The Exsys Terminal Block Adapter is ideal for test purposes and various industrial applications, such as connecting individual cable harnesses with open cable ends. It features a 9 pin male connector and a 10 pin terminal block for flexible wiring connections. The adapter operates within a temperature range of 32°F to 131°F, making it suitable for a wide range of environments and applications. Easy installation of open cable endsPacked in reclose able bag

The Exsys Gigabit Ethernet PoE+ Splitter splits the signal of a PoE supplier into data and power supply and outputs both signals separately. This allows non PoE capable Ethernet end devices to be connected to a PoE switch or other PSE and use their power supply. It is compliant with the PoE+ standard IEEE 802.3at and provides a voltage of 12VDC with a power of max. 20W at the terminal block for feeding the end device. Thanks to the rugged metal housing and the extended operating temperature range from 40°C to 80°C, it is suitable for a wide range of applications even in harsh environments. No configuration and installation requiredLED status indicators for power supply and PoEIP40 ratingIncludes DIN Rail Kit and wall mounting bracket

The Exsys Media Converter provides reliable conversion between copper and fibre optic environments. It is compatible with 10/100/1000Base T with 60W PoE+ and dual mode 100/1000Base X SFP. The Ethernet port supports both half duplex and full duplex modes. Different types of optionally available SFP modules can be used depending on the requirements. Thanks to the rugged metal housing and the extended operating temperature range of 40°C to 75°C, it is suitable for a wide range of applications even in harsh environments. Power is supplied via the terminal block. Supports auto negotiation and half or full duplexPower booster generates PoE voltage range 46 to 57 VDCIP40 ratingIncludes DIN Rail Kit and wall mounting bracket

The Exsys Cable comes with A connector providing one high performance 16C550 type UART compatible RS 232 TTL/CMOS serial port. It is designed for PC, thin client or server to provide instant COM port expansion via the USB 1.1, 2.0 or 3.2 Gen1 Bus. It provides a USB to RS 232 port with 5V / 3.3 / 2.5V / 1.8V TTL/CMOS compatible logic levels. With the easy installation you don't need to open the computer system and install it when the system run. Data bits is 7 or 8Stop bits is 1 or 2Power from the USB bus

The Exsys D Type Adapters are designed to be installed in panels or enclosures with D type cut outs. These adapters are ideal for use as a service interface or for integrating digital equipment into professional audio systems. The adapters are panel mountable for secure installation and feature an operating temperature range from 32°F to 131°F, making them suitable for a variety of industrial and audio applications. Housing diameter is approximately 24 mmTwo threads for screw mountingUSB C to USB C adapters support fast charging up to 100 W

The Exsys Mounting Adapters can be installed in a panel or enclosure with a 22.3mm hole. The integrated thread allows them to be fixed directly to the panel, making them ideal for mounting digital equipment connections on a front panel for easy access and clarity. It features an operating temperature range from 32°F to 131°F, making them suitable for a variety of industrial and audio applications. Integrated thread with lock nutUSB C to USB C adapters support fast charging up to 100 W

The Exsys Rackmount Kit is installed in a standard 19" rack cabinet to enable to allow DIN Rail mounting of devices in the rack. It provides an easy way to neatly organize DIN Rail power supplies, media converters, USB hubs, PoE injectors, switches and other DIN Rail mounted devices in the server rack. Depth adjustable from 25 mm to 205 mmMaximum load capacity is 8 kg

The Exsys Gigabit Switch offers full gigabit performance on all ports despite its small external dimensions. Up to 30W are available on each of the four RJ45 ports for connecting PoE power devices such as IP cameras or IP phones. The fifth Gigabit port is an SFP slot. Matching SFP transceivers are available as accessories. Thanks to the robust metal housing and the extended operating temperature range from 40°C to 80°C, it is suitable for a variety of applications, even in harsh environments. Power is supplied via the terminal block and can also be redundant to reduce operational failures. Supports auto negotiation and 10/100Mbps half and full duplex and 1000Mbps full duplexSupports jumbo frames up to 9kBytesTerminal block for redundant DC inputIP40 rating

The Exsys Mounting Adapters can be installed in a panel or enclosure with a 22.3mm hole, respectively 25.3mm. The integrated thread allows them to be fixed directly to the panel, making them ideal for mounting digital equipment connections on a front panel for easy access and clarity. It features an operating temperature range from 32°F to 131°F, making them suitable for a variety of industrial and audio applications. Integrated thread with sealing ring and lock nutUSB C to USB C adapters support fast charging up to 100 W

The Exsys Terminal Block Adapter allow stripped wires to be connected without tools. They can be used for testing and various industrial applications, as well as for model making and other hobby applications. The adapter operates within a temperature range of 32°F to 131°F, making it suitable for a wide range of environments and applications. Push and release terminal allows easy tool free wiringNo soldering or screwdriver requiredEasy installation of open cable ends

The Exsys USB hub is used for up to ten end devices that can be installed on the wall or on a mounting rail. It ensures secure data transmission and a performance of up to 5Gbit/s. It is also equipped with 15KV ESD overvoltage protection. A maximum of 1.0A is available at nine USB ports via the external power supply, while up to 2.4A is available at one port. Redundant power supply when using TB and DC jack15KV ESD Surge protectionIncludes wall mount kit and DIN Rail KitAutomatic recognition the data transfer rate for the attached external devices

The Exsys USB hub comes in a metal housing with four USB 3.2 Gen 1 outputs can be installed on the wall or also on a carrier rail. All ports are located on the top, offering great flexibility for installation in a case or cabinet, for example. In addition, it is equipped with 15KV ESD surge protection. Up to 1A can be provided to each port via the external power supply. Redundant power supply when using TB and DC jack15KV ESD Surge protectionIncludes wall mount kit and DIN Rail KitAutomatic recognition the data transfer rate for the attached external devices
