Meanwell 90W ErP Single Output Switch Mode Desktop Power Supply - GST90A Series The Mean Well GST90 Series are Single Output 90W Desktop Green Adaptors. This class I desktop power supply features a very low No Load Power Consumption of ˂0.15W and up to 91% high efficiency, making it a good energy saving alternative. The GST90 comes in a 94V-0 rated plastic case, which is flame retardant and prevents users from electric shock. This Green Desktop Power Adaptor complies with energy efficiency level VI. The power adapter features an LED indicator and protections for short circuit, overload and over voltage. The GST90 guarantees safety and reliability and is ideal for applications such as consumer electronic devices, telecommunication devices, office facilities and industrial equipments. Universal AC input / full range3 pole AC inlet IEC320-C14Protections for short circuit, overload, over voltage and over temperatureFully enclosed Plastic CaseClass I Power with earth pinLED indicator for Power onNo load power consumption ˂0.15WErP level VI compliant

Mean Well Embedded Switch Mode Power Supply The Mean Well HRPG-600 series 648W single output AC to DC embedded switch mode power supply has an output current rating of 27A at 24VDC. It has a universal input supply voltage rating ranging from 85VAC to 264VAC/120VDC to 370VDC. Note:Power derating above 40°CMTBF to MIL-HDBK-217F Features and Benefits High efficiency up to 88%Long life and high reliabilityNo load power consumption is less than 0.75WBuilt-in active PFC functionBuilt-in cooling fan ON-OFF controlBuilt-in DC OK signalBuilt-in remote sense functionShort circuitOver loadOvervoltage and over temperature protectionWithstands 300VAC surge input for 5 seconds Certifications UL60950-1TUV approved EN60950-1 CB certifiedEN55022 class B (EMC compliance)EN61000-3-2,-3 (power factor correction)

Mean Well HLG-600H-B Series 600W IP67 Rated Dimmable LED Driver Power Supply The Mean Well HLG-600H-B is a series of high wattage constant voltage/constant current LED Power supplies. This LED drivers feature wide input range 90 to 305 Vac and constant current output for general lighting fixtures. With up to date high performance topology design the HLG-600H-B possess up to 96% high efficiency, so they can be cooled by free air convection from -40 to +70°C. This Power supply is also dust-proof and water-proof IP67 rated, it has 5G anti vibration ability and 4kV surge immunity, making it suitable to withstand the dust and moisture of outdoor or indoor harsh environments These constant voltage/constant current LED drivers are suitable for applications such as LED street lighting, LED high-bay lighting, parking space lighting, LED search light and indoor or outdoor LED lighting. Wide range input 90 to 305VACBuilt-in active PFC functionNo load power consumption Up to 96% high efficiencyIP67 design for indoor or outdoor installationsThree in one dimming functionMeet 4kV surge immunity level (EN61000-4-5)-40 to +70°C working temperatureCooling by free air convectionProtections: Short circuit / Over Current / Over voltage / Over temperatureSuitable for dry, damp, wet locations

Mean Well Desktop Power Supply The Mean Well GST60A series desktop power supply is the latest invention with a high-quality adapter and a voltage rating of 12VDC. It provides 60W of continuous output power in a high-quality, compact enclosure suitable for many general power applications. It has an input frequency range from 47Hz to 63Hz. While the input voltage rating ranging from 90VAC to 264VAC/135VDC to 370VDC, its maximum input leakage current is 0.75mA. This product is equipped with a 3-pin standard IEC320-C14 power plug. This power supply boasts an efficiency rating of up to 92%, coupled with an extremely low no-load consumption rating of below 0.075W. Features and Benefits Output current is 5AProtections for short-circuit, overload and over voltageFully enclosed plastic caseClass I power with earth pinLED indicator for power onNo load power consumption less than 0.075WErP level VI compliantWorking temperature ranges between -30°C and 70°C Applications Consumer electronic devicesTelecommunication devicesOffice facilities Industrial equipment Certifications UL60950-1TUV EN60950-1BSMI CNS14336CCC GB4943J60950-1EN55022 class BEN61000-3-2,3FCC PART 15 / CISPR22 class BCNS13438 class BGB9254GB17625.1EN61000-4-2,3,4,5,6,8,11 Light industry level, criteria A

