GIC Liquid Level Controllers Fully Automatic operation enabling both draining and filling at the same time with a single device Protects submersible pumps against dry running and prevents overfilling Enables maximum utilization of incoming liquid supply Specially designed corrosion and shock resistant sensors to ensure problem free operation Features and Benefits Includes provision for Manual start Adjustable sensitivity level from 1k to 200k Ohm Adjustable reaction timer from 0.1s to 10s &#149; This Series 44 Level Controller can be used with a GIC level sensor such as <a href="/web/p/products/1828937">182-8937</a>

GIC Signal Transducer 24 Vdc Signal transducer with configurable input/output configuration that can be selected via DIP switch combinations. <BR/>Includes choice of 16 analogue configurations with 3-way 3.75 kV galvanic isolation and less than 100 ms response time. <BR/>Also features adjustable gain and offset. Slim 22.5 mm wide design<BR/>Fast response time<BR/>Easily configurable analog input/output

GIC Liquid Level Controllers Fully Automatic operation enabling both draining and filling at the same time with a single device Protects submersible pumps against dry running and prevents overfilling Enables maximum utilization of incoming liquid supply Specially designed corrosion and shock resistant sensors to ensure problem free operation Features and Benefits Includes provision for Manual start Adjustable sensitivity level from 1k to 200k Ohm Adjustable reaction timer from 0.1s to 10s &#149; This Series 44 Level Controller can be used with a GIC level sensor such as <a href="/web/p/products/1828937">182-8937</a>

GIC Level Controllers The GIC 44 series liquid level controller is used to detect the liquid level in a tank where liquids are electrically conducting and device controls the relay output. It has a 240VAC supply voltage and +/-20% accuracy. The mode of operation can be filling and draining, filling only one tank with dual-level monitoring, filling only one tank with single-level monitoring, draining only one tank with dual-level monitoring and draining only one tank with single-level monitoring. Features and Benefits Adjustable reaction timer from 0.1 second to 10 seconds<BR/>Fully automatic operation enabling both draining and filling at the same time with a single device <BR/>Protects submersible pumps against dry running and prevents overfilling<BR/>Enables maximum utilization of incoming liquid supply<BR/>Specially designed corrosion and shock-resistant sensors to ensure problem free operation<BR/>Includes provision for manual start adjustable sensitivity level between 1kohm and 200kohm<BR/>Power consumption is 3VA<BR/>2m enclosure with Din rail mount<BR/>Adjustable sensitivity of liquid between 1kohm and 200kohm Certifications CE certified<BR/>IEC 61000-3-2<BR/>IEC 61000-4-2<BR/>IEC 61000-4-3<BR/>IEC 61000-4-4<BR/>IEC 61000-4-5<BR/>IEC 61000-4-6<BR/>IEC 61000-4-11<BR/>CISPR 14-1<BR/>IEC 60947-5-1<BR/>IEC 61010-1<BR/>UL 508 listed<BR/>IP20 rated Compatible Sensors • This Level Controller can be used with a GIC level sensor such as <a href="/web/p/products/1828937">182-8937</a>

GIC Phase Failure & Neutral Loss Detection Monitoring Relays Supply monitoring relays with combined phase failure and neutral loss detection. Phase loss failure detection<BR/>Neutral loss detection<BR/>Phase reverse detection<BR/>Phase asymmetry<BR/>Adjustable over & under voltage trip level<BR/>LED indication for all failure conditions<BR/>Automatic recovery on fault removal

Digital Time Delay Relay Flexible functionality with wide range applications<BR/>Tamper proof with key lock function<BR/>Selectable up/down counting modes - to show elapsed/remaining time<BR/>3 Digit LCD for preset time and run time<BR/>Clear LED indication of relay status

