MF-SM Series Fully compatible with current industry standardsSelf-resetting on removal or reduction of trip currentPackaged per EIA 481-2 standard

The Bourns Electronics transient voltage suppressor diode for surge and ESD protection applications, in compact chip package DO-214AA (SMB) size format. Typical fast response times are less than 1.0 picosecond from 0 V to minimum breakdown voltage. It has 30 V working peak reverse voltage. 1500 watts power dissipationTypical temperature coefficient: DVBR = 0.1 % x VBR @ 25 °C x DT

The Bourns Electronics transient voltage suppressor diode for surge and ESD protection applications, in compact chip package DO-214AA (SMB) size format. Typical fast response times are less than 1.0 picosecond from 0 V to minimum breakdown voltage. It has 36 V working peak reverse voltage. 1500 watts power dissipationTypical temperature coefficient: DVBR = 0.1 % x VBR @ 25 °C x DT

6mm in. 250mW Side Adjust 3266X Series Bourns® 3266 Series 1/4" Square Multiturn Cermet Trimming Potentiometer (Trimpot®) Small size - high packing densitySealed to withstand immersion board washingDouble chevron shaft sealMoulded body with built in stand-offsWiper idles at ends of travel

6mm in. 250mW Side Adjust 3266X Series Bourns® 3266 Series 1/4" Square Multiturn Cermet Trimming Potentiometer (Trimpot®) Small size - high packing densitySealed to withstand immersion board washingDouble chevron shaft sealMoulded body with built in stand-offsWiper idles at ends of travel

The Bourns the overvoltage protectors devices are designed to limit overvoltages on digital telecommunication lines. Overvoltages are normally caused by a.c. power system or lightning flash disturbances which are induced or conducted on to the telephone line. A single device provides 2-point protection and is typically used for the protection of transformer windings and low voltage electronics. Low CapacitanceDigital Line Signal Level Protection ISDN,xDSLSafety Extra Low Voltage

The Bourns the transient voltage suppressor diodes for surge and ESD protection applications, in compact chip package DO-214AC (SMA) size format. The Transient Voltage Suppressor series offers a choice of Working Peak Reverse Voltage from 5 V up to 495 V and Breakdown Voltage up to 550 V. Typical fast response times are less than 1.0 picoseconds for unidirectional devices and less than 5.0 picoseconds for bidirectional devices from 0 V to Minimum Breakdown Voltage. RoHS compliantSurface Mount SMA packageStandoff Voltage 5.0 to 495 voltsPower Dissipation 400 wattsUL Recognized

Bourns 2300 Series Radial Chokes DC/DC converter, EMI filter applicationsLow radiationLow core lossHigh current capacityHorizontal or Vertical mountProduct Size 32.5mm Outside Diameter, 16.5mm ThickOperating temperature -55 to +105°C

4-Isolated Resistors

12-Turn 250mW 4mm 3224X Series Top Adjust Bourns Standard 3224X Series top adjust SMD Trimpot® trimming potentiometer with a power rating @ 70 °C of 0.25W. The 3224X series cermet trimmer features a flush adjustment screw, a pick and place centring design for automated placement compatibility and is Sealed to withstand standard board wash processing. Miniature (nominal 4mm square case size)Excellent mounting efficiencySuitable for flow/reflow soldering/hand solderMeets standard EIA and EIAJ footprintLow CRV - 1%

MF-NSMF Series Compact design to save board space - 1206 footprintSmall size results in very fast time to react to fault eventsSymmetrical designLow profile

H-516 Series 15 Turn Counting Dial From Bourns, the H-516 Series Counting Dial is for use with precision potentiometers or other rotating devices of up to 15 turns. The H-516 Series 0 – 15 turn counting dial has a compact design requiring only 22.8 mm diameter panel space, has no backlash and is for use with plastic shafts.
