Display Drivers, Linear Technology

RS-232 Line Drivers and Receivers, Linear Technology Linear Technology RS232 Transceiver and Line driver/receivers provide a range of single ended configurations. The data transmission RS232 is also known as TIA-232 supplies serial interface data rates up to 10 Mbps. The RS232 standard states the electrical characteristics and connector for point-to-point modem interface. Data terminal equipment (DTE), data communications equipment (DCE) configuration for the 3.3V / 5V supply voltage

Zero-Drift Amplifiers, Analog Devices The zero-drift amplifiers continuously self-correct for dc errors over time and temperature. Auto-zero and a chopper are combined to enable the amplifier to achieve microvolt-offsets and nanovolts per degree Celsius drift.

ADE7880, Polyphase Multifunction Energy Metering IC, Analog Devices The ADE7880 from Analog Devices is a high accuracy, 3-phase electrical energy measurement IC with serial interfaces and three flexible pulse outputs. The device incorporates second-order sigma-delta (Σ-Δ) analogue-to-digital converters (ADCs), a digital integrator and reference circuitry. In addition this device has the signal processing required to perform energy measurement and rms calculations. A fixed function digital signal processor (DSP) executes this processing, with the DSP program being stored in the internal ROM memory. Features Highly accurate – supports IEC 62053-21, IEC 62053-22, IEC 62053-23, EN 50470-1, EN 50470-3, ANSI C12.20, and IEEE1459 standardsSupports IEC 61000-4-7 Class I and Class II accuracy specificationCompatible with 3-phase, 3 or 4-wire (delta or wye) and other 3-phase servicesSupplies rms, active, reactive and apparent powers, power factor, THD, and harmonic distortion of all harmonics within 2.8 kHz pass band on all phasesSupplies rms and harmonic distortions of all harmonics within 2.8 kHz pass band on neutral currentBattery supply input for missing neutral operationReference: 1.2 V (drift 10 ppm/°C typical) with external overdrive capabilityLess than 1% error in harmonic current and voltage rms, harmonic active and reactive powers over a dynamic range of 2000 to 1 at TA = 25°CLess than 0.1% error in active and fundamental reactive energy over a dynamic range of 1000 to 1 at TA = 25°CLess than 0.2% error in active and fundamental reactive energy over a dynamic range of 5000 to 1 at TA = 25°CLess than 0.1% error in voltage and current rms over a dynamic range of 1000 to 1 at TA = 25°C Typical applications Energy metering systemsPower quality monitoringSolar InvertersProcess monitoringProtective devices

The Analog Devices AD712 is a high speed, precision monolithic operational amplifier offering high performance at very modest prices. Its very low offset voltage and offset voltage drift are the results of advanced laser wafer trimming technology. These performance benefits allow the user to easily upgrade existing designs that use older precision BiFETs and, in many cases, bipolar op amps. The superior ac and dc performance of this op amp makes it suitable for active filter applications. With a slew rate of 16 V/μs and a settling time of 1 μs to ±0.01%, the AD712 is ideal as a buffer for 12-bit D/A and A/D Converters and as a high-speed integrator. Enhanced replacement for LF412 and TL082AC performance

High Speed Operational Amplifiers, Analog Devices

Inverting Switching Regulators, Linear Technology Linear Technology's offer a selection of inverting switching regulators, these regulators are designed to invert input voltages to negative outputs. Offering input voltages up to 60V and switch currents up to 10A with adjustable or fixed outputs. They may also incorporate integrated schottky diodes, fixed frequency operation, programmable current limit and low noise operation characteristics.

Inverting Switching Regulators, Linear Technology Linear Technology's offer a selection of inverting switching regulators, these regulators are designed to invert input voltages to negative outputs. Offering input voltages up to 60V and switch currents up to 10A with adjustable or fixed outputs. They may also incorporate integrated schottky diodes, fixed frequency operation, programmable current limit and low noise operation characteristics.

The Analog Devices SSM2167 is a complete and flexible solution for conditioning microphone inputs in personal electronics and computer audio systems. It is also excellent for improving vocal clarity in com-munications and public address systems. A low noise voltage controlled amplifier (VCA) provides a gain that is dynamically adjusted by a control loop to maintain a set compression characteristic. The compression ratio is set by a single resistor and can be varied from 1:1 to over 10:1 relative to the fixed rotation point. Signals above the rotation point are limited to prevent overload and to eliminate popping. A downward expander (noise gate) prevents amplification of background noise or hum. This results in optimized signal levels prior to digitization, thereby eliminating the need for additional gain or attenuation in the digital domain. Adjustable noise gate thresholdAdjustable compression ratioAutomatic limiting feature prevents ADC overload

Buck-Boost Regulators, Internal Power Switch

LDO (Low Dropout) Linear Voltage Regulators, Adjustable Output, Analog Devices The Analog Devices Low Dropout (LDO) Linear Regulators offer fast transient response, excellent line and load regulation, and they have a wide input voltage range.

Voltage Reference, Up to 2.048V, Analog Devices
