Snap on mounting on switch disconnectors and changeover switches1 to 3 padlocks in the 04...6mm

The Lovato BF1801A230 is 3 Pole, 18A Contactor with 1 NC auxiliary contact. 1 NC Auxiliary

GAX Switch Disconnector Accessories Lovato electric GAX series switch disconnector accessories to suit the GA series from Lovato. A wide range of accessories including: Auxiliary Contacts Fourth Pole Door Couplings Shaft Extensions Terminal Covers Lovato Switch Disconnectors & Accessories

Lovato SM3R Series Motor Protection Circuit Breaker, 55 to 75A Current Rating, 690V AC Voltage Rating - SM3R7500 This motor protection circuit breaker, classified within the SM3R series, is designed to deliver superior circuit protection. With a current rating adjustable between 55A and 75A, it effectively safeguards motors from overloads and short circuits. The robust dimensions of 70mm in length, 169mm in width, and 165mm in depth, alongside an operational temperature range of -20°C to +70°C, make it suitable for various industrial environments. Features & Benefits • Magnetic and thermal protection prevents motor damage • High breaking capacity of 50kA at 400V for robust performance • Adjustable thermal trip settings ensure tailored protection • 3-pole configuration enhances versatility in applications • Screw terminal design simplifies installation and maintenance • Compact size optimises space in control panels Applications • Used with industrial motors to prevent damage • Ideal for automation systems requiring reliable circuit protection • Suitable for diverse environments with variable temperature conditions • Compatible with various machinery in electrical installations What is the maximum voltage rating of this device? The voltage rating reaches up to 690V AC, ensuring compatibility with standard industrial supply systems. How does the thermal trip adjustment help in operation? By allowing current settings to be fine-tuned between 55A to 75A, it helps accommodate different motor specifications and operational needs, ensuring optimal protection. What are the implications of a breaking capacity of 50kA? This high breaking capacity allows the circuit breaker to quickly interrupt fault currents, minimising damage during short circuits and enhancing overall safety. Can it be used in low-temperature environments? Yes, it operates effectively in temperatures as low as -20°C, making it suitable for colder climates and applications. What type of maintenance is required for optimal performance? Regular inspections for wear and checking connections are advisable, along with ensuring that the thermal trip settings remain accurate for specific motor applications.

Lovato Digital Ammeter, AC Current, ±0.5 % Meter Accuracy - DMK71R1 This digital ammeter from the DMK series is a precision metering instrument designed for accurate electrical measurement. It is an AC current type device suitable for use in industrial environments, allowing users to monitor three-phase current values effectively. Features & Benefits • Measurement range from 0.05A to 6A accommodates various currents• Compatible with external low voltage CT for flexible applications• Operating temperature range of -20°C to +60°C supports diverse environments• Fixed terminal type provides secure and stable connections Applications • Used for monitoring three-phase power systems• Ideal for electrical measurement in automation processes• Utilised in industrial settings requiring precise current tracking How does it ensure measurement accuracy? It offers an accuracy of ±0.5% full scale. In what frequency range does it operate? It operates within a frequency range of 45 to 66 Hz. Will it maintain accuracy during overload conditions? Yes, it can handle overloads up to +20% without compromising accuracy.

Lovato Contactor, 2NO, 20A Contact Current Rating - CN2020220 This contactor by Lovato, with a contact current rating of 20A, is designed for industrial applications. With a DIN rail mount style and 2-pole configuration, it is suitable for a range of electrical setups. Features & Benefits • Operates at a coil voltage of 220V, making it compatible with various systems• Can withstand temperatures from -5°C to +55°C, ensuring durability in different environments• Features a screw terminal type for easy installation and maintenance• Comes with a 2-pole configuration, providing flexibility in electrical connections• DIN rail mount style allows for convenient mounting in control panels Applications • Ideal for use in automation systems requiring high current switching capabilities• Suitable for industrial machinery where reliable control of electrical circuits is essential Can it operate in extreme temperatures? Yes, this contactor can operate in temperatures ranging from -5°C to +55°C. Will it be easy to install? Yes, the screw terminal type allows for easy installation in various setups. Is it suitable for industrial applications? Yes, this contactor is designed specifically for industrial use.

