The CONEC receptacle features a B17 size for the A side and integrates an RJ45 connector along with wire power for the B side. The A side connector housing is male, with power contacts configured as male and Ethernet contacts as female. It includes 4 positions for power contacts, including a protective earth, and 4 positions for data contacts. This hybrid assembly comes with a 1m cable and is designed for back panel mounting, utilizing a long version housing type. It employs a bayonet locking mechanism for secure connections, making it ideal for a range of applications. IP67 protection ratedRoHS compliant100 MHz Cat5 Performance data core

The CONEC Coaxial contact female 50 ohm with an inner conductor for solder termination and outer conductor for crimp or solder termination. Inner conductor minimum 50μin hard gold over minimum 50μin nickelOuter conductor minimum 30μin hard gold over minimum 50μin nickel

The CONEC Socket Connector C has a nickel base with 50 pins on all contacts. The contact area features 4 pins with hard gold plating, and the balance of the IDC pin is tin-plated. The operating temperature range is from -40°C to +105°C, and the current carrying capacity is 1A. It has a test voltage of 1000 Veff. Contacts Copper Alloy

The CONEC Coaxial Contact Socket 50 Ohm is designed for crimp termination of both the inner and outer conductors. It is compatible with cables such as 174U, 188AU, and 316U. Use Crimp Tool 360X10329XWith Tool Insert 360X11049XSelector Setting 5 for AWG26 center conductor of cable

The CONEC D-sub Female solder cup stamped contacts insulators are made of black PBT GF UL 94 V-0, while the contacts are constructed from copper alloy. The plating consists of a minimum 8μin hard gold over a minimum of 50μin nickel. The connector accepts cables with AWG 20. Metal shells made of steelMinimum 315μin tin plating over 40 to 80μin nickel

The CONEC Detent pin with threaded 4-40 UNC for snap lock with spring ring. Detent pin of Steel, nickel plated. Spring washer Steel and Nickel plated

The CONEC D-SUB Female 37pos. solder cup has a working voltage of 125 V AC, with a temperature range of -55°C to +125°C. It features a dielectric withstanding voltage of 1000 V, 50 Hz, for 1 minute. The connector's insulation resistance is greater than 5 GΩ, and it supports a current rating of 7.5 A (UL, VDE) / 5 A (CSA, VDE). It offers mating cycles as per the quality class, with quality class 1 allowing for 500 cycles, class 2 for 200 cycles, class 3 for 50 cycles, and class 4 supporting over 500 cycles. The solder cup accepts cables up to max. AWG 20. Contact Cu alloy, Au over NiInsulator PBT GF UL 94 V-0Shell made up of Steel and Sn over Ni

The CONEC D-Sub standard connectors with solder cup and AWG 20 stamped contacts. Shell Size 2 AShell Material SteelShell Plating Tin

The CONEC D-Sub standard connectors with solder cup and AWG 20 stamped contacts. Shell Size 4 cShell Material SteelShell Plating Tin

The CONEC D-Sub high-density connectors with solder cup and stamped contacts are designed for wire size AWG 22. They feature a through-hole mounting style with a diameter of 0.118 inch 3 mm. Quality class 3 (other quality classes available on request)Shell made of steel and tin-plated

The CONEC socket contact crimp is made from stamped phosphor bronze, with a gold flash over nickel finish in the contact area. It operates within a temperature range of -55°C to +125°C and is rated for a current of 7.5A Contact Resistance are greater than and equal to 10mΩCrimping Use Crimp Tool 360x10079X

The CONEC D-SUB Female 90° 9pos. Solder Pin Angled 0.370inch features copper alloy contacts with 8μin hard gold plating over a minimum of 50μin nickel. The metal bracket is made of zinc die-cast with 300μin copper, 40 to 120μin nickel, and 120-200μin tin. The threaded insert is copper alloy with a minimum of 200μin tin over 80μin nickel. The PCB-snap is made from copper alloy with a minimum of 200μin tin over 80μin nickel. Metal shells of Steel minimum. 315μin tin over 40 to 80μin nickelBlack insulators of PBT GF UL 94 V-0
