Fibox ARCA Enclosure Accessories Inner Door Quick and easy to installNo tools or screws requiredLockable for added security DIN Rail Frame Set Quick and easy to installComponents can be assembled on the frame outside the cabinetIncludes DIN rail frame, front plate, corner brackets and screws Wall Mounting Lug Set Provides space for wiringAvailable in 2 depths, 10mm & 40mmMade from stainless steel Mounting Plates Perforated, unperforated & multi-perforatedGalvanized steel, thickness 2 mm Lock Inserts 869-7996 locking insert double-bit 3 mm869-8009 for 1242E system869-8002 for V2432E system869-8006 for 455E system869-8015 for 405E system

CARDMASTER Polycarbonate Enclosures - IP65 The Cardmaster range of enclosures from Fibox are ideal for packaging instrumentation, measurement, monitoring and process control equipment. The box provides two compartments, one for circuit board insertion and the other for terminals and wiring. RoHS Compliant and Halogen FreeGood chemical resistanceElectrically insulatedTemperature range -40 to +80 °CFlammability rating UL 94-5VImpact resistance IK07 (side surface), IK08 (front surface)

The Fibox is a Inner door set with no Electrical insulation Height x Width x Depth - 280 x 280 x 30mm

FIBOX ABS Enclosures FIBOX ABS enclosures utilise world-class injection moulding technology. They are designed to house and protect electrical and electronic components in the most demanding applications. Features and Benefits • Ideal for housing electrical and electronic components• Lid features a recess which is ideal for membrane keypads• IP66/67 rating and comply with EN60529• Temperature range: -40 °C to +80 °C short term, -40 °C to +60 °C for continuous use• Dimensions: 65 x 50 x 45 mm to 300 x 230 x 110 mm• RAL 7035 (IP) Ingress Protection and what it means? IP rating classifies the degrees of protection provided against the intrusion of solid objects (including body parts like hands and fingers), dust, accidental contact, and water in electrical enclosures. FAQ’s Can the box be used outside?Yes, ABS series enclosures have an IP66/67 ratingAre they mountable?Yes, they are suitable for wall mounting or portable applicationsWhat is supplied?Enclosure, Base with screws for mounting plate/DIN-rail, Cover with PUR gasket and Stainless steel cover screws.

Fibox MNX Enclosures The MNX range of enclosures are a perfect choice to housing electronic systems and components. These polycarbonate light grey (RAL 7035) enclosures have an IP66 & IP67 certified protection allowing you to work safely and making the enclosures reliable under difficult working environmental conditions. These MNX series enclosures are available in vary of different sizes to accommodate your everyday applications. Features & Benefits • Light Grey finish• Electrical Insulated• IP66/67 and IK08 protection • Temperature -40°C to +80°C • Single door • Installation position - Upright on a wall, pole or frame• Flammability Rating - UL 746C 5"• UV resistance - UL508 (IP) Ingress Protection IP rating classifies the degrees of protection provided against the intrusion of solid objects (including body parts like hands and fingers), dust, accidental contact, and water in electrical enclosures.IP66 - Dust and water protectionIP67 - immersed in water under defined conditions of pressure and time (up to 1m of submersion) (IK) Impact Protection The IK rating reflects degrees of protection provided by enclosures for electrical equipment against external mechanical impacts. For more information please click on The Selection Process of an Enclosure.IK08 - Protected against 5 joules impact. Equivalent to impact of 1.7 kg mass dropped from 300 mm above impacted surface.

The Fibox is a Cabinet which include Cabinet base, door with PUR gasket, mounting plate, screws for mounting plate, 3mm double bit lock(s) with key, S versions with swing handle 2-point locking system, Door guide Height x Width x Depth - 400 x 400 x 210mmGasket material - Polyurethane

