Ea Elektro-Automatik Ea-El 9000 B Series Electronic Load, 0 → 3600 W, 0 → 750 V, 0 → 60 A

EA-EL 9000B Series 3U Electronic Loads with Multi-function Controller EA-EL 9000B Series 19" 3U conventional electronic loads are adjustable and programmable. They come equipped with a high-performance FPGA (Field Programmable Gate Array) controller with 16-bit resolution. EA-EL 9000B features include a flexible DC input range for use at high voltage or high current as required, within the nominal power rating. The TFT touch panel has an easy-to-operate intuitive menu structure. This integrates multiple functions such as a function generator with default wave forms (e.g., sinus, square, trapezoidal, ramp, arbitrary), memory, alarm manager and user profiles. It displays U/I/R/P values with 4-digit resolution. The DC input is highly stable and filtered with 0...100% adjustable parameters, very dynamic (30μs) and generates no ripple (FET linear technology). For external automated control, 9000B models have an on-board isolated 0-5V/0-10V analog and USB interface. An intelligent plugn play slot allows retrofitting optionally available interface modules such as CANopen, Ethernet, Profibus and Modbus. EA-EL 9000B is an excellent choice for demanding load testing, to provide for reproducible test data, and is suitable for automated system integration to form heavy-duty load banks. EA-EL 9000B Series Features and Benefits: 1.2kW to 7.2kW 0-80V, 0-200V, 0-360V, 0-500V, 0-750V DC 0-20A up to 0-510A depending on model FPGA controlled and programmable Isolated analog 0-5V/0-10V & USB interface on board Operation modes CV, CC, CP, CR, battery discharge mode Integrated sequencer with default waveforms, memory, alarm manager, user profiles TFT touch panel (64,000 colours) and setting encoders (intuitive easy-to-operate HMI) Plugn play digital interface slot (many optional interfaces e.g. Ethernet, CANopen, Profibus) Control software "ea-power-control pro" for automated testing & data logging Housing 19" 3U for all power ratings up to 7.2kW True master-slave parallel operation with summary function, stackable to create heavy duty load racks Input voltage 115/230V∼ 50/60Hz Housing 19" rack 3U, dimensions 485 x 133 x 510 mm deep (including terminals) Applications: For laboratory use in R&D and industry, for low noise and highly dynamic applications Automated load test benches and burn-in rooms Programmed/sequenced dynamic load testing and aging simulation of DC sources of any kind e.g. battery chargers, telecom power supplies, industrial and laboratory power supplies, open-frame/built-in power supplies Programmed/sequenced load testing of DC sources such as PV modules (solar arrays), car and truck alternators, electric vehicle motors (operating in generator mode) Discharging of all types of energy storage devices such as batteries (Li, Pb, Ni-Cad, Ni-MH) capacitors and fuel cells Programmed/sequenced testing of semiconductors, passive and active electronic components such us rectifiers, fuses, transistors (IGBT, FET), contacts, diodes, circuit breakers

Show Details

Ea Elektro-Automatik Ea-Ps 2000 B Series Digital Bench Power Supply, 0 → 42V, 6A, 1-Output, 100W

EA-PS 2000B Series EA-PS 2000B series μ-processor controlled and USB-programmable low-cost power supplies provide for a fully flexible 'auto-ranging' output. Enabling them to work with either a higher voltage or a higher current within the stipulated U/I/P rating. They are equipped with digital encoders for U and I setting, a full 4-digit LCD segment display with various function status (output pre-set, -lock and standby). And a mini USB port for computer control. The units have high stability and low ripple and are protected against overcurrent (OCP), DC over-voltage (OVP) and over-temperature (OTP). Applications include R&D, repair, test, maintenance and vocational training in small laboratories, workshops, technical schools and universities. Features and Benefits Frequency 45 Hz to 65 Hz Operating temperature 0 to 50°C Attractive flat desk-top housing Natural convection (no fan) IEC 320-C14 input receptacle Output via safety (banana) sockets LIZENZCODE EASYPS2000B The LIZENZCODE EASYPS2000B is a Software tool to control and monitor power supplies and electronic loads. This software tool is easy to handle with a minimum of setup required. The surface is completely in English. This tool is compatible to the use with PS2000B series power supplies.

