<B>Kunbus modular gateway solutions</B> Jumper unit for PiBridge. This unit is used for connecting single Revolution Pi modules together. <B>Features and benefits</B> • Universally suited for all basic and expansion modules of Revolution Pi <B>Applications</B> • Factory automation<BR/><BR/>• IIOT (Industrial Internet of Things) applications such as line automation<BR/><BR/>• Industry 4.0 applications such as data exchange in manufacturing technologies, cloud computing etc.

<B>Revolution Pi AIO - Powered by Raspberry Pi</B> Introducing RevPi AIO, the latest in industrial computing from Kunbus. Using a Raspberry Pi Compute Module, the system is able to perform high-performance tasks and applications with ease and accuracy.<BR/><BR/>Expand your RevPi Core products with a RevPi AIO module. You can expand your system not only by 4 analogue inputs and 2 analogue outputs but also by 2 inputs for RTDs. <B>Features and benefits</B> • DIN rail mountable (to EN 50022) & compact in size making it perfect to mount several where space restrictions may apply.<BR/><BR/>• IP20 rated (effective sealing resistant to foreign bodies such as dirt/dust)<BR/><BR/>• Polycarbonate housing material prescribed to standard EN 61131-3 (resistance to vibration/shock/damp air/high&low temperatures)<BR/><BR/>• 2 RTD inputs - enabling temperatures to be measured with high precision ranging from -165°C to +600°C in steps of 0.5 °C using common sensors like PT100/1000 probes. you can plug your probes directly into the device.<BR/><BR/>• RTD inputs & outputs are galvanically isolated to each other, with differential inputs eliminating ground loops.<BR/><BR/>• Connect your AIO expansion module to your RevPi base module by means of an overhead PiBridge plug.<BR/><BR/>• Similar to the digital IO RevPi devices, the AIO is protected against any disturbance according to EN61131-2 and is also protected against static discharges, bursts and surge impulses. <B>Applications</B> • Energy sector <BR/>• Graphical programming <BR/>• Lighting sector <BR/>• Home automation <BR/>• Graphical programming Using the analog I/O - module RevPi AIO your RevPi base module can be expanded by 4 analog inputs, 2 analog outputs and 2 RTD input channels. This expansion module is connected to your base module by the means of the overhead PiBridge plug. Inputs, RTD inputs and outputs are galvanically isolated to each other. Differential inputs eliminate ground loops.

<B>Revolution Pi DI - Powered by Raspberry Pi</B> The RevPi DI, like its counterparts, the DO/DIO, features a 28 pin connector on the front side of the module (2 rows of 14 male pins) and comes with female connectors with spring clip contacts up to 1.5mm². The DI has 16 digital outputs. <B>Features and benefits</B> • Galvanic separation between the PiBridge logic circuit (uses its own power supply) protects against reverse polarity, over voltages and transient voltage or current interference adhering to the requirements of EN61131-2.<BR/>• PiBridge cyclically exchanges with the RevPi Core's central processing image using the PiControl driver. As per these exchanges occurring, any possible error conditions and configuration data is also cyclically transmitted.<BR/>• DC inputs have a voltage threshold of 24 V supply voltage which is compliant with EN61131-2 type 1 & 3 as input definitions. Your input current will be capped at a maximum of 2.4mA.<BR/>• Adjustable low-pass filtering that helps prevent input signal bouncing. The filter applies to all inputs or none. All the inputs are protected against any ESD interference, including bursts and surges compliant to EN61131-2.<BR/>• SPI data exchange monitoring is enabled on the DO. Safe states are run if no SPI traffic is detected and also if output power supply drops too low or the output circuit reached an over-temperature.<BR/>• DIN rail mountable (to EN 50022) & compact in size making it perfect to mount several where space restrictions may apply.<BR/>• Polycarbonate housing material prescribed to standard EN 61131-3 (resistance to vibration/shock/damp air/high&low temperatures) <BR/>• IP20 rated (effective sealing resistant to foreign bodies such as dirt/dust)<BR/>• Outputs not only come through digital signal but also a pulse-width modulated PWM signal <B>Applications</B> • Automotive sector <BR/>• Energy sector <BR/>• Lighting sector <BR/>• Home automation With this digital input module, the RevPi Core can be extended by 16 digital inputs, thus creating the prerequisite for a small industrial controller. The expansion module is connected to the RevPi core via the top connector. The connector is included in the scope of delivery of this expansion module.