FIBOX Polycarbonate EK Series Enclosures Fibox EK series enclosure, ideal for housing electrical equipment in either a single enclosure or a flexible modular system. These polycarbonate enclosures are impact resistant, self-extinguishing and resistant to most acids and alkalis. The temperature range of the enclosure material is -40°C to +120°C, (+80°C for continuous use) and the flammability rating is UL94-V2. Features and Benefits • Excellent choice to house electronic and electrical components• Available with transparent or grey cover• IP 66/67 (IP) Ingress Protection and what it means? IP rating classifies the degrees of protection provided against the intrusion of solid objects (including body parts like hands and fingers), dust, accidental contact, and water in electrical enclosures. FAQ’s Can the box be used outside?• Yes, EK series enclosures have IP66 / IP67 ratingCan you purchase mounting plates seperately• EK series mounting plates are supplied with this product but are also available separatelyWhat is supplied?• Enclosure, lid and screws, PUR/EPDM gasket and screws

FIBOX ABS Enclosures FIBOX ABS enclosures utilise world-class injection moulding technology. They are designed to house and protect electrical and electronic components in the most demanding applications. Features and Benefits • Ideal for housing electrical and electronic components• Lid features a recess which is ideal for membrane keypads• IP66/67 rating and comply with EN60529• Temperature range: -40 °C to +80 °C short term, -40 °C to +60 °C for continuous use• Dimensions: 65 x 50 x 45 mm to 300 x 230 x 110 mm• RAL 7035 (IP) Ingress Protection and what it means? IP rating classifies the degrees of protection provided against the intrusion of solid objects (including body parts like hands and fingers), dust, accidental contact, and water in electrical enclosures. FAQ’s Can the box be used outside?Yes, ABS series enclosures have an IP66/67 ratingAre they mountable?Yes, they are suitable for wall mounting or portable applicationsWhat is supplied?Enclosure, Base with screws for mounting plate/DIN-rail, Cover with PUR gasket and Stainless steel cover screws.

The Fibox Modular component enclosure IP65 has insulated terminals, cover for unused modules, plastic cap for screws with AC 400V / DC 1000V rated voltage and polycarbonate cover material also transparent cover colour. Dimensions (H x W x D) 664 x 319 x 144 mmNumber of modules/rows 48/4Impact Resistance IK08Temperature -25 to +60 °CAcrylonitrile acrylic styrene baseRAL 7035 base colour

Polycarbonate housing, MNX range, IP67 High impact-resistant enclosure made from fibreglass-reinforced polycarbonateFor accommodating electronic systems and componentsUnique configuration of mounting points facilitates three different attachment methodsMoulded guides for quick installation of printed circuit boardsCovers have lightweight recessed central section for accommodating membrane keyboardsHalogen-freeFlame-retardant UL94-V2Colour: grey (RAL7035)Protection class IP67Operating temperature range: -40 °C → +80 °CGood chemical-resistanceChoice of grey and transparent coversAll base sections and covers are completely interchangeableMounting plates, wall mounting bracket and cover hinges can be ordered separately

Base, terminal compartment cover with EPDM gasket and screws for mounting plate/DIN-rail. -3 and -L3 versions: Transparent cover with PUR gasket, hinges, locking devices, FC version: Closed PC frame front plate with PUR gasket and cover screws. CARDMASTER range is ideal for packaging instrumentation, measurement, monitoring and process control equipment. It provides two compartments - one for circuit boards and sensors with slots for printed circuit board insertion, and another one for terminal and wiring. All sizes are available in both polycarbonate and ABS.

Polycarbonate or ABS IP 66//67 Euronorm II series cases Euronord range of enclosures from Fibox are designed to house DIN Rail-mounted terminal blocks and various types of sensors. The outer surface is free of ’gate marks’ creating a smooth area for labels, decals or screen printing. Cover screws fully tighten in 4 revolutions, are held captive, but are still removable. The enclosure meets IP66/67 with the installation of a Polyurethane gasket. Features and Benefits The bottom of the case has several attachment humps for mounting internal equipment.The stainless steel fastening screws and polyurethane seal protect the housing.The polyurethane enclosure in the version with a grey or transparent front cover are intended for harsh environments.ABS cases represent a more economical alternative for less demanding interior environments.Applications: terminal blocks, electrical devices, electronics and industrial electronics. Typical Applications Test and Measurement Instrumentation Medical Tools Transportation Equipment Industrial Controls Lighting Applications
