<B>Schneider Electric Acti9 iC60H MCB Range</B> Introducing Schneider Electrics iC60H series of multi-standard circuit breakers which combine circuit protection against short circuit currents and circuit protection against overload currents alongside protecting users against indirect contact with TN and IT neutral systems. <B>Benefits & Features</B> Fully compliant with standards IEC/EN 60898 and IEC/EN 60947-2. ACTi 9 is fully tested, approved and certified by national and international third parties. It guarantees that the user's installation is safe and compliant with all relevant safety standards. These MCBs are normally used for high inductive loads where switching surges are high. Providing essential protection in industrial and commercial buildings, these miniature circuit breakers work especially well in polluted environments and networks. VisiSafe guarantees the downstream circuit is always safe regardless of overvoltage conditions, even in the most demanding environments; the green strip indicates the safe position of contacts. VisiTrip red window on the front face indicates fault tripping allowing fast diagnosis, resolution, and reclosing loads for easier building management and reduced downtime. &#149; Downstream circuit is always safe<BR/>&#149; Class-2 insulation: ensures continuous protection for both operators and unqualified persons.<BR/>&#149; Insulated terminals (IP20)<BR/>&#149; Highly durable with robust connections that provide twice the standard tightening torque<BR/>&#149; Provide greater continuity of service thanks to VisiTrip<BR/>&#149; Double clip for dismounting with comb busbar in place <B>What does a miniature circuit breaker do?</B> It protects wires from overloads and short-circuits. For overload protection the temperature of a bimetal, through which the current passes is decisive. If the nominal current—the current the circuit breaker is designed for—rises slightly, the bimetal heats up to a greater extent and, after a certain period of time, this causes the switching mechanism to trip. Today MCBs are installed in all our homes, offices and other buildings, protecting the electrical wires from damage. They have the advantage that they can be manually reset without having to replace wire as in the case of the traditional fuse. The MCBs have either a button or lever that can be flicked to reset it. They are used instead of fuses due to their convenience and improved safety features. <B>What are the differences in the Tripping Curves B, C, and D?</B> Curve B: Tripping: 3 to 5 times the rated current.<BR/>Applications: protection of generators, persons, very long cables<BR/>Curve C: Tripping: 5 to 10 times the rated current<BR/>Applications: protection of circuits and general applications<BR/>Curve D: Tripping: 10 to 14 times the rated current<BR/>Applications: protection of high surge circuits, welders, transformers and motors

<B>Schneider Electric Acti9 iC60H MCB Range</B> Introducing Schneider Electrics iC60H series of multi-standard circuit breakers which combine circuit protection against short circuit currents and circuit protection against overload currents alongside protecting users against indirect contact with TN and IT neutral systems. <B>Benefits & Features</B> Fully compliant with standards IEC/EN 60898 and IEC/EN 60947-2. ACTi 9 is fully tested, approved and certified by national and international third parties. It guarantees that the user's installation is safe and compliant with all relevant safety standards. These MCBs are normally used for high inductive loads where switching surges are high. Providing essential protection in industrial and commercial buildings, these miniature circuit breakers work especially well in polluted environments and networks. VisiSafe guarantees the downstream circuit is always safe regardless of overvoltage conditions, even in the most demanding environments; the green strip indicates the safe position of contacts. VisiTrip red window on the front face indicates fault tripping allowing fast diagnosis, resolution, and reclosing loads for easier building management and reduced downtime. &#149; Downstream circuit is always safe<BR/>&#149; Class-2 insulation: ensures continuous protection for both operators and unqualified persons.<BR/>&#149; Insulated terminals (IP20)<BR/>&#149; Highly durable with robust connections that provide twice the standard tightening torque<BR/>&#149; Provide greater continuity of service thanks to VisiTrip<BR/>&#149; Double clip for dismounting with comb busbar in place <B>What does a miniature circuit breaker do?</B> It protects wires from overloads and short-circuits. For overload protection the temperature of a bimetal, through which the current passes is decisive. If the nominal current—the current the circuit breaker is designed for—rises slightly, the bimetal heats up to a greater extent and, after a certain period of time, this causes the switching mechanism to trip. Today MCBs are installed in all our homes, offices and other buildings, protecting the electrical wires from damage. They have the advantage that they can be manually reset without having to replace wire as in the case of the traditional fuse. The MCBs have either a button or lever that can be flicked to reset it. They are used instead of fuses due to their convenience and improved safety features. <B>What are the differences in the Tripping Curves B, C, and D?</B> Curve B: Tripping: 3 to 5 times the rated current.<BR/>Applications: protection of generators, persons, very long cables<BR/>Curve C: Tripping: 5 to 10 times the rated current<BR/>Applications: protection of circuits and general applications<BR/>Curve D: Tripping: 10 to 14 times the rated current<BR/>Applications: protection of high surge circuits, welders, transformers and motors