GIC Multi-function Timer Relay The GIC multi-function timer relay is a compact digital equipment with high precision. It performs different delay functions like cyclic off/ on, cyclic on/ off, interval, ON delay, one-shot output, signal OFF delay, signal off/ on, and signal on/ off in the range of 0.1 seconds to 999 hours. This timer relay has a wide range of programming features that provide the user with a comprehensive range of timing functions to suit a wide variety of applications. Due to the highly versatile voltage range, this timer relay can be installed into new and existing applications in an extremely hassle free way. Its low cost and high performance make it ideal for a wide range of applications in process control environments. Features and Benefits Fine adjustment of selected time range<BR/>1C/O SPDT contact configuration with relay output 2ADC, 3AAC<BR/>Supply voltage ranges from 24VAC to 240VAC and 24VDC to 240VDC<BR/>17 selectable functions available<BR/>Covers a wide AC and DC voltage range for added installation flexibility<BR/>Flexible functionality with wide range applications<BR/>Selectable up/down counting modes to show elapsed/remaining time<BR/>3 digit LCD for pre-set time and running time<BR/>Option to select up/down counting<BR/>Tamper proof with key lock function<BR/>All settings accomplished with only two keys<BR/>Up to 999 hours<BR/>Compact 17.5mm<BR/>Self-extinguishing housing<BR/>Clear LED indication of relay status Applications Textiles<BR/>Chemical industries<BR/>Mining<BR/>Irrigation<BR/>Raw material handling<BR/>Food and beverages<BR/>Industrial process control Certifications CE certified<BR/>IP20 rating for terminals<BR/>IP30 rating for enclosure<BR/>IP50 rated for front panel<BR/>CE certified<BR/>IEC 61000-3-2<BR/>IEC 61000-4-2<BR/>IEC 61000-4-4<BR/>IEC 61000-4-5<BR/>IEC 61000-4-11<BR/>CISPR 14-1

Digital Time Delay Relay Flexible functionality with wide range applications<BR/>Tamper proof with key lock function<BR/>Selectable up/down counting modes - to show elapsed/remaining time<BR/>3 Digit LCD for preset time and run time<BR/>Clear LED indication of relay status

GIC Multi-function Timer Relay The GIC multi-function timer relay is a compact digital equipment with high precision. It performs different delay functions like cyclic off/ on, cyclic on/ off, interval, ON delay, one-shot output, signal OFF delay, signal off/ on, and signal on/ off in the range of 0.1 seconds to 999 hours. This timer relay has a wide range of programming features that provide the user with a comprehensive range of timing functions to suit a wide variety of applications. Due to the highly versatile voltage range, this timer relay can be installed into new and existing applications in an extremely hassle free way. Its low cost and high performance make it ideal for a wide range of applications in process control environments. Features and Benefits Fine adjustment of selected time range<BR/>1C/O SPDT contact configuration with relay output 8A<BR/>Supply voltage ranges from 24VAC to 240VAC and 24VDC to 240VDC<BR/>8 selectable functions available<BR/>Covers a wide AC and DC voltage range for added installation flexibility<BR/>Flexible functionality with wide range applications<BR/>Selectable up/down counting modes to show elapsed/remaining time<BR/>3 digit LCD for pre-set time and running time<BR/>Option to select up/down counting<BR/>Tamper proof with key lock function<BR/>All settings accomplished with only two keys<BR/>Compact 17.5mm<BR/>Self-extinguishing housing<BR/>Clear LED indication of relay status Applications Textiles<BR/>Chemical industries<BR/>Mining<BR/>Irrigation<BR/>Raw material handling<BR/>Food and beverages<BR/>Industrial process control Certifications CE certified<BR/>IP20 rating for terminals<BR/>IP30 rating for enclosure<BR/>IP50 rated for front panel<BR/>CE certified<BR/>IEC 61000-3-2<BR/>IEC 61000-4-2<BR/>IEC 61000-4-4<BR/>IEC 61000-4-5<BR/>IEC 61000-4-11<BR/>CISPR 14-1

GIC Multifunction Timer Relay Micon 175 Series Asymmetric & Multifunction Timers provide the user with a comprehensive range of timing functions to suit a wide variety of applications. Thanks to the highly versatile Timer voltage range the Micon 175 series can be installed into new and existing applications hassle free 1 C/O contact configuration<BR/>Signal & non-signal based modes available<BR/>Covers a wide AC & DC Voltage range for added installation flexibility<BR/>0.1 - 100 Hour time range available with a maximum reset time of 200 ms<BR/>Relay & power status shown via Tri-Colour LED indication<BR/>ON time & OFF time settings can be indipendantly set for further customisation for your application<BR/>Low power consumption helps to keep running costs down<BR/>IP40 rated enclosure with IP20 rated terminals <B>Multifunction Timer functions include:</B><BR/><BR/>Signal ON Delay<BR/>Cyclic ON/OFF<BR/>Cyclic OFF/ON<BR/>Signal OFF Delay<BR/>Signal OFF/ON<BR/>Accumulative Delay on Signal<BR/>Impulse ON/OFF<BR/>Leading Edge Impulse<BR/>Trailing edge Impulse<BR/>Leading Edge Bi-Stable