Mean Well (PSD-30 Series) Single Output Module DC-DC Converter The Mean Well PSD-30 Series brings reliability alongside great affordability. This series of DC-DC Converter is highly compliant with industrial standards such as EN55032, EN61000-4-2,3,4,6,8, and more. Lightweight and compact in size, the PSD series is perfect for applications/projects requiring space-saving.This series is robust enough to work under temperatures of -20 to +60℃, has low ripple and noise, and great efficiency. (Series) Features & Benefits: • Cooling by free air convection• Low cost, high reliability• Built-in EMI filter for greater low ripple and noise• 1500V AC I/O isolation• 2-year manufacturer warranty (Series) Input specifications: • DC Currents ranging from 4.5A/12V, 2.5A/24V & 1.1A/48V.• Efficiency ratings from 77% to 83% (Series) Output specifications: • Rated currents between 1.25A to 5A• Current ranges of 0 to 5A• 2s, 50ms setup, rise & hold-up time at full load (Series) Compliance & Protection: •105 ∼150% rated output power• Reverse polarity via an internal fuse• Hiccup mode recovery (automatic recovery after fault is removed)• Safety standards: EAC TP TC 004 approved, IEC 62368-1 CB approved by Dekra• EMS immunity: Compliance to EN61000-4-2,3,4,6,8; ENV50204, EN 55024, light industry level, criteria A, EAC TP TC 020

Mean Well Power Switch Mode Power Supply The Mean Well RSP-1500 series 1536W single output embedded switch mode power supply has an output current rating of 32A at 48VDC. It has a universal input supply voltage rating from 90VAC to 264VAC and 127VDC to 370VDC. Note:Derate output 2% per °C above 45°C (12V), 50°C (24, 27, 48V). The depth excludes terminal block. Features and Benefits high-efficiency up to 91%Long life and high reliabilityBuilt-in fanRemote senseRemote ON-OFF controlAlarm signal outputCurrent sharing up to 6000W (3+1)LED indicator for power onEasy installation, input screw terminals and output 2xM8 bolts (supplied)Adjustable output voltage (±10%)Short circuit protectionOverload protectionOvervoltage and over temperature protection Applications Factory control or automation apparatusTest and measurement instrument Laser related machineBurn-in facilityDigital broadcastingRF application Certifications EN 60950UL 60950EN 61000-3-2 (harmonic current)EN 55022 class B (EMC)EN55032 (CISPR32) / EN55011 (CISPR11)EN55032 (CISPR32) / EN55011 (CISPR11)EN61000-3-2EN61000-3-3EN61000-4-2EN61000-4-3EN61000-4-4EN61000-4-5EN61000-4-6 EN61000-4-8EN61000-4-11

Mean Well 300W Railway Certified Regulated Isolated DC-DC Converter - RSD 300 Se The Mean Well railway power supply RSD-300 series can satisfy the various requirements of vehicle applications. Complies with railway certificates (EN50155, IEC60571, IEC61373, EN50121-3-2) making them suitable for use in vehicles that are equipped with DC power source. This Power supply has a 5G anti-vibration ability and a wide range working temperature of -40 to +70℃, with protections for short circuit, overload, output over voltage, over temperature and input reverse polarity, it also has a built in current limiting circuit. The RSD-300 possess up to 91% of high efficiency, it is semi encapsulated for PCB protection, providing the basic function of anti moisture, anti dust and heat dissipation. The RSD-300 can be cooled without forced air and still work between -40% and +70% ambient temperature. This Mean Well power supply is suitable for applications of harsh environment and for all kinds of vehicles that are equipped with DC power source. The applications include railway, metro rapid transit system, subway, bus, leisure trailer, vessel and also security system, DC UPS system, and telecom equipments. Comply with EN50155 (IEC60571) railway related regulations 2:1 wide input range 4000VDC input/output isolation High efficiency up to 91% Cooling by free air convection Built-in constant current limiting circuit Protections: Short circuit / Overload / Over voltage / Over temperature / Input reverse polarity (no damage) using 105℃ long life electrolytic capacitorsLED indicator for power on 100% full load burn-in test-40 to +70℃ wide operating range