<B>Revolution Pi DIO - Powered by Raspberry Pi</B> The RevPi DIO has 14 digital inputs and 14 digital outputs giving you greater versatility with your systems and applications. The DIO offers many solutions to industrial automation when paired up with the RevPi Core/Core3 range. As a Revolution Pi user, you will have access to a community built around solutions that can help you embed innovation in your workspace. <B>Features and benefits</B> • Galvanic separation between the PiBridge logic circuit (uses its own power supply) protects against reverse polarity, over voltages and transient voltage or current interference adhering to the requirements of EN61131-2.<BR/>• PiBridge cyclically exchanges with the RevPi Core's central processing image using the PiControl driver. As per these exchanges occurring, any possible error conditions and configuration data is also cyclically transmitted.<BR/>• DC inputs have a voltage threshold of 24 V supply voltage which is compliant with EN61131-2 type 1 & 3 as input definitions. Your input current will be capped at a maximum of 2.4mA.<BR/>• Adjustable low-pass filtering that helps prevent input signal bouncing. The filter applies to all inputs or none. All the inputs are protected against any ESD interference, including bursts and surges compliant to EN61131-2.<BR/>• SPI data exchange monitoring is enabled on the DIO. Safe states are run if no SPI traffic is detected and also if output power supply drops too low or the output circuit reached an over-temperature.<BR/>• Outputs not only come through digital signal but also a pulse-width modulated PWM signal <B>Applications</B> • Automotive sector <BR/>• Energy sector <BR/>• Lighting sector <BR/>• Home automation With this digital I/O module, the RevPi Core can be extended by 14 digital inputs and 14 digital outputs, thus creating the prerequisite for a small industrial controller. The expansion module is connected to the RevPi core via the top connector. The connector is included in the scope of delivery of this expansion module.

<B>Kunbus modular gateway solutions</B> The Kunbus Gateway enables continuous and reliable communication between different networks and systems & applications. The Gateway will convert all data that the target network can handle in the transfer. It will automatically omit any non-transferrable data, additionally adding any necessary data into the network. <B>Features and benefits</B> • Plug & Play capabilities with this Gateway via DIN rail capabilities meaning it can be detached/reattached easily.<BR/><BR/>• The protocols are inside compact modules, with housings at 22.5 x 101.4 x 115 in size. You can easily exchange the protocol modules to conveniently connect one network to another.<BR/><BR/>• KUNBUS Gateways are equipped with an integrated web server and program parts on the Gateway are updateable via an FTP server. <BR/><BR/>• KUNBUS Gateways help reduce stock costs. Due to their modular structure, you can wait with the configuration until the exact time of delivery to your customer. <BR/><BR/>• Galvanised isolation to help prevent current flow between two or more sharing units.<BR/><BR/>• Conventional gateways often have to be replaced in their entirety upon failure, however with KUNBUS if you can isolate the offending gateway, you can replace the defective module only, therefore, saving you long-term on costs and keeping your key continuous operation intact.<BR/><BR/>• Diversely combinable with the most important industrial protocols for communication networks. <B>Applications</B> • Factory automation<BR/><BR/>• IIOT (Industrial Internet of Things) applications such as line automation<BR/><BR/>• Industry 4.0 applications such as data exchange in manufacturing technologies, cloud computing etc. The RevPI Gate Serial serves to easily integrate the RevPi Core into an existing serial network. The gateway is connected to the RevPi Core base module via the upper system connector. Up to two different gateways can be connected per basic module.