Show Details

Ea Elektro-Automatik Ea-Ps 2000 B Series Digital Bench Power Supply, 0 → 42V, 10A, 1-Output, 160W

EA-PS 2000B Series EA-PS 2000B series μ-processor controlled and USB-programmable low-cost power supplies provide for a fully flexible 'auto-ranging' output. Enabling them to work with either a higher voltage or a higher current within the stipulated U/I/P rating. They are equipped with digital encoders for U and I setting, a full 4-digit LCD segment display with various function status (output pre-set, -lock and standby). And a mini USB port for computer control. The units have high stability and low ripple and are protected against overcurrent (OCP), DC over-voltage (OVP) and over-temperature (OTP). Applications include R&D, repair, test, maintenance and vocational training in small laboratories, workshops, technical schools and universities. Features and Benefits Frequency 45 Hz to 65 Hz Operating temperature 0 to 50°C Attractive flat desk-top housing Natural convection (no fan) IEC 320-C14 input receptacle Output via safety (banana) sockets LIZENZCODE EASYPS2000B The LIZENZCODE EASYPS2000B is a Software tool to control and monitor power supplies and electronic loads. This software tool is easy to handle with a minimum of setup required. The surface is completely in English. This tool is compatible to the use with PS2000B series power supplies.

Show Details

Ea Elektro-Automatik Ea-Ps 2000 B Series Digital Bench Power Supply, 0 → 84V, 3A, 1-Output, 100W

EA Elektro-Automatik Laboratory Power Supply The EA Elektro-Automatik laboratory bench power supply has a power rating of 100W. It is microprocessor controlled and USB-programmable single-channel power supply which provides fully flexible 'auto-ranging' output. Enabling them to work with either a higher voltage or a higher current within the stipulated U/I/P rating. These power supplies are equipped with digital encoders for U and I setting. It has a full 4-digit LCD segment display with various function status (output pre-set, -lock and standby) and a mini USB port for computer control. The units have high stability and low ripple and are protected against overcurrent (OCP), DC over-voltage (OVP) and over-temperature (OTP). It has output voltage ranging between 0V to 84V and outputs current rating ranging between 0A to 3A. LIZENZCODE EASYPS2000B The LIZENZCODE EASYPS2000B is a Software tool to control and monitor power supplies and electronic loads. This software tool is easy to handle with a minimum of setup required. The surface is completely in English. This tool is compatible with the use of PS2000B series power supplies. Features and Benefits Natural convection (no fan) Safety output sockets Efficiency 85% Operating frequency ranging between 45Hz and 65Hz Attractive flat desk-top housing Adjustable threshold current Output via safety (banana) sockets Operating temperature ranges between 0°C and 50°C Applications Industry and system applications Laboratories and test institutes Schools, university and laboratories Workshop and development Certifications EN60950 IEC 320-C14

Show Details

Ea Elektro-Automatik El 9000 T Series Electronic Dc Load, 0 → 600 W, 0 → 80 V, 0 → 45 A

Programmable Electronic DC loads EL 9000 T Series 400 W - 600 W The new EA-EL 9000 T series of compact electronic DC loads offers three tower models for the daily application in research laboratories and even schools. Lower power ratings allow for a multitude of test applications while being cost effective and space saving. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides interesting features. Such as a true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The colour TFT touch panel offers an intuitive manual operation, like it is prolific with smartphones or tablet computers. Response times during the control of the devices via analogue or digital interface improved by an ARM processor controlled hardware, compared to older electronic load series. Features and Benefits  Input Power Ratings: 0 W to 400 W, 0 W to 500 W, 0 W to 600 W  Input Voltages: 0 V to 80 V, 0 V to 200 V, 0 V to 500 V  Input Currents: 0 A to 8 A, 0 A to 18 A, 0 A to 45 A  Multilingual colour touch panel  True function generator  Adjustable protections: OVP, OCP, OPP  Operation modes: CV, CC, CP, CR  USB port as standard  Ethernet and analogue interface optional  SCPI and Modbus RTU supported  Control software (Windows)  LabView Vis

Show Details

Ea Elektro-Automatik El 9000 Dt Series Electronic Dc Load, 0 → 450 W, 0 → 360 V, 0 → 10 A

