Absolute Encoder AC36 - 10mm Shaft 12 bit resolutionSSI gray interfaceOptical encoder with a true geared multiturnOperating temperature: -40 to 100°CConnection: Cable radial 1.5m

The Time Counters is a compact and high-quality counter ideal for various applications. With features like high shock resistance, low power consumption, and miniature dimensions, it offers reliable performance in a small package. Suitable for PCB mounting for easy installationWide operating temperature range from -10 to +60°C for versatile useResidual ripple less than 1% for precise countingShock stability of over 3500 m/s ensures durability

The Hengstler 7 digits DC version mini h time counters is has electrical connections in standard grid. Machine-solderable and washable versions are also available. High shock resistanceMiniature dimensionsLow power consumption

Motor Feedback AD36 - 8mm Shaft 13 or 17 bit resolutionSSI Gray + Quadrature 1Vp-pOptical encoder with a true geared multiturnOperating temperature: -40 to 120°CPCB connector 12 pole radial 0,5m cable

Multifunctional Counter - Tico 774 Universally applicable as tachometer, timer, shift-counter and batch-counterSimplified handlingSeparate preset adjustment (signal 1, trail preset, range or limit value)Versatile and easy to program, 4 keys to directly address presets, prescaler and seperate totalizerClearly readable display with large digitsDisplay and preset range: -999 999 to +999 999Alarm signal: display flashes when preset 0, 1 or 2 are activeInput frequency up to 60 kHzRelay outputs: 250Vac / 30Vdc / 5AEasy installation due to pluggable terminals3 PresetsIP65 protection (front panel) Typical Applications: Time controllingPosition indicationBatch countingCutting to lengthRotation speed controlling

RI 58-D series incremental hollow shaft encoders Encoders with diameter of 58 mm, for direct mounting at end of motor arm.Reduced housing depth for highly compact mounting.Simplicity and safety of coupling to the shaft thanks to the use of a concentric clip.High precision of output signals for use in the most demanding applications.Use of Opto-Asic technology for greater reliability and protection against electrical and electromagnetic interference.Integrated control circuitry with alarm output.

RI58-0 10mm Shaft Low cost, high specification

Hengstler 0732030, MULTIFUNCTION C/LED/12-24VDC/2V/2R

RI38 Universal Mounting Low torque/High efficiency with ball bearings

The Hengstler 7 digits time counter suitable for both AC and DC operations and DIN rail attachment. Low-costHighly legible displaySimple installationNo reset

RI38 Universal Mounting Low torque/High efficiency with ball bearings

Hengstler Digital Counter The Hengstler TICO 731 series digital impulse counter is a programmable, panel mount device. This counter has a voltage input and transistor output. It also has an 8-digit LCD display. It is lithium battery operated. This counter is simple to program, choose from negative or positive edge-triggered count inputs with low count (30Hz) or high count (7.5kHz) input speeds. The counter can be reset externally or by pressing the front reset button that can also disabled via a bridge wire. Features and Benefits Units display rate per minute of pulses receivedResettableProgrammable KeylockFront dimensions is 48mm x 24mmPlug-in screw terminal connectionOperating temperature ranges between 0°C and 50°C Applications Industrial counting applicationsControl and monitoring systemsManufacturing assembly line Certifications IP54 ratedEN 61010-1EN 50178, protective system II