Three-Phase Digital Voltmeter The modular digital metering instruments DMK70R1 for industrial and service fields warrant an extreme stability of the readouts owing to the large number of samplings.The measures in TRMS provide for a correct operation of voltage with high harmonic content. The model are able to store and display maximum (HIGH) and minimum (LOW) values of the readouts. Three-phase voltmeter meter with a LED displayVoltage measurements in True RMSStoring of minimum and maximum valuesProgrammable relay output (1 C/O)Selection option for Automatic or Manual resettingIP40 degree of protection on frontDIN rail mounting

Lovato Timer Relay, SPDT Contact Configuration, 8A Maximum Current - TMM1 This innovative Lovato timer relay is designed to provide reliable control in automation, electronics, electrical, and mechanical industries. The adjustable time delay feature allows for precise timing control, while the 8A capacity ensures compatibility with a range of applications. This series combines cutting edge technology with ease of use, making it an essential component for efficient operations. Features & Benefits • SPDT configuration for versatile control options• DIN rail mounting for easy installation in industrial settings• Multi function capability for customizable timer functions• Screw terminal for secure connections• External power supply for enhanced reliability• 12 to 240V AC/DC supply voltage for flexibility• Wide time range from 0.1s to 10 days for tailored operations• Compact design with dimensions of 104.7mm x 17.5mm x 64.9mm• Operating temperature range from 20°C to +60°C for adaptability Applications • Ideal for time-sensitive processes in manufacturing• Used for controlling lighting systems in commercial buildings• Suitable for automation applications in robotics• Perfect for scheduling operations in industrial machinery Can it withstand extreme temperatures? This timer relay has an operating temperature range from -20°C to +60°C, ensuring reliability in various environments. Will it work with both AC and DC power supplies? Yes, the timer relay is compatible with supply voltages ranging from 12 to 240V AC/DC for versatile applications. Is it easy to install in industrial settings? The timer relay features DIN rail mounting, allowing for straightforward installation in industrial environments.

Lovato Series BF Contactor, 660V AC/690V AC Contact Voltage Rating, 32A Contact Current Rating - BF18T4A400 This contactor is suitable for various industrial applications that require effective control of electrical devices. Its robust design and high voltage capabilities make it an important element in automation systems, ensuring efficient switching and control. The device is also compatible with DIN rail mounting, facilitating seamless installation across different setups. Features & Benefits • Handles up to 32A current for increased operational capacity • Rated for 400V AC coil voltage for versatile use • 4NO configuration supports multiple devices • High voltage rating of 690V AC ensures safe operation • Designed for DIN rail mounting for efficient space utilisation • Operates within a temperature range of -50 to +70°C for consistent performance Applications • Controls motors in manufacturing processes • Commonly used in automation controllers for machinery • Suitable for HVAC systems to manage fan and pump operations • Utilised in lighting systems requiring multiple circuits • Effective for switching high and low voltage circuits What type of installation is suitable for this model? It is designed for DIN rail mounting, making installation in control panels straightforward. Can this be used in outdoor applications? While it functions well within a wide temperature range, consider providing an enclosure for protection against environmental factors. Is it compatible with standard motorised load applications? Yes, it is suitable for various motor control applications within specified ratings. What maintenance is required for optimal performance? Regular inspections for wear and electrical connectivity are recommended to maintain its functionality. Is it possible to connect multiple devices to one unit? Yes, the 4NO configuration permits multiple connections, provided load ratings are carefully considered.

Lovato Series FB Base Mount Fuse Holder, 14x51mm Fuse Size, IP20 - FB02A3P This base mount fuse holder is intended for industrial applications, delivering consistent performance in electrical systems. It accommodates a 14x51mm fuse, providing effective protection for circuits operating up to 690V AC. The holder's sturdy construction and IP20 rating make it a suitable option for environments where safety and dependability are essential. Features & Benefits • Accommodates standard 14x51mm fuses for versatile usage • Rated for 50A current to support various applications • Designed with a 3-pole configuration suitable for three-phase systems • Easy installation on DIN 35mm rails • Offers IP20 protection against internal solid objects • Suitable for industrial settings, promoting safety and performance Applications • Utilised within electrical panels for enhanced circuit protection • Ideal for automation systems requiring reliable fuse integration • Applied in machinery for stable power distribution • Used in control cabinets for secure electrical connections What type of fuse is compatible with this holder? The holder is compatible with 14x51mm fuses for optimal performance. How do I install it on a DIN rail? It can be securely mounted by clipping the unit onto the DIN 35mm rail. Can it be used in outdoor environments? Due to its IP20 rating, it is unsuitable for outdoor use. What are the specifications for operational voltage? It supports a maximum voltage of 690V AC. Is it suitable for use in commercial settings? Yes, while designed for industrial applications, it can also be used in commercial environments.

Accessories A range of accessories designed for use with the Lovato Platinum 22mm push button, selector switch and control station series.

The Lovato BF0901A024 is 3 Pole, 9A Contactor with 1 NC auxiliary contact. 1 NC Auxiliary
