Splashproof Rocker Switches A range of illuminated and non-illuminated double pole rocker switches designed for panel mounting. These high inrush switches are AC mains rated with a 150 A surge capability. With simple snap-in panel retention, these rocker switches are easy to install. Featuring an ergonomic Softline actuator and an IP40 splash resistant cover, ideal for environments where exposure to moisture is a possibility. The latching on-off switches are available with a black body and a choice of red or green illumination depending on application and design requirements. Suitable for maintenance and repair of equipment and machinery or new installations.<BR/><BR/><B>Features and Benefits</B><BR/><BR/>• I/O markings<BR/>• An option of red or green illumination<BR/>• Clear protective splash resistant front cover<BR/>• Ergonomic Softline actuator<BR/>• Silver alloy contacts<BR/>• Secure snap-in panel mounting<BR/>• Standard 30 x 22.1 mm cut out<BR/>• Connection via 6.3 mm x 0.8 mm spade terminals<BR/>• DPST switch configuration<BR/><BR/><B>Typical applications for splash resistant rocker switches</B><BR/><BR/>Rocker switches are one of the most frequently used electrical switches used in the market today. Due to the simple design and easy operation, rocker switches are found in almost every industry. Some of the most common are:<BR/><BR/>• Laboratory equipment<BR/>• Power supplies and peripherals<BR/>• Portable test equipment<BR/>• Audio and video equipment<BR/>• Domestic appliances<BR/>• Security equipment<BR/><BR/><B>FAQ</B><BR/><BR/>•<B> Are the rocker switches easy to connect?</B><BR/>Yes, as the rocker switches have male quick connect 0.250 in (6.35 mm) tab terminals at the rear connection is easy. Simply select the appropriate red, yellow or blue female receptacle crimp connectors according to wire size required.<BR/>• Part number<B> </B><a href="/web/p/products/129432">129-432</a><B> </B>is a green illuminated rocker switch<BR/>• Part number <a href="/web/p/products/129426">129-426</a> is a red illuminated rocker switch<BR/>• Part number <a href="/web/p/products/129448">129-448</a> is a black non-illuminated rocker switch<BR/> <BR/>

Splashproof Rocker Switches A range of illuminated and non-illuminated double pole rocker switches designed for panel mounting. These high inrush switches are AC mains rated with a 150 A surge capability. With simple snap-in panel retention, these rocker switches are easy to install. Featuring an ergonomic Softline actuator and an IP40 splash resistant cover, ideal for environments where exposure to moisture is a possibility. The latching on-off switches are available with a black body and a choice of red or green illumination depending on application and design requirements. Suitable for maintenance and repair of equipment and machinery or new installations.<BR/><BR/><B>Features and Benefits</B><BR/><BR/>• I/O markings<BR/>• An option of red or green illumination<BR/>• Clear protective splash resistant front cover<BR/>• Ergonomic Softline actuator<BR/>• Silver alloy contacts<BR/>• Secure snap-in panel mounting<BR/>• Standard 30 x 22.1 mm cut out<BR/>• Connection via 6.3 mm x 0.8 mm spade terminals<BR/>• DPST switch configuration<BR/><BR/><B>Typical applications for splash resistant rocker switches</B><BR/><BR/>Rocker switches are one of the most frequently used electrical switches used in the market today. Due to the simple design and easy operation, rocker switches are found in almost every industry. Some of the most common are:<BR/><BR/>• Laboratory equipment<BR/>• Power supplies and peripherals<BR/>• Portable test equipment<BR/>• Audio and video equipment<BR/>• Domestic appliances<BR/>• Security equipment<BR/><BR/><B>FAQ</B><BR/><BR/>•<B> Are the rocker switches easy to connect?</B><BR/>Yes, as the rocker switches have male quick connect 0.250 in (6.35 mm) tab terminals at the rear connection is easy. Simply select the appropriate red, yellow or blue female receptacle crimp connectors according to wire size required.<BR/>• Part number<B> </B><a href="/web/p/products/129432">129-432</a><B> </B>is a green illuminated rocker switch<BR/>• Part number <a href="/web/p/products/129426">129-426</a> is a red illuminated rocker switch<BR/>• Part number <a href="/web/p/products/129448">129-448</a> is a black non-illuminated rocker switch<BR/> <BR/>