<B>Schneider Electric LC1D Series Contactor, 4 Poles, 80A Contact Current Rating - LC1D65008P7</B> This contactor is designed for efficient load control applications, featuring a robust construction suited for industrial environments. The four-pole configuration offers versatile functionality, while the compact dimensions of 127mm in length, 85mm in width, and 125mm in depth make it ideal for installation in limited spaces. Operating at a coil voltage of 230V, it manages loads up to 80A effectively, handling maximum contact voltage ratings of 690V AC. <B>Features & Benefits</B> • Supports resistive loads ensuring optimal performance <BR/>• Rated operational current of 80A for reliable operation <BR/>• Utilisation category AC-1 for standard applications <BR/>• Offers operational temperature range from -40°C to 60°C <BR/>• Compatible with standard 35mm DIN rail mounting <B>Applications</B> • Used in automation systems for controlling motor operations <BR/>• Utilised in industrial machinery for power distribution <BR/>• Suitable for HVAC systems to manage electrical loads <BR/>• Applied in lighting control for large facilities <BR/>• Implemented in commercial electrical installations for safety <B>What is the electrical durability of this device when handling an 80A load?</B> It provides substantial electrical durability of 1.4 million cycles while handling an 80A load at operational voltage levels up to 440V AC, ensuring long-lasting performance. <B>Can this contactor withstand extreme environmental conditions?</B> Yes, it is designed to operate in a wide temperature range, from -40°C to 60°C, enabling it to function reliably even in harsh environmental conditions. <B>What are the connection and terminal specifications for this contactor?</B> The device features screw clamp terminals accommodating flexible and solid cables, allowing for easy installation of various cable sizes up to 35mm² for power circuits and 4mm² for control circuits. <B>How does this device ensure safety and prevent electrical failures?</B> It is equipped with a rated insulation voltage of 600V and conforms to standards such as EN 60947, which enhances safety and reliability during operation under normal and fault conditions.

Accessories for Cam Switches Accessories suitable for use with Schneider Harmony K series cam switches.

XB5 Accessories

<B>Schneider Electric Acti 9 DT40 MCB 1 Pole</B> Acti 9 DT40 series multi-standard circuit breakers combine circuit protection against short circuit currents and circuit protection against overload currents it also protects people against indirect contact with TN and IT neutral systems. Fully compliant with standards IEC/EN 60898 and IEC/EN 60947-2. ACTi 9 is fully tested, approved and certified by national and international third parties. It guarantees that your installation is safe and compliant with all relevant safety standards which demonstrates to your customers that you use industry-approved materials and best practices. These MCBs are normally used for high inductive loads where switching surges are high. Providing essential protection in industrial and commercial buildings, these miniature circuit breakers work especially well in polluted environments and networks. VisiSafe guarantees the downstream circuit is always safe regardless of overvoltage conditions, even in the most demanding environments; the green strip indicates the safe position of contacts.<BR/>VisiTrip red window on the front face indicates fault tripping allowing fast diagnosis, resolution, and reclosing loads for easier building management and reduced downtime <B>Benefits and Features</B> Downstream circuit is always safe<BR/>Class-2 insulation: ensures continuous protection for both operators and unqualified persons. <BR/>Insulated terminals (IP20)<BR/> Highly durable with robust connections that provide twice the standard tightening torque. <BR/>Provide greater continuity of service thanks to VisiTrip. <BR/>Double clip for dismounting with comb busbar in place 5 pc- 5/64&#146;&#146; hex key wrenches with polybag <B>Standards</B> IEC 60898 - Relates to Low Voltage Circuit Breakers for use in household and similar<BR/>Installations. In the UK traditionally known as miniature circuit breakers <BR/>(MCB&#146;s).<BR/>IEC 60947-2 Relates to Low Voltage Circuit Breakers for use in industrial and similar<BR/>Installations. In the UK traditionally known as moulded case circuit breakers <BR/>(MCCB&#146;s) and also air circuit breakers (ACB&#146;s).<BR/> <B>Q: What is the differences in the Tripping Curves B, C, and D?</B> A: Curve B: Tripping: 3 to 5 times the rated current.<BR/>Applications: protection of generators, persons, very long cables <BR/> Curve C: Tripping: 5 to 10 times the rated current<BR/>Applications: protection of circuits and general applications<BR/> Curve D: Tripping: 10 to 14 times the rated current <BR/>Applications: protection of high surge circuits, welders, transformers and motors