<B>Kunbus modular gateway solutions</B> The Kunbus Gateway enables continuous and reliable communication between different networks and systems & applications. The Gateway will convert all data that the target network can handle in the transfer. It will automatically omit any non-transferrable data, additionally adding any necessary data into the network. <B>Features and benefits</B> • Plug & Play capabilities with this Gateway via DIN rail capabilities meaning it can be detached/reattached easily.<BR/><BR/>• The protocols are inside compact modules, with housings at 22.5 x 101.4 x 115 in size. You can easily exchange the protocol modules to conveniently connect one network to another.<BR/><BR/>• KUNBUS Gateways are equipped with an integrated web server and program parts on the Gateway are updateable via an FTP server. <BR/><BR/>• KUNBUS Gateways help reduce stock costs. Due to their modular structure, you can wait with the configuration until the exact time of delivery to your customer. <BR/><BR/>• Galvanised isolation to help prevent current flow between two or more sharing units.<BR/><BR/>• Conventional gateways often have to be replaced in their entirety upon failure, however with KUNBUS if you can isolate the offending gateway, you can replace the defective module only, therefore, saving you long-term on costs and keeping your key continuous operation intact.<BR/><BR/>• Diversely combinable with the most important industrial protocols for communication networks. <B>Applications</B> • Factory automation<BR/><BR/>• IIOT (Industrial Internet of Things) applications such as line automation<BR/><BR/>• Industry 4.0 applications such as data exchange in manufacturing technologies, cloud computing etc. The RevPI Gate EtherCAT serves to easily integrate the RevPi core into an existing EtherCAT network. The EtherCAT Gateway is connected to the RevPi Core base module via the upper system connector. Up to two different gateways can be connected per basic module.

<B>Kunbus modular gateway solutions</B> The Kunbus Gateway enables continuous and reliable communication between different networks and systems & applications. The Gateway will convert all data that the target network can handle in the transfer. It will automatically omit any non-transferrable data, additionally adding any necessary data into the network. <B>Features and benefits</B> • Plug & Play capabilities with this Gateway via DIN rail capabilities meaning it can be detached/reattached easily.<BR/><BR/>• The protocols are inside compact modules, with housings at 22.5 x 101.4 x 115 in size. You can easily exchange the protocol modules to conveniently connect one network to another.<BR/><BR/>• KUNBUS Gateways are equipped with an integrated web server and program parts on the Gateway are updateable via an FTP server. <BR/><BR/>• KUNBUS Gateways help reduce stock costs. Due to their modular structure, you can wait with the configuration until the exact time of delivery to your customer. <BR/><BR/>• Galvanised isolation to help prevent current flow between two or more sharing units.<BR/><BR/>• Conventional gateways often have to be replaced in their entirety upon failure, however with KUNBUS if you can isolate the offending gateway, you can replace the defective module only, therefore, saving you long-term on costs and keeping your key continuous operation intact.<BR/><BR/>• Diversely combinable with the most important industrial protocols for communication networks. <B>Applications</B> • Factory automation<BR/><BR/>• IIOT (Industrial Internet of Things) applications such as line automation<BR/><BR/>• Industry 4.0 applications such as data exchange in manufacturing technologies, cloud computing etc. The RevPI Gate PROFINET IRT is used to integrate the RevPi core into an existing PROFINET network without any problems. The PROFINET Gateway is connected to the RevPi Core base module via the upper system connector. Up to two different gateways can be connected per basic module.

