The TDK-Lambda is a wall mount power supplies are certified to IEC/ES/EN60601-1 and EN60601-1-11, are compliant to EN60601-1-2 and designed to meet IEC60335-1. Requiring no earth ground, the WMM30 series is ideally suited for Medical, Clinical and Home Healthcare applications. Four interchangeable AC plugs are available for use in North America, Europe, UK and Australia. Alternative output connectors and cable assemblies are available on request. Medical Safety Certifications and ImmunityClass II InputMeets DoE Level VI and EU Tier 2 Efficiency and 4kV Input to Output IsolationAlternative Connectors and Cable AssembliesFlexible System Integration

15W to 1500W Single Output Industrial Power Supplies HWS-A Series The TDK-Lambda HWS-A series of AC-DC power supplies, comprises five models rated from 15-150W. A significant upgrade of the established HWS series, which is still compatible with the new HWS-A series to enable easy upgrade. This switch mode power supply is up to 12% lighter compare to the previous series and features up to 91% efficiency and a very low power consumption at no load, contributing to a reduction in environmental impact. The HWS-A power supplies operate from a universal input of 85-265Vac, The 50, 100 and 150W models include active power factor correction, the operating temperature of the HWS-A models range from -10 to +50°C at full load and up to 70°C with appropriate derating. Typical industrial applications of these switch mode power supplies include equipment used for factory automation, process control, LED display and signage, test and measurement, broadcast and communications. High efficiency up to 91%Wide range AC inputLow costEasy system coolingSupports global useLimited Life time warranty

The TDK-Lambda is a 13.2 to 30W DC-DC Converter. The 1 inch x 1 inch footprint CCG15 and CCG30 series of isolated DC-DC converters operate from wide range 9 to 36Vdc or 18 to 76V inputs with 15W and 30W power levels and output voltages from 3.3V to 30V. Single output models can be adjusted -10% to +10% by using the trim terminal. The CCG can operate in ambient temperatures of -40 to 85°C and has an input to output isolation of 1,500Vdc. Six sided shielding reduces radiated and conducted EMI. Wide 4:1 Input RangesSpace Saving Package SizesReduced Derating at High Ambient TemperaturesLess Board Area NeededEasier System ComplianceMore Useable Power

The TDK-Lambda is a 60W Single and Dual Output DC-DC converters. The PXD60 industrial DC-DC converters feature wide 4:1 input ranges in a compact 2 x 1 inch industry standard package. With efficiencies upto 92%, the PXD60 series typically draws a low 3mA input current when the remote on or off function is used, prolonging battery life for portable equipment. The modules have six-sided shielding to reduce radiated noise. Less Board Area NeededSuitable For Industrial ApplicationsLonger Battery LifeReduces Radiated Noise

The TDK-Lambda is a 1.3 to 10.8W DC-DC Converter. The space saving CCG1R5 to CCG10 series of isolated DC-DC converters operate from wide range 4.5 to 18V, 9 to 36Vdc or 18 to 76V inputs with 1.3W to 10.8W power levels and output voltages from 3.3V to 30V (1). Single output models can be adjusted -5% to +10% by using the trim terminal. The CCG can operate in ambient temperatures of up to -40 to +100°C (model dependent) and have an input to output isolation of 1,500Vdc. Both through hole and surface mount packages are offered. Wide 4:1 Input RangesSpace Saving Package SizesReduced Derating at High Ambient TemperaturesNo Silicone PottingLess Board Area NeededEasier System ComplianceMore Useable PowerReduced Quality Risk During Surface Mount Reflow Process