Schneider Electric XB5FD33 This flush mounted selector switch is a part of the Harmony XB5 plastic range and is a complete product. It has a mounting diameter of 30.5 mm. Customized marking option through web customization tool is available in Schneider Electric website. The flush mount design of this selector switch addresses the market demands for ergonomic and aesthetics. It comes with antimicrobial characteristics. It has a black standard handle with 3 positions ± 45 degree stay put. The contact type is 2NO slow break and the connection terminal is screw clamp. The shape of the head is round. The bezel and the fixing collar is plactic. The weight of this selector switch is 43 grams, height is 42 mm, and width is 36.6 mm. The simplicity of installation, flexibility, and robustness makes it suitable for the majority of industrial segments and applications. With IP66, 67, 69, and 69K, type 13, and 4X, IK03, protection against solid objects, dust, water, and high impact is achieved. It is certified with EN/IEC, CE marking, UL, CSA, NEMA, JIS, and marine approvals. To name a few, flush mounted metal circular blanking plug, metal ring, spacer, protective washer, and flush mounting kit are some of the dedicated accessories to be ordered separately, available to facilitate the installation. The packaging includes 1 unit of this selector switch. It can be easily installed to a panel cut out with the help of a cross head screwdriver. Contacts and heads are designed to prevent vibration, helping to ensure secure mounting and wiring. Operating temperature from -40°C to 70°C<BR/>High chemical robustness<BR/>High vibration resistance with shake-proof terminal screws<BR/>Large set of accessories to customize your panels<BR/>Various types of connection are available: screw clamp, connector, Faston connector, spring terminal, or printed circuit board.<BR/>A wide choice of contact blocks for general purpose or specific applications (low current, standard, or high power switching) <BR/>Benefits<BR/>High performance in chemical environments (cleaning solvents, alcohol, detergent, cutting oil, milk)<BR/>Attractive and affordable flush mount versions, stylish and easy to clean<BR/>Flexibility and adaptability through modular design<BR/>Simplicity and speed of installation<BR/>Wide offer providing a solution for all of your applications<BR/>Applications<BR/>General purpose offer covering all segments and applications:Industry<BR/>Machines and control panels in packaging, material handling, pumping…<BR/>Ideal in extreme environments: food and beverage, marine, etc. Building and infrastructure<BR/>Energy distribution panels, public works, restaurants, commercial buildings, airports, etc. Flush mounted selector switch 3 pos stay put 2NO screw clamp

Acti9 Cutable Comb Busbars Range of cutable comb busbars compatible with IC60, IID, ISW-NA, IK60, IID K and ISW switch disconnector Mounting mode: Horizontal <BR/>Rated operational voltage: 415 V AC <BR/>Rated insulation voltage: 500 V AC

<B>Schneider Electric Acti 9 DT40 MCB 1 Pole</B> Acti 9 DT40 series multi-standard circuit breakers combine circuit protection against short circuit currents and circuit protection against overload currents it also protects people against indirect contact with TN and IT neutral systems. Fully compliant with standards IEC/EN 60898 and IEC/EN 60947-2. ACTi 9 is fully tested, approved and certified by national and international third parties. It guarantees that your installation is safe and compliant with all relevant safety standards which demonstrates to your customers that you use industry-approved materials and best practices. These MCBs are normally used for high inductive loads where switching surges are high. Providing essential protection in industrial and commercial buildings, these miniature circuit breakers work especially well in polluted environments and networks. VisiSafe guarantees the downstream circuit is always safe regardless of overvoltage conditions, even in the most demanding environments; the green strip indicates the safe position of contacts.<BR/>VisiTrip red window on the front face indicates fault tripping allowing fast diagnosis, resolution, and reclosing loads for easier building management and reduced downtime <B>Benefits and Features</B> Downstream circuit is always safe<BR/>Class-2 insulation: ensures continuous protection for both operators and unqualified persons. <BR/>Insulated terminals (IP20)<BR/> Highly durable with robust connections that provide twice the standard tightening torque. <BR/>Provide greater continuity of service thanks to VisiTrip. <BR/>Double clip for dismounting with comb busbar in place 5 pc- 5/64&#146;&#146; hex key wrenches with polybag <B>Standards</B> IEC 60898 - Relates to Low Voltage Circuit Breakers for use in household and similar<BR/>Installations. In the UK traditionally known as miniature circuit breakers <BR/>(MCB&#146;s).<BR/>IEC 60947-2 Relates to Low Voltage Circuit Breakers for use in industrial and similar<BR/>Installations. In the UK traditionally known as moulded case circuit breakers <BR/>(MCCB&#146;s) and also air circuit breakers (ACB&#146;s).<BR/> <B>Q: What is the differences in the Tripping Curves B, C, and D?</B> A: Curve B: Tripping: 3 to 5 times the rated current.<BR/>Applications: protection of generators, persons, very long cables <BR/> Curve C: Tripping: 5 to 10 times the rated current<BR/>Applications: protection of circuits and general applications<BR/> Curve D: Tripping: 10 to 14 times the rated current <BR/>Applications: protection of high surge circuits, welders, transformers and motors