Mini Double Pole A fully approved double pole rocker switch<BR/>Fits into the space traditionally required for a single pole switch<BR/>DPST silver contacts<BR/>Connection via 6·3mm faston connectors<BR/>>3mm contact gap<BR/>Nylon 66 94 V-2

Curved Rocker Switches The single throw types have 3mm contact separation<BR/>Electrical life: >10⁴ operations at full load<BR/>Maximum operating temperature: +90°C<BR/>Connection is by 4.8x0.8mm blade terminals<BR/>Dimensions: H21, W15 (SP), W24 (DP), depth behind panel 12.5 (19.9 with terminals), max. panel thickness 3 mm

Toggle Switches, Std, Toggle Cover Splashproof switch covers to fit toggles with a 0.468 in dia. bush<BR/>Moulded in black flexible PVC threaded insert<BR/>Half cover leaves end of toggle exposed whilst maintaining seal on shaft<BR/>This is especially useful where high wear on the switch is envisaged

Toggle Switches, Std, Toggle Cover Splashproof switch covers to fit toggles with a 0.468 in dia. bush<BR/>Moulded in black flexible PVC threaded insert<BR/>Half cover leaves end of toggle exposed whilst maintaining seal on shaft<BR/>This is especially useful where high wear on the switch is envisaged

Arcolectric Miniature Push Button Switches Momentary action switches with slow make-and-break contacts. <BR/>Single hole fixing to clear 7.4mm.<BR/>Solder terminals<BR/>Contact Material: Gold flashed Ag/Cu Alloy<BR/>Contact Rating: 0.5A @ 240Vac

Arcolectric Miniature Push Button Switches Momentary action switches with slow make-and-break contacts. <BR/>Single hole fixing to clear 7.4mm.<BR/>Solder terminals<BR/>Contact Material: Gold flashed Ag/Cu Alloy<BR/>Contact Rating: 0.5A @ 240Vac

Panel Mount Mains Pushbutton Switches Arcolectric presents the 8300 series of Mains Pushbutton Switches. These high current miniature switches are designed for easy snap-in panel mounting and are available in both illuminated and non-illuminated versions and with latching and momentary options. <B>Features and Benefits:</B><BR/>• Double pole switches for snap fitting into a 19.2x13 panel cutout<BR/>• 3mm contact gap<BR/>• Operating Temperature 105°C <BR/>• Contact Resistance <20MΩ <BR/>• Contact Material Silver Alloy <BR/>• Dielectric Strength >1000V <BR/>• Insulation Resistance >20MΩ <BR/>• Electrical Life (operations) 10000 <BR/>• Actuator Length (mm) 4.5 <BR/>• Actuator Width (mm) 15 <BR/>• Height (mm) 21 <BR/>• Max. Panel Thickness (mm) 2 - 3<BR/>• Panel Cut-out (mm) 19.2x13 <BR/>• Depth Behind Panel (mm) 25.5 The 8300 Series includes: • Stock number <a href="/web/p/products/2507907">250-7907</a> is a black, non-illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/2507913">250-7913</a> is a black, non-illuminated pushbutton switch (Momentary)<BR/>• Stock number <a href="/web/p/products/2507929">250-7929</a> is a red, illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/2507935">250-7935</a> is a green, illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/5333030">533-3030</a> is a red, non-illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/5333046">533-3046</a> is a red, non-illuminated pushbutton switch (Momentary)<BR/>• Stock number <a href="/web/p/products/5333052">533-3052</a> is a green, non-illuminated pushbutton switch (Momentary)

