SMT Transient Suppressors - TransGuard® Multilayer ZnO ceramic suppressors Copper Clad Steel, Solder Coated Lead Finish

AVX 0805 COG (NPO) Dielectric MLCC Capacitors This range of AVX COG (NPO) MLCCs (Multilayer Ceramic Capacitors) feature one of the most stable capacitor dielectrics available. The capacitance change with temperature is 0 ±30ppm/°C, which is less than ±0.3% C from -55°C to +125°C. The operating temperature range is 55ºC to +125ºC.

AVX 0805 COG (NPO) Dielectric MLCC Capacitors This range of AVX COG (NPO) MLCCs (Multilayer Ceramic Capacitors) feature one of the most stable capacitor dielectrics available. The capacitance change with temperature is 0 ±30ppm/°C, which is less than ±0.3% C from -55°C to +125°C. The operating temperature range is 55ºC to +125ºC.

AVX 0201 X5R Dielectric Capacitors AVX 0201 X5R Dielectric is a general purpose dielectric for ceramic capacitors available in high capacitance values up to 100 μF. These ceramic multilayer capacitors MLCC have a temperature variation of capacitance that is within ±15% from -55 ºC to +85 ºC.Suited for decoupling and filtering applications. The X5R are Available in High Capacitance values (up to 100μF).

AVX - X7R Dielectric Multilayer Ceramic Capacitors The X7R dielectric MLCC’s from AVX offer a ’temperature stable’ range of capacitors which can be used in a wide operating temperature range from -55°C to +125°C. These capacitors are an excellent choice for a wide range of applications that have changes in capacitance due to applied voltages. Features & Benefits Capacitance ±15% from -55°C to +125°C’Temperature stable’ range of capacitors Applications Can be used with a wide range of industrial applications where changes in capacitance occur

AVX – High Voltage FLEXITERM MLC Chips The high voltage FLEXITERM MLC chips offer a small sized, low leakage solution for a wide range of 600V to 5000V applications. The capacitors have a capacitance range from 10 pF to 0.047 μF and can be used in a wide operating temperature range from -55°C to +125°C. Features & Benefits Small sized, low leakage solutionCan be used with 600V to 5000V applications10 pF to 0.047 μF Capacitance range-55°C to +125°C Operating temperature Applications Snubbers in high frequency power convertersresonators in SMPSHigh voltage chip designs with low ESR’s

AVX C0G (NP0) Dielectric Capacitors AVX COG (NPO) dielectric capacitors offer one of the most stable capacitor dielectrics available.Capacitance change with temperatureIs 0 ±30ppm/°C which is less than ±0.3% C from -55°C to +125°C.Operating Temperature Range 55ºC to +125ºC

AVX 1206 X7R Dielectric Capacitors AVX X7R Dielectric capacitors are called temperature stable" ceramics and fall into EIA Class II materials. The dielectric chip usage covers a broad range of industrial applications where known changes in capacitance due to applied voltages are acceptable. The AVX Standard Commercial-Grade MLCCs are available in case sizes 0402, 0805, and 0603. Voltage Range: 4 V to 500 V. Capacitance Range: 100 pF to 22 μF.

SR Series AVX SR series radial ceramic multilayer capacitors are suited to commodity applications with voltage requirements up to 500v and where leaded is preferred over SMD.These leaded capacitors have excellent thermal shock and vibration resistance. Voltages range from 50 V to 500 V.Temperature range up to 125°C. Suitable for wave soldering.

TAJ Standard Series 2.5 to 16Vdc TAJ Series are General Purpose SMT Chip Tantalum Capacitors7 case sizes availableLow profile options availableCV range: 0.10-2200μF / 2.5-50VApplications include General low power DC/DC and Low Drop Out regulator

TPS Series 20 to 50Vdc The TPS series of low ESR SMD capacitors from AVX are designed for use mainly in power supply applications. The TPS series of capacitor are available in 14 different case sizes. Low ESR (equivalent series resistance)High ripple current capabilityLow power and heat dissipation

TPS Series 2.5 to 6.3Vdc The TPS series of low ESR SMD capacitors from AVX are designed for use mainly in power supply applications. The TPS series of capacitor are available in 14 different case sizes. Low ESR (equivalent series resistance)High ripple current capabilityLow power and heat dissipation
