55 Series Relay Accessories Isolation Coil To Contact 2000 V Note The colour of RS stock 666-7987 is Black

58 Series Finder 58 series relay interface modules are an ideal interface for PLC and electronic systems. Features and Benefits 4PCO contact configurationContact resistance: 50mΩOperating temperature range -40 to + 70°CDimensions: H76mm, W27mm, D73mmMechanical life: DC versions; 50 x 106 operations, AC versions; 20 x 106 operations Replacement relays stock no. 385-913 etc are available (Finder 55 Series), and should be selected such that the coil voltage matches the original type

4C Series with Instant Eject Relays Ideal interface for PLC and electronic systemsInstant ejection of relay using plastic retaining clipSupply status indication and coil suppression module as standard440Vac switching voltageWidth: 15.8mmContact material: AgNi

The Finder Power relay has high DC load switching capability. It has cadmium free contact material. Reinforced insulation between coil and contacts according to EN 60335-1, with 6 mm clearance & 8 mm creep age distance. DC coilsPlug-in mounting

The Finder Miniature PCB Relay has cadmium-free contact material. It meets EN 60335-1 glow wire requirements. 35 mm rail mounting with screw, screw less or push-in terminals. Mounted on sockets ≤ 10 A8 mm creep age and clearance

38 Series - Screw and Screwless Terminals Ideal interface for PLC and electronic systemsDimensions: H89.7mm x W14mm x D77.1mmAgNi contactsOperating temperature range: -40°C to +55°C

55 Series Relay The Finder 55 series miniature relays for general purpose applications. Features & Benefits Test button and mechanical indicator Ac/dc coils Cadmium free contacts Dimensions: H 39.5, W 20.6, D 27.5 Mechanical life: AC; 2 x 107, DC; 5 x 107 Operating temperature range -40 to +85°C Wide range of accessories also available Silver-Nickel Cadmium free contacts Dust-proof RT I standard protection rating For use with 94 series sockets

The Finder Three-phase voltage monitoring relay is a thermistor temperature sensing relay for industrial application. Temperature and short circuit detection with PTC. Fault memory selectableLED status indication

Finder Series 55 Relay, 4PDT Contact Configuration, 24V DC Coil Voltage - 55.34.9.024.0094 This relay plays a vital role in controlling various automation processes within industries like electronics and mechanical engineering. With a 24V DC operating voltage, it ensures effective performance in various environments. Features & Benefits • 24V DC coil voltage for efficient operation • High voltage isolation of 4kV for added safety • Single coil design for simplified control configurations • 4PDT contact configuration for versatile switching functions • 600Ω coil resistance for optimised energy use • Capable of handling a switching current of 7A Applications • Used in control panels for industrial automation systems • Ideal for interfacing electronic devices in machinery • Utilised in safety relays for automation tasks • Employed in control circuits for HVAC systems • Suitable for electrical installations needing secure switching What is the maximum voltage the relay can isolate? The relay can isolate up to 4kV, ensuring a high level of safety. How should this component be mounted in an application? This model is designed for plug-in mounting, which simplifies installation. Can it handle multiple loads simultaneously? With its 4PDT configuration, it can effectively manage multiple loads. What type of environments is it suitable for? This relay is designed for industrial settings where control and switching reliability are essential. What maintenance does this device require? Regular checks for proper operation and contact integrity are recommended for optimal performance.

Solid State Relay 5A - 77 Series High switching speed, high endurance, low control powerSpark and bounce-free switchingZero Cross versions are for applications such as: Lamp inrush current reduction (CFL - Compact Fluorescent energy-saving Lamps and similar); Heater Control; Solenoid, contactor driverRandom Switch-on versions are for applications such as: Fine Controls involving shorter time (especially motor control); AC supply phase different from AC output phase; 3-phase general purpose

The Finder Power relay for precise relay control in diverse application. Featuring advanced technology, it ensures accurate signal detection and seamless relay operation, its compact design allows for easy integration into control system, and its reliability makes it a trusted choice for industrial settings. 16 A Power relaySELV coil-contact separator optionCadmium free contact material optionsSockets and accessories

55 Series Relay Accessories Finder 55 series relay accessories including sockets, coil indication and EMC suppression modules Features and Benefits Depending on module selected, they can provide; Suppression of coil back emf on switch-off LED indication to show when the coil in energized Protection against reverse polarity applied across the coil terminals By-pass of troublesome leakage currents in the coil circuit
