GWN Series, Grab Wire Designed to offer grabwire switch protection for personnel working in close proximity to conveyors or rotating and moving machines in various environments<BR/>Typical applications: - conveyors, assembly lines, transfer lines, packaging machinery, process equipment<BR/>Grabwire switches are a convenient way of installing two-rope pull switches on a long rope run, with common wiring and two heads<BR/>When the units are correctly installed and set, the system switching contacts are closed allowing the system to operate<BR/>If the grabwire is pulled the switch contacts will open, providing operator safety. Whether the grabwire has been pulled, gone slack or been broken, it can only be started by manually resetting the switch unit<BR/>100M max span, each side<BR/>Ingress protection to IP65 as standard<BR/>Sealed M20 cable entries<BR/>Safety and auxiliary contacts as standard 2N/C + 1N/O<BR/>To comply with BS 5304 switch units should be fitted at each end of the grabwire<BR/>To complete an installation a connection kit is required, containing the wire rope, instruction leaflet and all other necessary elements<BR/>Please order the appropriate kit for length for your installation from the RS Rope kits for grabwire switches<BR/>Standards & Approvals BS EN 60947-5-1, BS EN 60947-5-5, BS 5304

Emergency Stop Control Station - Aluminium Stayput, pull to release, key release or lockable flap action1 N/C and 1 N/O contact Ingress protection from IP652 x M20 cable entriesStandards: BS EN 60947-5-1, BS EN 60947-5-5

Craig & Derricott Emergency Stop Station The Craig & Derricott i-push series emergency stop station has a red mushroom style head pushbutton with the diameter of 38mm. The housing is made of die-cast aluminium material. The flap is depressed to actuate the pushbutton with one or more padlocks in position. This ensures resetting cannot take place until all the padlocks are removed. This pushbutton has a contact current rating of 16A and a voltage rating of 250V. Features and Benefits 1NO/1NC contact configuration<BR/><BR/>Pull to release actuation method<BR/>Cable entry of M20<BR/><BR/>Surface mount<BR/>Non-illuminated<BR/>Printed flap cover legend<BR/>Key release or lockable flap action Certifications BS EN 60947-5-1<BR/>BS EN 60947-5-5<BR/>IP65 rated

Craig & Derricott Emergency Stop Station The Craig & Derricott i-push series emergency stop station has a red mushroom style head pushbutton with the diameter of 38mm. The housing is made of die-cast aluminium material. This pushbutton has a contact current rating of 16A and a voltage rating of 250V. Features and Benefits 1NO/1NC contact configuration<BR/><BR/>Pull to release actuation method<BR/>Cable entry of M20<BR/><BR/>Surface mount<BR/>Non-illuminated<BR/>Circular yellow legend<BR/>Key release or lockable flap action Certifications BS EN 60947-5-1<BR/>BS EN 60947-5-5<BR/>IP65 rated

I-Switch Die-Cast Switch Disconnectors The die-cast range of enclosed switch disconnectors from Craig & Derricott provides the user with a product that can withstand harsh treatment in the industrial environment. With sealing to IP66 these products can safely be placed in environments where resistance to impacts, moisture and dust/dirt are a concern. IP66 contoured die cast enclosure

I-Switch Die-Cast Switch Disconnectors The die-cast range of enclosed switch disconnectors from Craig & Derricott provides the user with a product that can withstand harsh treatment in the industrial environment. With sealing to IP66 these products can safely be placed in environments where resistance to impacts, moisture and dust/dirt are a concern. IP66 contoured die cast enclosure

I-Switch Die-Cast Switch Disconnectors The die-cast range of enclosed switch disconnectors from Craig & Derricott provides the user with a product that can withstand harsh treatment in the industrial environment. With sealing to IP66 these products can safely be placed in environments where resistance to impacts, moisture and dust/dirt are a concern. IP66 contoured die cast enclosure

I-Switch Die-Cast Switch Disconnectors The die-cast range of enclosed switch disconnectors from Craig & Derricott provides the user with a product that can withstand harsh treatment in the industrial environment. With sealing to IP66 these products can safely be placed in environments where resistance to impacts, moisture and dust/dirt are a concern. IP66 contoured die cast enclosure

Sloped Roof Stainless Steel Switch Disconnectors Craig & Derricott i-switch range of slopped roof stainless steel switch disconnectors specially suited for hygienic environments. The design has been created to minimise areas where dirt can accumulate and incorporates a flush rear surface and universal fixing that include IP66 sealings. The i-switch range incorporates a mechanical interlock, which when a padlock is inserted prevents the enclosure lid from being removed. Features and Benefits Brushed satin stainless steel Padlockable in the 'Off' position Safety interlock included Two cable knockouts

Sloped Roof Stainless Steel Switch Disconnectors Craig & Derricott i-switch range of slopped roof stainless steel switch disconnectors specially suited for hygienic environments. The design has been created to minimise areas where dirt can accumulate and incorporates a flush rear surface and universal fixing that include IP66 sealings. The i-switch range incorporates a mechanical interlock, which when a padlock is inserted prevents the enclosure lid from being removed. Features and Benefits Brushed satin stainless steel Padlockable in the 'Off' position Safety interlock included Two cable knockouts

Sloped Roof Stainless Steel Switch Disconnectors Craig & Derricott i-switch range of slopped roof stainless steel switch disconnectors specially suited for hygienic environments. The design has been created to minimise areas where dirt can accumulate and incorporates a flush rear surface and universal fixing that include IP66 sealings. The i-switch range incorporates a mechanical interlock, which when a padlock is inserted prevents the enclosure lid from being removed. Features and Benefits Brushed satin stainless steel Padlockable in the 'Off' position Safety interlock included Two cable knockouts

Polycarbonate Switch Disconnector (On-load Isolator) High Impact polycarbonate enclosure<BR/>Contoured base for easy wiring<BR/>Up to 3 padlocks can be inserted in the off position<BR/>Neutral & earth Terminals<BR/>IP65 Ingress protection
