<B>Megger Calibration Check Box, 30mA RCD Included, 2.2kg Weight - MTB7671 Series - 1002-224</B> Are your electrical installation testers up to the job? Verify that everything's in order using this calibration check box from Megger. It not only confirms that your testers are working properly, but also looks at measurement ranges, so you know you're using the right current or voltage for the job. Plus, it checks insulation, continuity, loop, PFC and RCD functions, making it a highly versatile piece of kit. <B>Features & Benefits</B> • Protected with 30mA RCD to keep you safe from faulty testers<BR/>• Colour-coded test functions and simple PASS/FAIL values take the guesswork out of results<BR/>• Suitable for indoor and outdoor conditions with operating temperature range between 0°C and +40°C<BR/>• Portable design weighs just 2.2kg, including the handy carrying case <B>Applications</B> • Street lighting<BR/>• Engineering systems<BR/>• Building construction <B>What size is the check box?</B> The unit is 100 (H) x 320 (L) x 280mm (W), making it a compact choice that fits easily into a storage cabinet or on a workbench. <B>What's included with this calibration check box?</B> The set comes with 10 history cards and 160 'Instrument Tested' labels, along with an instruction manual to help you get started.

LT300 Loop Tester The LT300 combines high current-loop testing over a wide range of frequencies and supply voltages with simple operation. This is a HIGH CURRENT ONLY tester, designed for installations where there are no RCDs installed. A two-wire test performs a fast loop impedance measurement at a test current up to 27A, with a resolution of 0.01ohms. Frequency range and operating voltage are wide, allowing for a diverse range of applications up to and including CATIV 550V phase-to-phase. Testing commences automatically as soon as the instrument is connected to the supply. Repeat testing is provided by the TEST button. High current loop tester<BR/>Simple auto start operation<BR/>16Hz to 400Hz frequency range<BR/>Up to CATIV 300V phase-to-earth (550V phase-to-phase) applications<BR/>Optional two-wire lead set available separately, RS stock no. <a href="/web/p/products/5377282">537-7282</a>

<B>Megger Insulation Tester HV Test Lead Set,</B><B> 18mm Jaw Capacity, 10m Lead Length - MIT500 Series - 1002-643</B> Check how well your electronic device resists current flow with this insulation tester HV test lead set from Megger. It has three leads terminated with jaw connectors, so you can clamp down on the device you're checking. Plug these components into an MIT500 series insulation tester to view and store your readings. Thanks to a cable insulation rating of 12kV DC, you can rest assured you're in safe hands when using this set. <B>Features & Benefits</B> • Maximum jaw opening diameter of 18mm for increased surface contact<BR/>• Dual-insulated silicon cable construction offers protection from electric shock<BR/>• Compact external dimensions of 139 (L) x 73mm (W) to fit into tight spaces <B>Applications</B> • Power plants<BR/>• Oil and gas industry<BR/>• Aerospace engineering<BR/>• Agricultural equipment <B>How long are the leads in this set?</B> The leads in this set are each 10m long, giving you plenty of reach. <B>What's the insulation measurement capacity of this set?</B> You can use this test lead set to measure insulation ratings up to 5 or 10kV, making it a versatile option.