Programmable Electronic DC loads EL 9000 T Series The new EA-EL 9000 DT series of compact electronic DC loads, extends the current EA-EL 9000 T series by 10 models. It offers new voltage, current and power ratings for a multitude of applications for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides interesting features. Such as a true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The colour TFT touch panel offers an intuitive manual operation, like it is prolific with smartphones or tablet computers. Response times during the control of the devices via analogue or digital interface are improved by an ARM processor controlled hardware, compared to older electronic load series. Features and Benefits  Input Power Ratings: 0 to 400 W up to o to 1200 W  Input Voltages: 0 to 80 V up to 0 to 750 V  Input Currents: 0 to 5 A up to 0 to 60 A  Multilingual colour touch panel  User profiles, true function generator  Adjustable Protections: OVP, OCP, OPP  Operation Modes: CV, CC, CP, CR  Ethernet, analogue and USB port as standard  Carrying handle with tilt stand  SCPI and Modbus RTU supported  Control software (Windows)  LabView VIs

Show Details

Ea Elektro-Automatik El 9000 B Hp Series Electronic Dc Load, 0 → 2400 W, 0 → 80 V, 0 → 170 A

EL 9000 B HP Series The electronic DC loads series EA-EL 9000 B HP replace the current EA-EL 9000 HP series. They reduce the required unit height from 3U to 2U. Meaning, the steady power of 7200 W of a former EA-EL 9000 HP device can already be achieved in 6U of height where it required 9U before. The result is a space saving of 33% which allows for achieving even more power in a 19" cabinet. All models support the four common regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FPGA-based control circuit provides interesting features, such as a function generator with a table-based function for the simulation of nonlinear internal resistances. Features and Benefits  Power Ratings: 0 to 600 W up to 0 to 2400 W  Input Voltages: 0 to 80 V up to 0 to 750 V  Input Currents: Up to 170 A per unit  FPGA-based control circuit  Multilingual colour touch panel  User profiles, true function generator  Adjustable Protections: OVP, OCP, OPP  Operation Modes: CV, CC, CP, CR  Galvanically isolated interfaces (analogue and USB)  Master-slave bus for parallel connection  Optional: Digital, plug and play interfaces  SCPI and Modbus RTU supported  LabView VIs and remote control software (Windows)

Show Details

Ea Elektro-Automatik El 9000 Dt Series Electronic Dc Load, 0 → 600 W, 0 → 500 V, 0 → 16 A

Programmable Electronic DC loads EL 9000 T Series The new EA-EL 9000 DT series of compact electronic DC loads, extends the current EA-EL 9000 T series by 10 models. It offers new voltage, current and power ratings for a multitude of applications for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides interesting features. Such as a true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The colour TFT touch panel offers an intuitive manual operation, like it is prolific with smartphones or tablet computers. Response times during the control of the devices via analogue or digital interface are improved by an ARM processor controlled hardware, compared to older electronic load series. Features and Benefits  Input Power Ratings: 0 to 400 W up to o to 1200 W  Input Voltages: 0 to 80 V up to 0 to 750 V  Input Currents: 0 to 5 A up to 0 to 60 A  Multilingual colour touch panel  User profiles, true function generator  Adjustable Protections: OVP, OCP, OPP  Operation Modes: CV, CC, CP, CR  Ethernet, analogue and USB port as standard  Carrying handle with tilt stand  SCPI and Modbus RTU supported  Control software (Windows)  LabView VIs

Show Details

Ea Elektro-Automatik El 9000 T Series Electronic Dc Load, 0 → 500 W, 0 → 200 V, 0 → 18 A

Programmable Electronic DC loads EL 9000 T Series 400 W - 600 W The new EA-EL 9000 T series of compact electronic DC loads offers three tower models for the daily application in research laboratories and even schools. Lower power ratings allow for a multitude of test applications while being cost effective and space saving. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides interesting features. Such as a true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The colour TFT touch panel offers an intuitive manual operation, like it is prolific with smartphones or tablet computers. Response times during the control of the devices via analogue or digital interface improved by an ARM processor controlled hardware, compared to older electronic load series. Features and Benefits  Input Power Ratings: 0 W to 400 W, 0 W to 500 W, 0 W to 600 W  Input Voltages: 0 V to 80 V, 0 V to 200 V, 0 V to 500 V  Input Currents: 0 A to 8 A, 0 A to 18 A, 0 A to 45 A  Multilingual colour touch panel  True function generator  Adjustable protections: OVP, OCP, OPP  Operation modes: CV, CC, CP, CR  USB port as standard  Ethernet and analogue interface optional  SCPI and Modbus RTU supported  Control software (Windows)  LabView Vis

