Vandal-resistant: Impact resistant Front protectionGold-plated silver contacts available for low voltages and currentsOptional illumination and laser markingsExcellent tactile feedbackLong service life: > 1 million cycles of operationStainless steel anodised aluminium or brass coloured switches16 mm, 19 mm or 22 mm mountingApplicationExposed public areas: e.g. ticketing and vending machinesIndustrial: Machinery and factory equipmentLifting and moving: Elevators and people moversBuilding management: Access control and security systemsAudio and video equipmentMedical equipmentFood Industry (corrosion and acid resistant versions available on request)

Robust mono-block Foolproof and fail-safe designVery low back panel depthAttractive, modern design Reliable and long service lifeClearly visible illumination

Illuminated Push Button Switch - EAO 31 Series The EAO 31 series of illuminated push button switches are suitable for use in many Human Machine Interface (HMI) panel mounting applications including Process Control, Panel Building, Machinery and Instrumentation. The illuminated push button switches are available in a choice of round (18mm diameter), square (18x18mm) or rectangular (18x24mm) bezels with snap action or low level switching elements with momentary or maintained switching actions.The snap action switching element is a self-cleaning, double-break, snap action system with solder terminals, while the low level switching element is designed for switching low power loads in electronic circuits ranging from 10μA at 100μV up to 100mA at 42Vac/dc, termination is via universal terminals that allow either direct soldering or PCB mounting.Illumination for the EAO 31 series of push button switches is via a T1 midget groove filament lamp or single chip LED with a voltage of between 6 and 48V. For supply voltages above 48V, it is necessary to use an external series resistor. All EAO 31 series of illuminated push button switches require a 16mm panel cut out and are suitable for panels with a thickness of between 1.5 and 6mm. They have a long life, short rebound time and a stable contact resistance. Various configurations available including low level or snap action elements, momentary or maintained switching actions and normally closed or normally open contactsRaised button profileSelf-extinguishing switch and actuator housing materialClass II compliantElectric strength 2500Vac 50Hz for 1 minute between all terminals and earth, as per IEC 60512-2-11

The EAO Universal Switch offers a offers a high quality Series 09 switches facilitate an almost unlimited combination of switching functions for wide ranging applications in vehicles. They have a modular, ergonomic design and an appealing, durable surface coating with fantastic haptics and tactile feedback. The basic versions include switches with white symbol illumination and the option of no, one or three red LED status indicators. The series 09 universal switch is available in two variants standard and dual contact. Ideal for safety relevant applicationsErgonomic, modular design with IP5K4 protectionIt has wide range of designsApplication specific configuration options

EAO Flushmount Pushbutton Switches, Series 61 The EAO Series 61 is a high quality, modular switch range that includes pushbuttons, indicators, selector switches, keylock switches and Emergency-stop. Available in raised or flush mount. Flush mounting (2mm front-of-panel protrusion), professional grade pushbutton switchesMomentary or maintained high quality with a good tactile feelFlush mounts into 24x24mm square, 25mm round and 24x30mm rectangular cut-outsSwitch rating 5A @ 250VacIP65 protectionLarge legend areaSelf cleaning snap action switching elementSuitable for use with T1 3/4 midget groove lamps or LED, see stock numbers 3607660 or 2829976 typicallyFor Contact Blocks see stock numbers 219-5447, 219-5453 or 219-5469Optional tool kit consisting of lens remover, contact block remover and mounting nut spanner is recommended, see stock no. 219-5481

The EAO Actuator is designed to provide exceptional reliability and user interaction in various applications. Engineered with precision, it features a front diameter of 30 mm combined with a robust mounting design, ensuring a seamless fit in panel installations. The actuator boasts a unique maintained - rest - maintained switching action, allowing for intuitive operation. Aesthetic black housing and white lever complement modern design trendsLightweight construction ensures easy installation and handlingSuitable for a wide range of demanding industrial applications