<B>Kunbus RevPI Gate Ethernet/IP Modular Gateway</B> The Kunbus Gateway enables continuous and reliable communication between different networks and systems & applications. The Gateway will convert all data that the target network can handle in the transfer. It will automatically omit any non-transferrable data, additionally adding any necessary data into the network. <B>Features and benefits</B> • Plug & Play capabilities with this Gateway via DIN rail capabilities meaning it can be detached/reattached easily.<BR/><BR/>• The protocols are inside compact modules, with housings at 22.5 x 101.4 x 115 in size. You can easily exchange the protocol modules to conveniently connect one network to another.<BR/><BR/>• KUNBUS Gateways are equipped with an integrated web server and program parts on the Gateway are updateable via an FTP server. <BR/><BR/>• KUNBUS Gateways help reduce stock costs. Due to their modular structure, you can wait with the configuration until the exact time of delivery to your customer. <BR/><BR/>• Galvanised isolation to help prevent current flow between two or more sharing units.<BR/><BR/>• Conventional gateways often have to be replaced in their entirety upon failure, however with KUNBUS if you can isolate the offending gateway, you can replace the defective module only, therefore, saving you long-term on costs and keeping your key continuous operation intact.<BR/><BR/>• Diversely combinable with the most important industrial protocols for communication networks. <B>Applications</B> • Factory automation<BR/><BR/>• IIOT (Industrial Internet of Things) applications such as line automation<BR/><BR/>• Industry 4.0 applications such as data exchange in manufacturing technologies, cloud computing etc. The RevPI Gate Ethernet/IP is used to easily integrate the RevPi core into an existing Ethernet/IP network. The Ethernet/IP gateway is connected to the RevPi Core base module via the top system connector. Up to two different gateways can be connected per basic module.

<B>Kunbus modular gateway solutions</B> The Kunbus Gateway enables continuous and reliable communication between different networks and systems & applications. The Gateway will convert all data that the target network can handle in the transfer. It will automatically omit any non-transferrable data, additionally adding any necessary data into the network. <B>Features and benefits</B> • Plug & Play capabilities with this Gateway via DIN rail capabilities meaning it can be detached/reattached easily.<BR/><BR/>• The protocols are inside compact modules, with housings at 22.5 x 101.4 x 115 in size. You can easily exchange the protocol modules to conveniently connect one network to another.<BR/><BR/>• KUNBUS Gateways are equipped with an integrated web server and program parts on the Gateway are updateable via an FTP server. <BR/><BR/>• KUNBUS Gateways help reduce stock costs. Due to their modular structure, you can wait with the configuration until the exact time of delivery to your customer. <BR/><BR/>• Galvanised isolation to help prevent current flow between two or more sharing units.<BR/><BR/>• Conventional gateways often have to be replaced in their entirety upon failure, however with KUNBUS if you can isolate the offending gateway, you can replace the defective module only, therefore, saving you long-term on costs and keeping your key continuous operation intact.<BR/><BR/>• Diversely combinable with the most important industrial protocols for communication networks. <B>Applications</B> • Factory automation<BR/><BR/>• IIOT (Industrial Internet of Things) applications such as line automation<BR/><BR/>• Industry 4.0 applications such as data exchange in manufacturing technologies, cloud computing etc. The RevPI Gate PROFIBUS serves to easily integrate the RevPi core into an existing PROFIBUS network. The PROFIBUS Gateway is connected to the RevPi Core base module via the top system connector. Up to two different gateways can be connected per basic module.

The Kunbus Revolution Pi Connect SE 32 GB version has a quad-core Arm Cortex-A72 processor with clock rate of 1.5 GHz. It has 1 GB LPDDR4 RAM. Maximum power consumption is 20 W. Number of digital input channel is 1. Protection class IP20<BR/>Operating temperature -25 °C to +55 °C

The Kunbus Revolution Pi Connect SE 8 GB version has a quad-core Arm Cortex-A72 processor with clock rate of 1.5 GHz. It has 1 GB LPDDR4 RAM. Maximum power consumption is 20 W. Number of digital input channel is 1. Protection class IP20<BR/>Operating temperature -25 °C to +55 °C

The Kunbus Revolution Pi Core SE 16 GB version has a quad-core Arm Cortex-A72 processor with clock rate of 1.5 GHz. It has 1 GB LPDDR4 RAM. It has 1 x 4-pole screw-type terminal connector for power supply. Maximum power consumption is 10 W. Protection class IP20<BR/>Operating temperature -25 °C to +55 °C