MIT500 Series Industrial Insulation Testers - 5 and 10kV Robust and reliable testers for high performance in the real-world. The new MIT series: MIT515, MIT525, MIT1025 are designed for industrial and power distribution applications.<BR/><BR/>The New MIT 515 (<a href="/web/p/products/7639267">763-9267</a>) instrument can be used to perform both simple Go No-Go insulation tests and basic diagnostic insulation tests such as Polarisation Index (PI).<BR/><BR/>There are two new advanced models: MIT 525 (<a href="/web/p/products/7639260">763-9260</a>) and MIT1025 (<a href="/web/p/products/7639264">763-9264</a>) with memory and diagnostic insulation testing. The 10 kV MIT1025 is suited to more rigorous testing of higher voltage equipment. The 5kV models test to 10TOhm while the 10kV models will test to 20TOhm and all instruments have a fully specified guard terminal/circuit to allow accurate results in a wide range of test situations. You can test from battery or from AC power and benefit from a long battery life and a rapid recharge time. To assist with storing and trending results, both the MIT525 and MIT1025 include memory and download to PC via USB, as well as additional diagnostic tests, such as Step Voltage (SV) and ramp test. 10 TΩ (5 kV) / 20 TΩ (10 kV) max. insulation resistance<BR/>Timed IR plus PI and DAR diagnostic tests<BR/>Operate with dead battery when on line power/mains<BR/>Rapid charge Li-ion battery – up to 6 hrs continuous testing (5 kV)<BR/>Dedicated voltmeter function (30 V to 660 V)<BR/>CATIV 600 V safety rating<BR/>Large LCD display with automatic backlight<BR/>Noise filter – rejects up to 3 mA noise<BR/>High altitude operation up to 3000 m<BR/><BR/><B>MIT525/1025 ADDITIONAL FEATURES:</B><BR/>Dielectric Discharge (DD), Step Voltage (SV) and ramp test functions<BR/>Advanced memory with time/date stamp, on screen recall<BR/>Real time clock<BR/>Download of memory via isolated USB (type B) interface (USB cable to PC)<BR/>PowerDB Lite asset management software

<B>Megger Insulation Tester HV Test Lead Set, 10kV Maximum Voltage, 10m Length - MIT500 Series - 1002-647</B> Amp up your electrical safety with this high-voltage test lead set from Megger. When plugged into the MIT515 insulation tester (763-9267), it checks for current leaks in your device's insulation. Thanks to a massive 10kV test voltage rating, this mighty piece of kit is suitable for use with very high-power equipment. The three leads all terminate in sturdy jaw connectors, so you can really get your teeth into the devices you're checking. For maximum user safety, these sturdy cables are insulated against surges of up to 12kV. <B>Features & Benefits</B> • 10m length lets you take measurements over big workplaces<BR/>• Wide 34mm clip capacity means you can clamp down on large surface areas with ease<BR/>• Set of 3 leads to cover multiple inputs <B>Applications</B> • Automotive engineering<BR/>• Power plants<BR/>• HVAC systems <B>How can I make sure the leads haven't suffered any damage?</B> For your peace of mind, the dual insulated silicon sheathing means it's easy to spot nicks or tears in this robust cable set. The outer layers are coloured red, blue and black respectively, while the inner layer is a contrasting white colour, so any damage is clearly visible.

MIT500 Series Industrial Insulation Testers - 5 and 10kV Robust and reliable testers for high performance in the real-world. The new MIT series: MIT515, MIT525, MIT1025 are designed for industrial and power distribution applications.<BR/><BR/>The New MIT 515 (<a href="/web/p/products/7639267">763-9267</a>) instrument can be used to perform both simple Go No-Go insulation tests and basic diagnostic insulation tests such as Polarisation Index (PI).<BR/><BR/>There are two new advanced models: MIT 525 (<a href="/web/p/products/7639260">763-9260</a>) and MIT1025 (<a href="/web/p/products/7639264">763-9264</a>) with memory and diagnostic insulation testing. The 10 kV MIT1025 is suited to more rigorous testing of higher voltage equipment. The 5kV models test to 10TOhm while the 10kV models will test to 20TOhm and all instruments have a fully specified guard terminal/circuit to allow accurate results in a wide range of test situations. You can test from battery or from AC power and benefit from a long battery life and a rapid recharge time. To assist with storing and trending results, both the MIT525 and MIT1025 include memory and download to PC via USB, as well as additional diagnostic tests, such as Step Voltage (SV) and ramp test. 10 TΩ (5 kV) / 20 TΩ (10 kV) max. insulation resistance<BR/>Timed IR plus PI and DAR diagnostic tests<BR/>Operate with dead battery when on line power/mains<BR/>Rapid charge Li-ion battery – up to 6 hrs continuous testing (5 kV)<BR/>Dedicated voltmeter function (30 V to 660 V)<BR/>CATIV 600 V safety rating<BR/>Large LCD display with automatic backlight<BR/>Noise filter – rejects up to 3 mA noise<BR/>High altitude operation up to 3000 m<BR/><BR/><B>MIT525/1025 ADDITIONAL FEATURES:</B><BR/>Dielectric Discharge (DD), Step Voltage (SV) and ramp test functions<BR/>Advanced memory with time/date stamp, on screen recall<BR/>Real time clock<BR/>Download of memory via isolated USB (type B) interface (USB cable to PC)<BR/>PowerDB Lite asset management software

