KFV Chassis Sockets Front mounting with threaded joint and solder terminals533-2728 is domino layout (with pin in four corners and a middle pin)

Minimodul Vertical Locking Headers These Lumberg Minimodul™ vertical locking pin headers mate with crimp contact housings (3114 Series) for indirect mating of wire to board connections.

KFV Chassis Sockets Front mounting with threaded joint and solder terminals533-2728 is domino layout (with pin in four corners and a middle pin)

The power supply cable socket is a reliable and durable connector designed for a temperature range of -20 °C to +70 °C. With a contact resistance of ≤ 30 mΩ and a nominal power of 1 A, this connector is ideal for various electrical applications. Straight version with solder eyes and bend protection for secure connectionsInsulating body made of PA for durabilityContact made of CuZn, nickeled for efficient power transmissionHousing made of PE for protection against external elementsMating cycles of ≥ 5000 for long-lasting useNominal voltage of 12 V DC for compatibility with common power suppliesTest voltage of 500 V/60 s for safety assuranceInsulation resistance of ≥ 100 MΩ for reliable performance

0332 Cable Plugs Threaded joint and solder terminals360° shielded

0322 Cable Sockets Threaded joint and solder terminals360° shielded

The Lumberg power supply chassis socket, available in an angular version with a break contact, is designed for integration into printed circuit boards. Temperature range -20 to +70 °CInsulating body PA, V-0 according to UL94

Minimodul Multimodul Crimp Contacts

DIN Chassis Socket for Printed Circuit Boards From Lumberg, this right-angle DIN 45322 circular connector socket is designed to be mounted on printed circuit boards, and is also suitable for locking.

SV Cable Plugs Straight version with threaded joint and solder terminals

Minimodul Vertical Locking Headers These Lumberg Minimodul™ vertical locking pin headers mate with crimp contact housings (3114 Series) for indirect mating of wire to board connections.

0305 Series Chassis Sockets Lumberg 0305 series chassis sockets with threaded joints and solder terminals. Back side mounting.
