Schneider Electric GV2RT16 TeSys GV motor circuit breaker, 3 poles (3P), 14A/690V, for high starting current peak motor applications 5.5kW@400V. It provides a thermal-magnetic protection with a thermal setting range 9-14A, a magnetic tripping level at 20xIn, high breaking capacity Icu 15kA@400V. Connection by screw clamp terminals. Start-stop control by toggle guaranteed for 100 000 cycles AC-3. It can be used for protection of 3-phase transformer applications. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). Features & Benefits • Screw clamp terminals for secure wiring• Wide operating temperature range between -20°C and +60°C for use in challenging conditions• Compact dimensions of 89 (H) x 45 (W) x 78.5mm (D) for installation in tight spaces Applications • Power plants• Industrial turbines• Compressors• Generators How long will this circuit breaker last? This circuit breaker has a robust mechanical service life of 100,000 cycles, so can be sure of long-lasting performance. Is this unit safe to handle? An IP20 rating indicates this unit is touch-proof and protected against objects larger than 12mm, so it's safe to handle.
