Convex and concave terminals
2, 4 or 8 isolated elements available
Resistance tolerance ±1 % and ±5 %
Resistance range: 10 ohms to 1 megohm

Bourns , CAT16 4.7kΩ ±5% Isolated Resistor Array, 4 Resistors, 0.25W total, 1206 (3216M), Concave

Manufacturer:
Manufacturer Part No:
CAT16-472J4LF
Enrgtech Part No:
ET15947165
Warranty:
Manufacturer
Checking for live stock
Resistance:
4.7kΩ
Resistor Type:
Array
Number of Resistors:
4
Package/Case:
1206 (3216M)
Power Rating:
0.25W
Termination Style:
Concave
Tolerance:
±5%
Case Style:
Moulded
Power Rating per Resistor:
0.062W
Circuit Designator:
ISOL
Length:
3.2mm
Depth:
1.55mm
Height:
0.6mm
Dimensions:
3.2 x 1.55 x 0.6mm
Series:
CAT16
Number of Terminals:
8
Minimum Operating Temperature:
-55°C
Maximum Operating Temperature:
+125°C
Temperature Coefficient:
±200ppm/°C
pdf icon
Datasheet CAT16-472J4LF-7eeb150d(datasheets)
Explore resistor arrays for compact circuit solutions. Enrgtech offers network resistors and SMD components ideal for balanced, space-saving electronic designs.
