The Linx compact helical antenna designed for use in 868 MHz and 915 MHz frequency bands for low-power, wide-area (LPWA) applications such as LoRaWAN®, Sigfox® and WiFi HaLow™ as well as ISM and remote control applications. This antenna is designed for embedded, inside-the-enclosure, applications, mounting directly to a printed circuit board (PCB) using a 6-32UNC screw. By eliminating the plastic housing and the need for an RF connector on the PCB, the ANT-8/9-PW-LPN provides a low-cost but high performing antenna solution. Compact size<BR/>Omnidirectional radiation pattern<BR/>Antenna mounts using provided 6-32UNC machine screw

The Linx compact helical antenna designed for 2.4 GHz ISM frequency band applications such as Bluetooth® and ZigBee®. It is designed for embedded, inside-the-enclosure, applications, mounting directly to a printed circuit board (PCB) using a 6-32UNC screw. By eliminating the plastic housing and the need for an RF connector on the PCB, this antenna provides a low-cost but high performing antenna solution. Compact size<BR/>Omnidirectional radiation pattern<BR/>Antenna mounts using provided 6-32UNC machine screw<BR/>Sensing and remote monitoring

The Linx SMA Jack to SMA Jack flange adapter is made of brass with gold finish. It has frequency range of 0 to 18 GHz, 50 Ω impedance, insulation resistance greater than 5000 MΩ and 1000 V RMS voltage rating. It is panel mount adapter with type 1/4in-36UNS threaded coupling fastening. It is most often used in testing and evaluation of products. Temperature range of -65°C to +165°C<BR/>Straight body style<BR/>Gold finished centre contact

The Linx SMA plug to RP-SMA jack adapter is made of brass with gold finish. It has frequency range of 0 to 18 GHz, 50 Ω impedance, 5000 MΩ(min) insulation resistance and 750 V RMS voltage rating. It has 1/4in-36 threaded coupling on both connectors. It is most often used in testing and evaluation of products. It has free hanging (in-line) mounting style and interface in accordance with MIL-STD-348A. Temperature range of -65°C to +165°C<BR/>Silicon rubber gasket on connector A<BR/>Gold finished centre contact<BR/>Straight body style

The Linx RP-SMA plug to N plug RG58 cable has brass connectors with nickel finished. Its has Be Cu pin with gold finished and black polyolefin heat shrink tubing. PTFE insulation<BR/>Compliant with EU RoHS directive

The Linx SMA jack to MHF1/U.FL plug adapter is made of gold finished brass and has gold plated centre contact. It has frequency range of 0 to 6 GHz, 50 Ω impedance, 5000 MΩ(min) insulation resistance and 1000 V RMS voltage rating. It has 1/4in-36 threaded coupling on connector A and snap on coupling on connector B. It is most often used in testing and evaluation of products. It has free hanging (in-line) mounting style and interface in accordance with MIL-STD-348A. Temperature range of -65°C to +165°C<BR/>Straight body style<BR/>Gold finished centre contact

The Linx RP-SMA jack to UFL/MHF1 plug cable has gold finished SMA female bulkhead mount connector on one side and U.FL plug on other side. It has frequency range from DC to 3 GHz and 50Ω characteristic impedance. It has 1.13mm coaxial cable of 100 mm overall length and black silicon rubber O-ring. Polyolefin heat shrink tubing<BR/>Gold finished nut and washer

The Linx RP-SMA Plug to SMA Jack adapter is made of brass with gold finish. It has frequency range of 0 to 18 GHz, 50 Ω impedance, 5000 MΩ(min) insulation resistance and 750 V RMS voltage rating. It has 1/4in-36 2B threaded coupling on connector A and 1/4in-36 2A. It is most often used in testing and evaluation of products. It has free hanging (in-line) mounting style and interface in accordance with MIL-STD-348A. Temperature range of -65°C to +165°C<BR/>Silicon rubber gasket on connector A<BR/>Gold finished centre contact<BR/>Straight body style

The Linx SMA Jack to SMA Jack adapter is made of stainless steel with gold finish. It has frequency range of 0 to 18 GHz, 50 Ω impedance, insulation resistance greater than 5000 MΩ and 1000 V RMS voltage rating. It has sealed bulkhead mounting style and type 1/4in-36UNS threaded coupling fastening. It is most often used in testing and evaluation of products. Temperature range of -65°C to +165°C<BR/>Silicon rubber O-ring on connector A<BR/>Gold finished centre contact

The Linx SMA jack to SMA Jack adapter is made of brass with gold finish. It has frequency range of 0 to 18 GHz, 50 Ω impedance, 5000 MΩ(min) insulation resistance and 750 V RMS voltage rating. It has 1/4in-36 2B threaded coupling on both connector. It is most often used in testing and evaluation of products. It has free hanging (in-line) mounting style and interface in accordance with MIL-STD-348A. Temperature range of -65°C to +165°C<BR/>Gold finished centre contact<BR/>Straight body style

The Linx SMA plug to MHF1/U.FL jack adapter is made of brass with gold finish and has gold plated centre contact. It has frequency range of 0 to 6 GHz, 50 Ω impedance, 5000 MΩ(min) insulation resistance and 250 V RMS voltage rating. It has 1/4in-36 threaded coupling on connector A and snap on coupling on connector B. It is most often used in testing and evaluation of products. It has free hanging (in-line) mounting style and interface in accordance with MIL-STD-348A. Temperature range of -65°C to +165°C<BR/>Silicon rubber gasket on connector A<BR/>Gold finished centre contact<BR/>Straight body style

The Linx RP-SMA jack to UFL/MHF1 plug cable has gold finished SMA female bulkhead mount connector on one side and U.FL plug on other side. It has frequency range from DC to 3 GHz and 50Ω characteristic impedance. It has 1.13mm coaxial cable of 200 mm overall length and black silicon rubber O-ring. Polyolefin heat shrink tubing<BR/>Gold finished nut and washer