EAO Switch Key, For Use With 31 Series, 6g Weight - 31-989.311 Can't find that crucial part of your keyed switching system or want a failsafe option to keep you covered in emergencies? This spare key from EAO is just the thing. Having it on hand gives you peace of mind when it comes to operating keylock switches or their locked switch covers. Keylock switches are practical in situations that call for extra security, as they prevent anyone without a compatible key from being able to control an actuator. This makes them popular for boosting user safety in industrial areas where there's a risk of harm from moving machinery. Features & Benefits • Flat design gives key plenty of torque for easy turning• Robust metal construction for resistance to abrasion and corrosion• Light weight of 6g for ease of handling• Handy hole lets you suspend key for simple storage Applications • Transportation vehicles• Automation control• Medical devices What kind of keylocks can I use this product with? This product pairs easily with any keylock switch or cover in the 31 series, making it a versatile piece of kit.

EAO Series 61 Low Depth IP67 and IP69K Sealed Emergency Stop Switches New 16mm mounted 27mm / 40mm diameter head ’foolproof’ Emergency Stop with IP69K protection. Short back panel depth of 21.2mm and low front panel height of 27.5mm with optional dot illumination and up to 3 contacts. • Emergency stop with red release arrow markings • Precise foolproof trigger action• IP69K Sealed product• Illuminated and non illuminated versions• 27mm and 40mm Mushroom head • Compact size 16mm mounting• Reliable mono-block single piece contruction• Gold contacts, maximum voltage 50V• UL listed meet newstandard EN ISO 13850 Electrical Characteristics • Complies with latest emergency-stop switches standards comply EN IEC 60947-5-1, EN IEC 60947-5-5 (Emergency-stop), EN ISO13850 Environmental Conditions • Operating temperature -25°C to+55°C• Storage temperature -40°C to +80°C• Sealed at the front to IP67 and to IP69K covering submersion and resitance to jetwash

Robust mono-block Foolproof and fail-safe designVery low back panel depthAttractive, modern design Reliable and long service lifeClearly visible illumination

Vandal-resistant: Impact resistant Front protectionGold-plated silver contacts available for low voltages and currentsOptional illumination and laser markingsExcellent tactile feedbackLong service life: > 1 million cycles of operationStainless steel anodised aluminium or brass coloured switches16 mm, 19 mm or 22 mm mountingApplicationExposed public areas: e.g. ticketing and vending machinesIndustrial: Machinery and factory equipmentLifting and moving: Elevators and people moversBuilding management: Access control and security systemsAudio and video equipmentMedical equipmentFood Industry (corrosion and acid resistant versions available on request)

Lenses - EAO 31 Series A selection of round, square and rectangular lenses in various colours suitable for use with the EAO 31 Series of illuminated push button switches and indicators. Each EAO 31 Series lens has a flat flush profile and is manufactured from Polymethyl Methacrylate. Lenses can be engraved, hot stamped or used with film inserts, apart from the white lenses 248-5510 and 248-5504 which are not suitable for use with film insert labelling.

EAO Flushmount Pushbutton Switches, Series 61 The EAO Series 61 is a high quality, modular switch range that includes pushbuttons, indicators, selector switches, keylock switches and Emergency-stop. Available in raised or flush mount. Flush mounting (2mm front-of-panel protrusion), professional grade pushbutton switchesMomentary or maintained high quality with a good tactile feelFlush mounts into 24x24mm square, 25mm round and 24x30mm rectangular cut-outsSwitch rating 5A @ 250VacIP65 protectionLarge legend areaSelf cleaning snap action switching elementSuitable for use with T1 3/4 midget groove lamps or LED, see stock numbers 3607660 or 2829976 typicallyFor Contact Blocks see stock numbers 219-5447, 219-5453 or 219-5469Optional tool kit consisting of lens remover, contact block remover and mounting nut spanner is recommended, see stock no. 219-5481