Mean Well 80W IP67 Dimmable Constant Current/Voltage LED Driver/Power Supply - HLG-80H HLN-80G series 80W IP67 waterproof dimmable constant current, constant voltage LED driver / power supply with universal AC input. These IP67 dimmable LED drivers / power supplies have a built in 3 in 1 dimming function, IP67 ingress protection and built in active PFC function. Suitable applications for these dimmable IP67 LED drivers / power supplies include LED lighting and moving sign applications ands can be used in dry, damp or wet locations. Full range universal AC inputIP67 design for indoor or outdoor applicationsFree air convection coolingBuilt in active PFC functionBuilt in 3 in 1 dimming function (1 to 10 Vdc or PMW signal or resistance)Constant current level adjustable via output cable with 1 to 10 Vdc or 10V PWM signal or resistorShort circuit, overload, over voltage and over temperature protectionCompliance to worldwide safety regulations for lightingEMC compliance to EN55015 class BHarmonic current compliance to EN61000-3-2 Class C (≥60% load); EN61000-3-3

Mean Well 40W IP67 Dimmable Constant Current/Voltage LED Driver/PowerSupply - HLG-40H HLG-40H series 40W IP67 waterproof dimmable constant current, constant voltage LED driver / power supply with universal AC input. These IP67 dimmable LED drivers / power supplies have a built in 3 in 1 dimming function and built in active PFC function. Suitable applications for these dimmable IP67 LED drivers / power supplies include LED lighting, moving sign and outdoor applications and can be used in dry, damp or wet locations. Full range universal AC inputIP67 design for indoor and outdoor installationsFree air convection coolingBuilt in active PFC functionConstant current level adjustable via output cable with 1 to 10 Vdc or 10V PWM signal or resistorBuilt in 3 in 1 dimming function (1 to 10 Vdc or PMW signal or resistance)Short circuit, overload, over voltage and over temperature protectionCompliance to worldwide safety regulations for lightingEMC compliance to EN55015 Class B Harmonic current compliance to EN61000-3-2 Class C (≥60% load); EN61000-3-3

Mean Well Switch Mode Power Supply The Mean Well PSP-600 series 600.7W single output AC to DC enclosed switch mode power supply has an output current rating of 44.5A at 13.5VDC. It has a universal input supply voltage rating ranging from 88VAC to 264VAC/124VDC to 370VDC. Note:Derate output 2% per °C above 50°C and below 0°C (no derating below 0°C to -20°C for SP750 Series). Depth excludes terminal blocks. Features and Benefits Adjustable output voltage (±10%)Built-in fan with speed controlCurrent sharing up to 2400W (3+1) (PSP-600 series only)Easy installationHigh efficiency up to 85%High reliabilityLED indicator for power onLong life OverloadOvervoltage and over temperature protection Remote ON-OFF controlRemote senseScrew terminalsShort circuit Certifications CB approvedEN 55022 Class B(EMC)EN 60950EN 61000-3-2 (Power factor correction)TUV approvedUL 60950

Slim and Low profile (33mm)Fanless design, 500W convectionWithstand 300VAC surge input for 5 secondsBuild-in active PFC function150% peak load capability(100ms)-20∼+70℃ working temperatureProtections: Short circuit / Overload / Over voltage / Over temperatureDC OK active signal and redundant function (option)Operating altitude up to 5000 meter(Note.5)LED indicator for power on3 years warrantyApplicationsIndustrial automation machineryIndustrial control systemMechanical and electrical equipmentElectronic instruments, equipments or apparatusLED display application AC-DC Slim Single output enclosed power supply with PFC, Output 15VDC at 33.4A

Mean Well Power Medical Power Supply The Mean Well RPS-60 series 60W single output AC to DC PCB type medical power supply has an output current rating of 5A at 12VDC. It has a universal input supply voltage rating from 90VAC to 264VACand 127VDC to 370VDC. Note:De-rating 2% per °C above 50°CMTBF to MIL-HDBK-217F (25°C) Features and Benefits Miniature size is 2in long and 4in wide High power densityhigh-efficiency up to 84% Long life and high reliabilityEnergy saving power supplyNo load power consumption less than 0.75WMedical safety approvedLow leakage current less than 200μAAdjustable output voltage (-5 to 10%) Short circuitOverload and overvoltage protectionExtra 10% 'peak current' rating for 10 secondsCooling by free air convectionEMI class B for class configuration Applications Oral irrigatorHemodialysis machineMedical computer monitorSleep Apnea device Certifications EN 61000-3-2 (harmonic current compliance)EN 55022 class B (EMC)TUV, CB, UL recognised component for Canada and USEN55011 (CISPR11)EN55011 (CISPR11)EN61000-3-2EN61000-3-3EN61000-4-2EN61000-4-3EN61000-4-4EN61000-4-5EN61000-4-6EN61000-4-8EN61000-4-11
