S-Force High Performance Compact Fans The 6300TD series provides a compact solution allied with high performance. Permits closed-loop speed control and monitoring which are becoming increasingly important in applications. This fan series is particularly suitable for the cooling of high-performance electronic components, such as those in servers, TCA systems, telecommunication devices, inverter drives and many other industrial applications. • Performance from 600m³/h to a maximum of 930m³/h, depending on model• PWM control input• Open-collector tachometer signal output as standard• Compatible with DCP and TMS controllers• S-Force family

The high-quality fan designed for engineers looking for reliability and efficiency. With features like sleeve bearing system, electronic function, and locked rotor protection, this fan is ideal for a variety of applications. Whether it's for cooling systems or ventilation, this fan is the perfect choice for user's engineering needs. Sleeve bearing system for enhanced durabilityElectronic function for added efficiencyLocked rotor protection ensures safe operationWide voltage range of 18.0V to 28.0V for versatile applicationsLow power consumption of 0.72W to 1.7W for energy efficiencyCompact design with dimensions of 80.0mm x 80.0mm x 25.4mm for easy installation

ebm-papst AC Ball Bearing Axial Fans Brought to you by ebm-papst, this wide range of AC ball bearing axial fans enforces excellent cooling purposes. With their square and round design and protection against motor overloading, the benefits of each axial fan will propel them ahead of their competition for proficient cooling purposes. All models are highly reliable and excellent quality. Features and Benefits • Motor overload protection• Both 230 V ac and 115 V ac versions available• Compact and robust fan design• Long life tendencies with constant pressure due to ball bearing internals• Fan operates at various speeds at both 50 Hz and 60 Hz• High quality fibre glass impeller blades for consistent airflow What is an Axial Fan? An axial fan is a type of fan commonly used within everyday applications, such as air conditioners and computers. It causes both air and gas (depending on the application) to flow directly through it in an axial direction at different speeds. Allowing the air flow to be axial and both entry and exit. The most common versions tend to have fewer impeller blades than conventional duct fans or centrifugal fans which have similar operations. Does this fan use ball bearings or sleeve bearings? This range of axial fans uses ball bearings. Although both are suitable for virtually the same applications. Ball bearings are generally the more preferred choice, due to their high reliability and long lasting tendencies. Another aspect includes their ability to operate at a higher temperature, which would be essential in harsher environments. What kind of safety features are available with this fan? A great safety aspect would be included with the motor. It provides overload protection, removing the risk of electrical surges or damage from excess energy pressure to the axial fan motor itself. This provides peace of mind that once the axial fan is mounted and operational, its ventilation or cooling process will continue to run with virtually no risk. Approvals UL, CSA, VDE

ebm-papst High Performance Reduced Noise DC Fans - 4300N Series The ebm-papst high-performance fan offers reduced operating noise thanks to a new aero-acoustic design. Fan operation is made easier with PWM and tachometer output model options. Manufacturer part number suffix: 'U' denotes IP68 protected, "R" denotes humidity protected. Features and Benefits • Superior efficiency • Lower noise levels • Reduced power consumption• Similar air flow running at a lower speed

ebm-papst 600 Series Sleeve Bearing DC Axial Fans From ebm-papst, the 600 Series of DC axial fans are designed to deliver high performance while retaining a space saving size. This range of axial fans have sleeve bearings, which offer cost effective protection of the central shaft from environmental factors. This results in a simplified and economic design that is suitable for many thermal management applications. With efficient brushless drives, and integrated communication electronics that prevent against reverse polarity, this series of fans are both reliable and easy to use. Features and Benefits • Low profile• Low power consumption• Air exhaust over struts• Protected against reverse polarity and locking.• Integrated electronic communication• Fibreglass reinforced plastic construction Applications These compact fans are ideal for installation in ACTA (Advanced Telecommunications Computing Architecture), which means they are suitable for a variety of applications.• Cabinet Cooling• Switch Networks• Power Systems• Telecom• Medical FAQ Q: What are the advantages of Sleeve Bearings fans over Ball Bearing fans?A: While ball bearing fans can typically run for longer and in more harsh conditions than sleeve bearing, sleeve bearing have the advantage of having a simplified, often more cost effective design. Because of their simplified design, sleeve bearings are more impact resistance.Q: Are these fans easy to use?A: With simple screw installation, and with their necessary communication electronics integrated into the design, these DC axial fans are easy to install and operate.Q: What are the advantages of this fan over competitors?A: The compact and thin design of these fans makes them useful for low profile applications. Where space-saving is a concern, this model of fan is ideal. Q: Are there accessories available for this fan?A: There is a finger guard (826-1345) and filter (826-1231) available for this series of fans.

ebm-papst Centrifugal Fan The ebm-papst centrifugal fan has an airflow of 209m³/h and a supply voltage rating of 24VDC. It is designed for operation in the harshest of environments. These fans are constructed for high dust, high humidity and direct water exposure in indoors and outdoors. They are ideal for wash-down situations and cannot be damaged by continuous immersion in water making them suitable for a broad range of applications. It is 220mm long, 220mm wide and 56mm deep. With a construction based on the entire motor (winding and PCB) being completely coated in plastic, the integrated operating electronics of ebm-papst fans are completely encased and the cable connection is specially sealed. Note:To prevent overloading the motor, these blowers must be operated against the minimum static pressures. Features and Benefits DC fans with electronic rotor switching and integrated electronic switching regulationMaintenance free Fibreglass-reinforced plastic, PBTP housing and PA vaneProtected against polarity reversal and overloadElectric connection with two 22AWG rated wires Applications Industrial useCentral air conditioning units or building ventilation systemsAutomobile Certifications CE certifiedIP68 rated

ebm-papst High Performance Ball Bearing Fans ebm-papst high performance ball bearing fans are an ideal soultion to a wide range of applications, featuring fibreglass-reinforced plastic and completely integrated electronic commutation. • Material: fibreglass-reinforced plastic• Fully integrated electronic commutation• Protected against reverse polarity and locking• Connected via single strands AWG 24, TR 64. Bared and tin-plated.

