Traco 5W TDN 5WI Series Isolated DC/DC Converters The TDN 5WI series of isolated DC/DC converters is a range of 5 Watt regulated dc/dc converters. They come in a very small compact DIP package measuring 13.2 x 9 x 10 mm. Ultra compact DIP package 0.52 x 0.36 x 0.40 inchI/O-isolation 1'500VDCFully regulated outputsOperating temperature range -40°C to +75°C without deratingShort circuit protectionRemote on/off

Traco Power DC-DC Converter, 3,000V DC Isolation Voltage, 4:1 Input Voltage Range - TMDC 06 Series - TMDC 06-2411 Struggling to reliably reduce your supply voltage in harsh conditions? Sort things out with this DC-DC converter from Traco Power. A wide input range from 9 to 36V DC enables you to hook it up to available power supplies in industrial, telecommunication and HVAC environments. Functional isolation and a 5.1V DC output means you can safely feed low-power circuits and equipment. As the unit comes fully encapsulated and works reliably in temperatures between -40°C and 80°C without a loss of performance, it's a robust option for heavy plant conditions. Features & Benefits • Overload, under-voltage and short-circuit protections take care of electrical faults• Chassis mounting style makes it handy for installation on machinery and control panels Applications • Textiles industry• IT and communications networks• Audio-visual equipment Does this DC-DC converter produce EMI? Integrated filters mean this component meets the EN 55032 standard for electromagnetic emissions in commercial and industrial applications. This ensures ripple and noise typically measure in at just 75mVp-p, so you can depend on this converter for use with professional audio-visual equipment, entertainment lighting controls and IT equipment. As there's no need to fit external filters, you need minimal installation space.

The TRACOPOWER TXO is a compact 45 Watt AC/DC open frame module with reinforced I/O isolation designed for a wide range of cost sensitive applications. Excellent temperature behaviour allows full load operation from -20°C to +50°C while going up to +70°C with derating. The TXO 45 series features short circuit protection, over current limitation and overvoltage protection and complies with European EMC standards and the Low Voltage Directive (LVD). Compact open frame power supply with pin connectorsUniversal input range 85 to 264 VACConvection cooledInternal EN55032 class B filterShort circuit protectionOvervoltage and overload protectionCompliance to EN 61000 3 23 year product warranty

Traco 1W SIP Fully Regulated Isolated DC-DC Converter - TMR 1 Series The Tracopower TMR 1 series is a compact 1W isolated DC-DC converter in SIP package. The TMR 1 has a wide 2:1 input voltage range and fully regulated outputs. Wide 2:1 input voltage rangeFully regulated outputsOperating temperature -40°C to +85°CNo minimum load requiredI/0 isolation 1500 VDCShort circuit protection

Traco 3W Isolated DC-DC Converter - TEN 3N Series The Traco Power TEN 3N Series of DC-DC Converters is a 3 Watt converter in DIP24 package. The updated design of this wide input DC-DC converter enables cost reduction without compromising on reliability and function. These Power converters come with an internal filter to meet EN55022 class A without external components. The TEN 3N series of DC-DC converters are the ideal solution for cost critical but demanding application, thanks to their increased EMC immunity and extended operating temperature range of -40°C to 85°C. Wide 2 : 1 input rangeInput filter to meet EN 55022, Class A and FCC, level A without external componentsExtended operating temperature range –40°C to 85°CI/O isolation 1’500 VDCDIP-24 packageHigh reliability, MTBF >1.0 Mio. h3-year product warranty

Traco Isolated DC - DC Converter, TEL 8WI Series From Tracopower the ultra-compact isolated 8WI series DIP-16 metal-packaged DC-DC converter with an ultra-wide 4:1 input voltage range. This DC-DC converter provides up to 86% efficiency allowing an operating temperature of up to +70°C at full load and and up to 80°C with 50% load. The Tracopower TEL 8WI series also comes equipped with an input filter, allowing the series to comply with EN55022 class A conducted emission.The Tracopower TEL 8WI series is a cost-effective product, without compromise on performance. This series is suited to applications where space is at a premium, such as instrumentation, IT and industrial electronics. Features and Benefits • Ultra-compact design with a DIP-16 metal package• Wide 4:1 input range.• Fully regulated outputs• Built in EN 55022 class A filter• Operating temperature range of -40 to +80°C• Equipped with industry standard safety features such as overload and short circuit protection.

Traco 12W Output Regulated Isolated DC-DC Converter - THD12WI Series The Traco Power THD 12WI series is a range of high performance, isolated, 12 Watt, DC-DC converters in a DIP-24 package with industry-standard footprint. With their high efficiency these regulated converters allows an operating temperature range of -40°C to +85°C. The THD 12WI series feature Built-in filters for both input and output minimizing the need of external filtering. These DC-DC converters offer overload and overvoltage protection, as well as remote On/Off. The THD 12WI DC-DC power supplies have a full SMD-design with exclusive use of ceramic capacitors, which guarantees high reliability and long product lifetime. Typical applications for these converters are industrial electronics, instrumentation, data communication systems and battery operated equipment with limited space available on the PCB. High power density: 12W in DIP 24 packageUltra-wide 4:1 input rangeVery high efficiency up to 85%I/O isolation 1500VInput filter meets EN 55022A without ext. componentsRemote On/OffUnder voltage lock-out circuitShielded metal case with insulated baseplateContinuous short-circuit protectionOperating temp. range –40°C to +85°CLead free design, RoHS compliant

