JST WC-122 Hand Crimping Tool for SHF Crimp Terminals Importance of a High-Quality Crimp When a crimping tool is used on a terminal, two crimps take place at the same time. One is the electrical connection between conductor and terminal. The other is the insulation crimp which provides strain relief against vibration and tension. It is important that the electrical connection is gas tight without any voids between the wire strands and the terminal. If there any voids present, then corrosion can occur causing resistance and excessive heat which damages the electrical connection. Using a good quality crimping tool will ensure that a full, gas tight crimp is produced preventing future deterioration of the electrical connection and insulation breakage JST WC-122 Hand Crimping Tool - Overview From JST a durable, reliable and easy to use hand operated crimping tool made from high quality materials. This crimp tool consists of two ergonomically designed handles with a soft grip for comfortable use, a ratchet mechanism, precision ground die assembly, locator and wire stop. The die assembly has three cavities for wire sizes 22 AWG, 24 AWG and 26/28 AWG. The pre-set load of the tool can be easily adjusted. Ratchet Mechanism The ratchet is pre-set to a specific force and remains locked until the handles of the tool are fully closed and the dies are bottomed. The handles cannot be opened until a full crimping cycle is achieved therefore preventing partial crimps. Once the cycle is complete the handles will re-open. The ratchet also enables the operator to repeatedly produce consistent, high-quality crimps. If jamming or terminal misplacement occurs the handles can be easily opened by pushing a ratchet release lever Locator and Wire Stop This hand crimp tool features a user friendly flap style locator which ensures the terminal is accurately positioned during the crimping process. The locator is simply flipped open allowing the terminal to be inserted into the correct profile. Once the terminal is inserted the locator is flipped back into place and the crimp tool is closed until the first ratchet. The pre-stripped wire is then inserted into the terminal until it butts against the wire stop, the hand tool can then be closed until the ratchet releases. The locator is opened and the full crimped terminal can then be carefully removed Key Features and Benefits &#149; Durable and easy to use<BR/>&#149; Precision ground dies<BR/>&#149; Ratchet mechanism ensures full crimp cycle is achieved<BR/>&#149; Ratchet release latch<BR/>&#149; Locator and wire stop for accurate terminal positioning<BR/>&#149; Easy re-adjustment of load<BR/>&#149; Ergonomically designed soft grip handles for comfortable use Questions and Answers What Terminals can this Crimping Tool be used with?<BR/>This hand crimping tool is designed for crimping JST loose piece SHF-001T-0 un-insulated crimp terminals that accept a wire size range from 28 AWG to 22 AWG onto cable

VL Series Tooling Tooling, Crimp and Extraction for Crimp Contacts: SVF-42T-P2.0, SVM-42T-P2.0, SVF/M-61T-P2.0, SVF/M-81T-P2.0.

JST EL Series Tooling

JST WC-240 Hand Crimping Tool for SPH Crimp Terminals Importance of a High-Quality Crimp When a crimping tool is used on a terminal, two crimps take place at the same time. One is the electrical connection between conductor and terminal. The other is the insulation crimp which provides strain relief against vibration and tension. It is important that the electrical connection is gas tight without any voids between the wire strands and the terminal. If there any voids present, then corrosion can occur causing resistance and excessive heat which damages the electrical connection. Using a good quality crimping tool will ensure that a full, gas tight crimp is produced preventing future deterioration of the electrical connection and insulation breakage JST WC-240 Hand Crimping Tool - Overview From JST a durable, reliable and easy to use hand operated crimping tool made from high quality materials. This crimp tool consists of two ergonomically designed handles with a soft grip for comfortable use, a ratchet mechanism, precision ground die assembly, locator and wire stop. The die assembly has three cavities for wire sizes 24 AWG, 26 AWG and 28/30 AWG. The pre-set load of the tool can be easily adjusted. Ratchet Mechanism The ratchet is pre-set to a specific force and remains locked until the handles of the tool are fully closed and the dies are bottomed. The handles cannot be opened until a full crimping cycle is achieved therefore preventing partial crimps. Once the cycle is complete the handles will re-open. The ratchet also enables the operator to repeatedly produce consistent, high-quality crimps. If jamming or terminal misplacement occurs the handles can be easily opened by pushing a ratchet release lever Locator and Wire Stop This hand crimp tool features a user friendly flap style locator which ensures the terminal is accurately positioned during the crimping process. The locator is simply flipped open allowing the terminal to be inserted into the correct profile. Once the terminal is inserted the locator is flipped back into place and the crimp tool is closed until the first ratchet. The pre-stripped wire is then inserted into the terminal until it butts against the wire stop, the hand tool can then be closed until the ratchet releases. The locator is opened and the full crimped terminal can then be carefully removed Key Features and Benefits &#149; Durable and easy to use<BR/>&#149; Precision ground dies<BR/>&#149; Ratchet mechanism ensures full crimp cycle is achieved<BR/>&#149; Ratchet release latch<BR/>&#149; Locator and wire stop for accurate terminal positioning<BR/>&#149; Easy re-adjustment of load<BR/>&#149; Ergonomically designed soft grip handles for comfortable use Questions and Answers What Terminals can this Crimping Tool be used with?<BR/>This hand crimping tool is designed for crimping JST loose piece SPH-002T-P05S un-insulated crimp terminals that accept a wire size range from 30 AWG to 24 AWG onto cable

BH Series Crimp Contact

The low profile type connector with height of 3.0mm is designed for connection to stroboscope flash and realized space saving Contact lance<BR/>countermeasure for inverse insertion and locking feature

The YLN connector adds variation in shape to the existing Colour variations of the YL connector in order to improve identification of connectors. Moreover, this connector has a mechanism to prevent incomplete mating by utilizing the inertia force generated when the plug and receptacle are mated and therefore, ensures complete mating. Design to Prevent incidental mating with the YL Connector<BR/>Inertial force mechanism<BR/>interchangeability<BR/>Finger friendly design

The Jst Manufacturing , J2000 series is a header , side entry type. It is centre locking type with double row. Double-row type<BR/>2.5 mm pitch

The Jst Manufacturing , J2000 series , tab housing is a panel mounting type housing and has double row. Double-row type<BR/>Glass-filled PBT, UL94V-0, black

The Jst Manufacturing , J2000 series , 2.5 mm pitch , receptacle contact is made of copper alloy and is selective gold-plated. 2.5 mm pitch<BR/>Applicable PC board thickness 1.6 mm<BR/>Copper alloy for superior conductivity

1.5mm JST ZH Connector Series Side Entry Through Hole Shrouded Headers These 1.5 mm pitch JST ZH Shrouded Headers are Side Entry, through Hole mounting types. The PC Board thickness for these 1.5 mm pitch JST ZH horizontal Headers can range from 0.6 to 1.2 mm.

JST CPT 2.0 mm Pitch Female Crimp Contacts Female crimp terminals for use with the JST CPT range of 2.0 mm pitch single and double circuit automotive connectors. See part number <a href="/web/p/products/1238227">123-8227</a> typically. Crimp tool <a href="/web/p/products/1238233">123-8233</a> is also available separately.