Panel Mount Mains Pushbutton Switches Arcolectric presents the 8300 series of Mains Pushbutton Switches. These high current miniature switches are designed for easy snap-in panel mounting and are available in both illuminated and non-illuminated versions and with latching and momentary options. <B>Features and Benefits:</B><BR/>• Double pole switches for snap fitting into a 19.2x13 panel cutout<BR/>• 3mm contact gap<BR/>• Operating Temperature 105°C <BR/>• Contact Resistance <20MΩ <BR/>• Contact Material Silver Alloy <BR/>• Dielectric Strength >1000V <BR/>• Insulation Resistance >20MΩ <BR/>• Electrical Life (operations) 10000 <BR/>• Actuator Length (mm) 4.5 <BR/>• Actuator Width (mm) 15 <BR/>• Height (mm) 21 <BR/>• Max. Panel Thickness (mm) 2 - 3<BR/>• Panel Cut-out (mm) 19.2x13 <BR/>• Depth Behind Panel (mm) 25.5 The 8300 Series includes: • Stock number <a href="/web/p/products/2507907">250-7907</a> is a black, non-illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/2507913">250-7913</a> is a black, non-illuminated pushbutton switch (Momentary)<BR/>• Stock number <a href="/web/p/products/2507929">250-7929</a> is a red, illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/2507935">250-7935</a> is a green, illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/5333030">533-3030</a> is a red, non-illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/5333046">533-3046</a> is a red, non-illuminated pushbutton switch (Momentary)<BR/>• Stock number <a href="/web/p/products/5333052">533-3052</a> is a green, non-illuminated pushbutton switch (Momentary)

Panel Mount Mains Pushbutton Switches Arcolectric presents the 8300 series of Mains Pushbutton Switches. These high current miniature switches are designed for easy snap-in panel mounting and are available in both illuminated and non-illuminated versions and with latching and momentary options. <B>Features and Benefits:</B><BR/>• Double pole switches for snap fitting into a 19.2x13 panel cutout<BR/>• 3mm contact gap<BR/>• Operating Temperature 105°C <BR/>• Contact Resistance <20MΩ <BR/>• Contact Material Silver Alloy <BR/>• Dielectric Strength >1000V <BR/>• Insulation Resistance >20MΩ <BR/>• Electrical Life (operations) 10000 <BR/>• Actuator Length (mm) 4.5 <BR/>• Actuator Width (mm) 15 <BR/>• Height (mm) 21 <BR/>• Max. Panel Thickness (mm) 2 - 3<BR/>• Panel Cut-out (mm) 19.2x13 <BR/>• Depth Behind Panel (mm) 25.5 The 8300 Series includes: • Stock number <a href="/web/p/products/2507907">250-7907</a> is a black, non-illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/2507913">250-7913</a> is a black, non-illuminated pushbutton switch (Momentary)<BR/>• Stock number <a href="/web/p/products/2507929">250-7929</a> is a red, illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/2507935">250-7935</a> is a green, illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/5333030">533-3030</a> is a red, non-illuminated pushbutton switch (Latching)<BR/>• Stock number <a href="/web/p/products/5333046">533-3046</a> is a red, non-illuminated pushbutton switch (Momentary)<BR/>• Stock number <a href="/web/p/products/5333052">533-3052</a> is a green, non-illuminated pushbutton switch (Momentary)

Non-Illuminated Snap-mounting switches with silver contacts <BR/>Connection via .250in push-on receptacles<BR/>Contact rating 16 (4)A @ 250Vac<BR/>Contact resistance <100mΩ<BR/>Inrush rating 150A<BR/>Nylon 6.6; Polycarbonate actuator, Nylon 6.6 case<BR/>Dielectric Strength >1kV (Across Open Contacts); >3kV (Between Poles); >4kV (Between Live Parts and Accessible Metal)<BR/>Insulation Resistance >20mΩ<BR/>IP Rating IP40<BR/>Number Of Operations >10⁴<BR/>Hole cutters; single-pole <a href="/web/p/products/543721">543-721</a>; double-pole <a href="/web/p/products/545345">545-345</a>