GIC Multi-function Timer Relay The GIC Micon 175 Series multi-function timer relay is solid-state, compact equipment with high precision. It performs different delay functions like asymmetric off/on and asymmetric on/off in the range of 0.1 seconds to 100 hours. This timer relay has a wide range of programming features that provides the user with a comprehensive range of timing functions to suit a wide variety of applications. Due to the highly versatile voltage range, this timer relay can be installed into new and existing applications in an extremely hassle free way. Its affordability, optimum space management, and high performance make it ideal for a wide range of applications in process control environments. Features and Benefits Fine adjustment of the selected time range<BR/>SPDT 1C/O contact configuration with relay output of 5A at 24VDC<BR/>The supply voltage ranges from 12VAC/VDC to 240VAC/VDC for added flexibility<BR/>Reset time of 200ms<BR/>Screw terminal type<BR/>2 different functions available<BR/>LED Indications for power and relay status<BR/>On time and off time settings can be independently set for further customisation for your application<BR/>Low power consumption helps to keep running costs down Applications Textiles<BR/>Chemical industries<BR/>Mining<BR/>Irrigation<BR/>Raw material handling<BR/>Food and beverages<BR/>Industrial process control Certifications UL approved<BR/>IP20 rated terminals<BR/>IP30 rated enclosure<BR/>IP40 rated front side<BR/>CE certified<BR/>cULus certified<BR/>IEC 61000-3-2<BR/>ESD IEC 61000-4-2<BR/>IEC 61000-4-3<BR/>IEC 61000-4-4<BR/>IEC 61000-4-5<BR/>IEC 61000-4-6<BR/>IEC 61000-4-11<BR/>IEC 61000-4-29<BR/>CISPR 14-1<BR/>IEC 60068-2-1<BR/>IEC 60068-2-2<BR/>IEC 60068-2-6<BR/>IEC 60068-2-27

GIC Multi-function Timer Relay The GIC multi-function timer relay is solid-state, compact equipment with high precision. It performs different delay functions like accumulative delay on signal, cyclic off/ on, impulse on/ off, leading-edge bi-stable, leading-edge impulse, signal off/ on, signal on/ OFF delay, and trailing edge impulse off in the range of 0.1 seconds to 100 hours. This relay has a wide range of programming features that provide the user with a comprehensive range of timing functions to suit a wide variety of applications. Due to the highly versatile voltage range, this timer relay can be installed into new and existing applications in an extremely hassle free way. Its affordability and high performance make it ideal for a wide range of applications in process control environments. Features and Benefits Fine adjustment of the selected time range<BR/>1C/O SPDT contact configuration with relay output 8A<BR/>Multi-voltage range is 12VAC to 240VAC and 12VDC to 240VDC<BR/>Covers a wide AC and DC voltage range for added installation flexibility<BR/>Time delay is reset of 200ms<BR/>10 different functions available<BR/>LED Indications for power and relay status<BR/>ON time and OFF time settings can be independently set for further customisation for your application<BR/>Low power consumption helps to keep running costs down Applications Textiles<BR/>Chemical industries<BR/>Mining<BR/>Irrigation<BR/>Raw material handling<BR/>Food and beverages<BR/>Industrial process control Certifications UL approved<BR/>IP20 rated<BR/>CE certified<BR/>cULus approved<BR/>IEC 61000-3-2<BR/>ESD IEC 61000-4-2<BR/>IEC 61000-4-3<BR/>IEC 61000-4-4<BR/>IEC 61000-4-5<BR/>IEC 61000-4-6<BR/>IEC 61000-4-11<BR/>IEC 61000-4-29<BR/>CISPR 14-1<BR/>IEC 60068-2-1<BR/>IEC 60068-2-2<BR/>IEC 60068-2-6<BR/>IEC 60068-2-27