<B>Schneider Electric | GV2M Series | Motor Protection Circuit Breaker</B> Protecting your motors from faults such as an overload of high voltage, short circuits, or relay shutdowns is vital in an age where any downtime can be detrimental to a business and its operations. Schneider Electric has built a reliable, robust series known as the GV2M series of Motor Protection Circuit Breaker to act as an intermediary between your devices, protecting vital equipment in the event of unforeseen incidents. <B>Features and benefits:</B> &#149; Flexibility in locking the N/C position via the use of 3 padlocks is available. &#149; Motor Protection Switch Push button style control type with easily distinguishable button, coloured in red. &#149; 100,000 cycles of electrical/mechanical durability. &#149; Light-weight, robust and compact in its design, the GV2M series is perfect for tight spaces. &#149; If used on its own, the MPCB has manual or local control. Combined with a contactor and you have access to an automatic & remote control. &#149; Spring terminal & Screw clamping is available. <B>Protection ratings & Safety features:</B> &#149; Live parts are inaccessible to any direct contact from external users, improving the safety of operations around the MPCB. &#149; Thermal-magnetic trip technology to help protect the unit built into the circuit-breaker. &#149; EN 60204, IEC 60947-1, IEC 60947-2, IEC 60947-4-1 standard ratings (full list in the datasheet). &#149; Certified ATEX, BV, CCC. CSA and more (full list in the datasheet). &#149; IP20 degree of protection, conforming to IEC 60529 - further protection against solid objects e.g a persons fingers. &#149; IK04 degree of protection - impacts of up to 0.5 Joules to the device offer limited protection. <B>Applications:</B> &#149; Electrical Motor Control and protection &#149; Easily assembled into any configuration by screw or clip-fixing onto mounting rails. <B>How do you select the right Motor Protection Circuit Breaker?</B> MPCBs are more critical now than ever. Most infrastructure now relies on a motor behind the scenes to power critical uninterruptible systems such as heating, ventilation, cooling all of which we take for granted. These systems are vital in ensuring business productivity and therefore must be protected against overcurrents, thermal overloads and much more. To select the right MPCB, consider the systems you and your business rely upon. Checking the features and benefits of each MPCB will prove invaluable when deciding what critical infrastructure you wish to protect.

Accessories for the Open and Enclosed Switch Disconnectors

<B>Schneider Electric | GV2P Series | Motor Protection Circuit Breaker</B> Protecting your motors from faults such as an overload of high voltage, short circuits, or relay shutdowns is vital in an age where any downtime can be detrimental to a business and its operations. Schneider Electric has built a reliable, robust series known as the GV2P series of Motor Protection Circuit Breaker to act as an intermediary between your devices, protecting vital equipment in the event of unforeseen incidents. <B>Features and benefits:</B> &#149; Flexibility in locking the N/C position via the use of 3 padlocks is available.<BR/><BR/>&#149; Motor Protection Switch rotary knob style control type.<BR/><BR/>&#149; 100,000 cycles of electrical/mechanical durability.<BR/><BR/>&#149; Light-weight, robust and compact in its design, the GV2P series is perfect for tight spaces.<BR/><BR/>&#149; If used on its own, the MPCB has manual or local control. Combined with a contactor and you have access to an automatic & remote control.<BR/><BR/>&#149; Spring terminal & Screw clamping is available.<BR/><BR/>&#149; Thermal- magnetic trip unit technology.<BR/><BR/><B>Protection ratings & Safety features:</B><BR/><BR/>&#149; Live parts are inaccessible to any direct contact from external users, improving the safety of operations around the MPCB.<BR/><BR/>&#149; Thermal-magnetic trip technology to help protect the unit built into the circuit-breaker.<BR/><BR/>&#149; EN 60204, IEC 60947-1, IEC 60947-2, IEC 60947-4-1 standard ratings (full list in the datasheet).<BR/><BR/>&#149; Certified ATEX, BV, CCC. CSA and more (full list in the datasheet).<BR/><BR/>&#149; IP20 degree of protection, conforming to IEC 60529 - further protection against solid objects e.g a persons fingers.<BR/><BR/>&#149; IK04 degree of protection - impacts of up to 0.5 Joules to the device offer limited protection. <B>Applications:</B> &#149; Electrical Motor Control and protection<BR/><BR/>&#149; Easily assembled into any configuration by screw or clip-fixing onto mounting rails. <B>How do you select the right Motor Protection Circuit Breaker?</B> MPCBs are more critical now than ever. Most infrastructure now relies on a motor behind the scenes to power critical uninterruptible systems such as heating, ventilation, cooling all of which we take for granted. These systems are vital in ensuring business productivity and therefore must be protected against overcurrent, thermal overloads and much more. <BR/><BR/>To select the right MPCB, consider the systems you and your business rely upon. Checking the features and benefits of each MPCB will prove invaluable when deciding what critical infrastructure you wish to protect.