ebm-papst AC Sleeve Bearing Axial Fans From ebm-papst, this wide range of AC sleeve bearing axial fans enforces excellent cooling purposes. With their robust design and protection against motor overloading, the benefits of each axial fan will propel them ahead of their competition for proficient cooling purposes. All models are highly reliable and excellent quality. Features and Benefits • Motor overload protection• Both 230 V ac and 115 V ac versions available• Compact and robust fan design• Fan operates at various speeds at both 50 Hz and 60 Hz• High quality fibre glass impeller blades for consistent airflow What is an Axial Fan? An axial fan is a type of fan commonly used within everyday applications, such as air conditioners and computers. It causes both air and gas (depending on the application) to flow directly through it in an axial direction at different speeds. Allowing the air flow to be axial and both entry and exit. The most common versions tend to have fewer impeller blades than conventional duct fans or centrifugal fans which have similar operations. What kind of safety features are available with this fan? A great safety aspect would be included with the motor. It provides overload protection, removing the risk of electrical surges or damage from excess energy pressure to the axial fan motor itself. This provides peace of mind that once the axial fan is mounted and operational, its ventilation or cooling process will continue to run with virtually no risk. Does this fan use sleeve bearings or ball bearings? This range of axial fans uses sleeve bearings. Although both are suitable for virtually the same applications. Sleeve bearings have the advantage of both their low cost and low energy ratings. Ensuring a cost effective way of both cooling and ventilating applications.

ebm-papst Compact DC Fan Assemblies with Inserts and Connectors ebm-papst compact DC fans are suitable for high air performance with moderate pressure build-up and feature threaded inserts in each corner to take an M3 threaded bolt and a Molex 22-01-2025 connector. Ideal for PC cooling and various other applications. • DC fans• Plastic housing• Molex connector fitted• Threaded inserts for easy mounting• Connection via lead 313mm (+/- 10mm)• Threaded brass inserts fitted on both sides• Blowing over struts• Protection IP20

ebm-papst AC Ball Bearing Axial Fans Brought to you by ebm-papst, this wide range of ball bearing axial fans enforces excellent cooling purposes. With their round design and impedance protection against overloading, the benefits of each axial fan propels them ahead of their competition for proficient cooling purposes. All models are highly reliable and excellent quality. Features and Benefits • Diecast aluminium housing (black)• Sheet steel blades• Motor stall protection• Can be operated at both 50 Hz and 60 Hz• Excellent blade performance at high pressure• Automatic reset feature What is motor stalling in a fan? Motor stalling can occur when the operating motor inside an axial fan has more load than designed. This can cause the axial fan to fail or in more extreme circumstances damage the internals. This series of axial fans fully protects against this outcome with its temperature sensor, which incorporates an automatic reset maintaining the original speed after a failure. What are Axial Fans? An axial fan is a type of fan commonly used within everyday applications, such as air conditioners, computers and laptops. It causes both air and gas (depending on the application) to flow directly through it in an axial direction. Allowing the air/gas flow to be axial and both entry and exit. The most common versions tend to have fewer impellers than a conventional ducting fan which have similar operations. Does this fan use ball bearings or sleeve bearings? This particular series of axial fans uses ball bearings. Although both are suitable for virtually the same applications. Ball bearings generally are the more preferred choice, due to their high reliability and long lasting tendencies. Another benefit is their ability to be mounted in any axial direction, whether that be vertical or horizontal.

The ebm-papst DC axial fan is a direct-current drive operated general fan motor with developed geometry and provides smooth rotation using three phase motor concept which generates less extra heat in the rotor and stator. Air flow direction exhaust over strutsRotational direction counter clockwise, looking towards rotorMaterial housing plastic (PBT)Material impeller plastic (PA)PWM control input

ebm-papst EC Centrifugal Fan The ebm-papst centrifugal fan has an airflow of 1290m³/h (for 50Hz) at a fan speed of 3230rpm and has a supply voltage rating of 230VAC. It is an electronically commutated motor fan with an external rotor motor. This double inlet centrifugal fan is integrated within the impeller that reduces installation dimensions. The fan is featured with backwards-curved blades. It is an ideal solution for a wide range of applications and also suitable for intake suction use. The scroll housing is open on both the sides for added efficiency and reduction in noise level. The robust and space-saving design of this ebm-papst centrifugal fan makes it versatile and easy to use. The fan is 220mm wide and 92mm deep. Features and Benefits Low-pressure centrifugal solutionsFitted with highly efficient GreenTech EC motorAerodynamic shape reduces noise emissionsHybrid construction makes impellers highly corrosion-resistantEC control options available Applications Control cabinet coolingIn-line duct fansHome ventilation unitsHeat pumps Certifications IP54 rated
