FIFO'sUp to 921600 baudConnectorDrivers for all popular operating systemsSample programs, Test and Terminal software

The Brainboxes PoE+ gigabit Ethernet switch is remove the need for costly electrical installations by enabling the transmission of electrical power over the same cable that carries data. Available with fast and gigabit Ethernet, plus SFP, and in a range of enclosures to perfectly fit your application, PoE switches are simple to install, fully conform to IEEE 802.3af/at Ethernet standards for reliable performance, and offer the flexibility to deploy powered devices at almost any location. Fully compliant to IEEE 802.3af/atcCompact designAllows power and data to be combined on the same Ethernet cableDIN Rail Mountable or Embedded

Brainboxes Ethernet to Analogue I/O Converter The Brainboxes Ethernet to analogue I/O converter is a state-of-the-art device with 4 non-isolated analogue outputs and an RS485 expansion. This device can be controlled over TCP/IP using the Modbus TCP protocol or simple ASCII commands. It can be configured and secured from a web browser and can be installed as a COM port on a Windows PC to give complete backward compatibility, essential for legacy applications. Additionally, Brainboxes supply a suite of APIs and sample code to communicate with the ED device using Microsoft. NET framework, C++, Java, JavaScript, PHP, and more. Features and Benefits 4 analogue outputs - selectable as either current or voltageControl instantly from any web-browser1 Ethernet portOperating temperature ranges between -30°C and 80°CUse with Modbus or ASCII commands1500VRMS magnetic isolation from Ethernet Applications Control and switching of AC and DC motorsFansRelays driversPumpsVoltage regulatorLED's and bulbsAir conditioningHeaters and solenoids Certifications CEIP20 rated