Traco Power Redundancy Module, Remote ON/OFF, Screw Terminals - TSP-REM Series - TSP-REM360 Keep your equipment running smoothly with this redundancy module from Traco Power. You can use it with two identical TSP-series 24V DC power supplies to establish a redundant power system that lets you avoid downtime and process failures. Both units together supply the desired 24V DC output voltage in normal circumstances. If one unit fails, the other automatically delivers the full load. Alarm monitoring keeps you abreast of system status so you can carry out maintenance as needed. Features & Benefits • Remote ON/OFF function for easy control in complex systems• Operating temperature range between -25°C and +70°C means it's suitable for harsh conditions• Aluminium chassis is lightweight and durable• IP20 protection against accidental touch and objects larger than 12mm, for shock-free handling Applications • Heating systems• Industrial automation equipment• Telecommunications networks Can I change one of the attached power supply modules while the other stays active? Yes, the outputs on this redundancy module are hot-swappable so you can replace one while the other remains on. This lets you keep vital equipment running without a hitch.

The TRACO POWER TEN 60WIR is a ruggedized 60 Watt railway approved DC/DC converter series with a wide 4:1 input voltage range and increased resistance against electromagnetic interference, shock/vibration and thermal shock. The standard version comes with a preassembled heatsink which was specifically designed for this 2” x 1” metal package converter. Together with a high efficiency of up to 92% this gives the converter an effective operating temperature range of -40° to +70°C without derating. Operating temperature range –40°C to +90°CI/O-isolation 3’000 VDCEfficiency 92%Under voltage lock out circuitAdjustable output voltage and Remote On/OffEN 50155 and EN 61373 approval for railway applicationsQualification for fire behaviour according to EN 45545-2

TRACOPOWER TDR 2SM Series DC-DC Converter, 4.5 to 9 V DC Input Voltage Range, 2W Power Rating - TDR 2-0523SM This DC-DC converter by TRACOPOWER is a high-quality, isolated power solution with a 2W power rating. It is designed for efficiency and reliability, making it a dependable choice for a wide range of applications. Features & Benefits • Compact design suitable for surface mounting• Wide 2:1 input voltage range for flexibility• Fully regulated outputs for stable performance• Low ripple and noise for clean power delivery• High efficiency over the full load range• Remote on/off control for convenience• Continuous short-circuit protection for safety Applications • Ideal for use in communication equipment• Suitable for instrumentation applications• Can be used for industrial electronics Can it provide stable power in a wide range of temperatures? This DC-DC converter can operate reliably in temperatures ranging from -40°C to +85°C without any derating. Will it work efficiently without a minimum load requirement? Yes, this converter does not require a minimum load to operate efficiently, making it versatile for various applications. Is it suitable for space-critical applications? With its compact design and high reliability, this DC-DC converter is the reliable solution for space-critical high-end applications.

Traco 20W Single/Dual Output Regulated Isolated DC-DC Converter - THN 20WI Series 20W single/dual output regulated isolated high performance DC-DC converter modules with a high power density, wide input voltage range and low input current characteristics at minimal load. These regulated isolated high performance DC-DC converter modules have a high efficiency enabling operation in temperature ranges of up to 75°C or 85°C with a heatsink. Typical applications for these DC-DC converter modules include mobile equipment, instrumentation and distributed power architectures in communication and industrial electronics. Ultra compact size: 1.0” x 1.0” x 0.4”Shielded metal case with isolated baseplateWide 4:1 input voltage rangesVery high efficiency up to 90%Output voltage adjustableRemote On/Off controlOperating temp. range –40°C to +75°C and up to 85 °C with heat-sinkI/O isolation voltage 1500 VdcInput filter meets EN 55022 class A without external componentsNo minimum load required

Tracopower (TME Series) 1W SIP Single Output Unregulated Isolated DC-DC Converter The Traco Power TME series is a range of miniature isolated, 1 Watt, DC/DC converters in a SIP package. The full SMD design of these isolated converters makes it possible to offer a product with high performance at a low cost. The TME DC-DC converters require only 0.7 cm2 board space and are the perfect solution for space-critical industrial applications for board level power distribution. (Series) Features & Benefits: • Operating temperature (–40°C to +85°C), Storage temperature (–50°C to +125°C), Case temperature (Max. +90°C) • Humidity (non-condensing) 95 % rel H max • Isolation voltage (input/output) 1,000 VDC, Isolation capacity (input/output) 60 pF typ, Isolation resistance (input/output) >1,000 Mohm • Lead-free design, RoHS compliant • Industry-standard pinout • Casing material non-conductive black plastic (UL 94-V0 rated) (Series) Input specifications: • Reverse polarity input current 0.3 A max.• Reflected input ripple current can be reduced by ext. 1 – 3.3 μF polyester film capacitor• Input filter Internal capacitors (Series) Output specifications: • Capacitive load of 33 μF max • Short circuit protection limited 0.5 s max. • Ripple and noise (20 MHz Bandwidth) 150 mVp-p max. • Temperature coefficient ±0.01 %/K typ. / ±0.02 %/K max