TDK-Lambda Switch Mode Power Supply The TDK-Lambda HWS series 624W rated switch mode power supply with a single output has an output current rating of 13A at 48VDC. It has a universal input supply voltage rating from 85VAC to 265VAC and 120VDC to 330VDC.Note:Peak load current for 10 seconds (maximum) ON time, 35% duty cycle. The de-rate output above 50°C. The depth excludes terminal block/connectors. Features and Benefits Adjustable output voltage (±20%)Built-in fan on 300W to1500W typesConforms to SEMI F47 requirements for semiconductor manufacturing equipmentDesigned for high reliability and long product lifecycleEasy installationExceptionally compact, requires typically 50% less space than previous generation productsLED indicator for power ONOvervoltage and over current protectionScrew terminals Certifications CSA 60950-1EN 50178EN 55022-BEN 60950-1EN 61000-3-2 (power factor correction)FCC class BUL 60950-1UL508

The TDK-Lambda PCB Mount Power Supplies offers medical grade AC-DC power supplies. These power supplies are characterized by their small size and lightweight construction. They are Class II compliant, meaning no ground connection is needed. With medical safety certifications, it ensures safe and reliable performance in medical applications. Dual OutputVoltages are 12V and -12VCurrents are 5A and 1.25AMaximum Power Output is 40WEfficiency is 80 percent

50W to 600W Single Output Industrial Power Supplies RWS Series The TDK-Lambda RWS-B series of AC-DC power supplies comprises four models rated from 50 to 600 watts, featuring simple function design, compact dimensions, and high efficiency. The RWS-B series of switch mode power supplies is positioned as a mid-range product with simple functionality. The RWS-B series come in a simplified, compact, highly efficient power supply package. Improved efficiency at low loads and power consumption during stand-by contribute to reduce the environmental impact. The RWS-B power supplies offer outstanding thermal performance for cooler operation over their operating temperature range of -10 to +70°C; the RWS100B and RWS150B models are convection cooled, whereas the higher power models incorporate an internal cooling fan. These enclosed AC-DC power supplies operate from a universal input of 85-265Vac to meet a wide range of applications, including industrial, test & measurements, broadcast, communication and LED signage. Low ProfileHigh efficiencyUniversal Input rangeScrew terminal connectionLevel B EMI

The TDK-Lambda is a 15 to 20W Medical and Industrial DC-DC Converters. The PXG-M series of medical and industrial DC-DC converters feature a wide 4:1 input range in a compact 1.6 x 1 inch industry standard package. With 5kV input to output isolation, 2.5uA touch current and a low off-load power draw, these encapsulated modules are ideal for fixed and portable applications. Less Board Area NeededSuitable For Medical and Industrial ApplicationsHigh Input to Output IsolationLonger Battery Life

TDK-Lambda, PCB Mount, Encapsulated, Switch Mode AC-DC Power Supply - KW Series TDk Lambda KW series of encapsulated PCB power supplies off a compact solution to a wide range of applications. The compact footprint of the KW series makes it suitable for space-critical applications without external components. The series is highly efficient with reduced power losses, making board thermal management easier. Features and BenefitsSmall, lightweight & universal input.Input 85-265Vac, ideal for small systems and instrumentation applications worldwide.Overvoltage/Overcurrent protection.Plastic case complies to UL94V-0.Conducted noise (EMI) VCCI-II and FCC-B (will meet VDE-B with external capacitor).Typical ApplicationsIndustrial.Test & measurement.Communications & Broadcast.

The TDK-Lambda is a wall mount power supplies are certified to IEC/ES/EN60601-1 and EN60601-1-11, are compliant to EN60601-1-2 and designed to meet IEC60335-1. Requiring no earth ground, the WMM30 series is ideally suited for Medical, Clinical and Home Healthcare applications. Four interchangeable AC plugs are available for use in North America, Europe, UK and Australia. Alternative output connectors and cable assemblies are available on request. Medical Safety Certifications and ImmunityClass II InputMeets DoE Level VI and EU Tier 2 Efficiency and 4kV Input to Output IsolationAlternative Connectors and Cable AssembliesFlexible System Integration

The DTM medical external power supplies are housed in a rugged plastic case and are rated from 40 to 300W with output voltages from 5V to 54V. Off-load power draws as low as ApplicationsGeneral Purpose IndustrialMedical / ScientificTest & MeasurementBroadcastCommunicationsHome MedicalEasier system complianceGlobal OperationConsumes less energy