Show Details

Ea Elektro-Automatik El 9000 T Series Electronic Dc Load, 0 → 400 W, 0 → 500 V, 0 → 8 A

Programmable Electronic DC loads EL 9000 T Series 400 W - 600 W The new EA-EL 9000 T series of compact electronic DC loads offers three tower models for the daily application in research laboratories and even schools. Lower power ratings allow for a multitude of test applications while being cost effective and space saving. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides interesting features. Such as a true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The colour TFT touch panel offers an intuitive manual operation, like it is prolific with smartphones or tablet computers. Response times during the control of the devices via analogue or digital interface improved by an ARM processor controlled hardware, compared to older electronic load series. Features and Benefits  Input Power Ratings: 0 W to 400 W, 0 W to 500 W, 0 W to 600 W  Input Voltages: 0 V to 80 V, 0 V to 200 V, 0 V to 500 V  Input Currents: 0 A to 8 A, 0 A to 18 A, 0 A to 45 A  Multilingual colour touch panel  True function generator  Adjustable protections: OVP, OCP, OPP  Operation modes: CV, CC, CP, CR  USB port as standard  Ethernet and analogue interface optional  SCPI and Modbus RTU supported  Control software (Windows)  LabView Vis

Show Details

Ea Elektro-Automatik Ea-Psi 9000 T Series Digital Bench Power Supply, 0 → 80V, 40A, 1-Output, 1Kw

EA PSI 9000 T Series The microprocessor controlled laboratory power supplies of series EA-PSI 9000 T offer a user-friendly, interactive handling concept, along with a ex-tensive set of standard features, which can facilitate operating them. Configuration of output parameters, supervision features and other settings is smart and comfortable. The implemented supervision features for all output parameters can help to reduce test equipment and make it almost unnecessary to install external supervision hardware and software. Features and Benefits • Wide input voltage range 90...264 V with active PFC • High efficiency up to 92% • Output power ratings: 0...320 W up to 0...1500 W • Output voltages: 0...40 V up to 0...500 V • Output currents: 0...4 A up to 0...60 A • Flexible, power regulated output stage • Supervision (OVP, OCP, OPP) • Over-temperature protection (OT) • Intuitive touch panel with display for values, status and notifications • USB port as standard, Ethernet & analogue optional (all interfaces galvanically isolated) • Integrated function generator • Internal resistance simulation and regulation • 40 V models compliant to SELV (EN 60950) • SCPI command language supported • LabView VIs • Control software for Windows

Show Details

Ea Elektro-Automatik Ea-Psi 9000 T Series Digital Bench Power Supply, 0 → 40V, 40A, 1-Output, 640W

EA PSI 9000 T Series The microprocessor controlled laboratory power supplies of series EA-PSI 9000 T offer a user-friendly, interactive handling concept, along with a ex-tensive set of standard features, which can facilitate operating them. Configuration of output parameters, supervision features and other settings is smart and comfortable. The implemented supervision features for all output parameters can help to reduce test equipment and make it almost unnecessary to install external supervision hardware and software. Features and Benefits • Wide input voltage range 90...264 V with active PFC • High efficiency up to 92% • Output power ratings: 0...320 W up to 0...1500 W • Output voltages: 0...40 V up to 0...500 V • Output currents: 0...4 A up to 0...60 A • Flexible, power regulated output stage • Supervision (OVP, OCP, OPP) • Over-temperature protection (OT) • Intuitive touch panel with display for values, status and notifications • USB port as standard, Ethernet & analogue optional (all interfaces galvanically isolated) • Integrated function generator • Internal resistance simulation and regulation • 40 V models compliant to SELV (EN 60950) • SCPI command language supported • LabView VIs • Control software for Windows