<B>Megger Insulation Tester, LCD Screen, 30 to 660V Voltage Measurement Range - MIT500 Series - MIT525</B> Keen to check the quality of your electrical insulating material? This Megger insulation tester is just the thing. By clamping the leads on your test object, you can measure resistance up to 10TΩ to detect current leaks in heavy-duty systems. This allows you to put an end to electrical hazards to keep equipment and personnel safe and sound. For on-the-go testing, this unit has a lithium-ion battery that can operate continuously for up to six hours. <B>Features & Benefits</B> • Lockable terminals guard against accidental lead disconnection<BR/>• Battery charges in just 2.5 hours to help reduce downtime<BR/>• Large backlit LCD is easy to read in areas of low light<BR/>• IP65 rating means it's protected against dust and low-pressure water jets<BR/>• Safe for use in harsh conditions, thanks to a wide operating temperature range of -20°C to +50°C <B>Applications</B> • Circuit breakers<BR/>• Transformers<BR/>• Electric motors and generators <B>How accurate is this unit?</B> This insulation tester has a high accuracy of ±5% on readings up to 1TΩ and +10% on readings up to 10TΩ. This means you can count on it for precise results.

<B>Megger Loop Impedance and RCD Combined Tester, ±2% ±1V Voltage Measurement Accuracy, Backlit Display - </B><B>LTW300 Series</B><B> - LTW425-EU-BS</B> Examine your circuit protection devices for efficiency with this loop impedance and RCD combined tester from Megger. It checks your loop systems, measuring the resistance of electrical loads and safety components like fuses and breakers to find high-resistance connections. The unit also assesses the trip time and sensitivity of your RCD to ensure it reacts quickly to leakage faults. Thanks to non-trip testing, you can monitor your live network without setting off ≥30mA RCDs, which prevents downtime. A backlit display means you won't miss a thing, even when you're working in dark spots. <B>Features & Benefits</B> • Auto-start function improves safety by kicking off the test immediately after you connect the leads<BR/>• Wide operating voltage range between 50 and 440V AC for versatile use<BR/>• Automatic noise detection and test extension to ensure accurate results<BR/>• Built-in front cover for impact protection in harsh environments <B>Applications </B> • Audiovisual installations<BR/>• Oil and gas plants<BR/>• Marine engineering <B>How much does this tester weigh?</B> This unit weighs just 1kg excluding the test leads, so it's easy to transport when going about your work.

LTW 300 Series Earth loop impedance testers to verify the loop impedance of a live electrical circuit without the need to disconnect the electrical supply. The LTW300 series instruments offer a safe and easy 2 wire loop testing solution that does not trip 30mA RCDs and can be used on a wide range of voltages. Backlit display<BR/>0.01Ω resolution<BR/>No-trip loop test on circuits with RCDs of ≥30 mA<BR/>3 phase circuits with RCD protection can be tested<BR/>Tests radial circuits where the circuit does not return to the origin, even where only a phase and neutral contacts are available.<BR/>10 second non trip loop test time with Auto test extension up to a further 10 seconds if noise is detected, to improve the accuracy of the test<BR/>High current loop testing for supplies that do not have an RCD fitted <BR/>AUTO START will start the loop test running as soon as the test leads are connected; no need to press the test button means much safer testing<BR/>PFC Display up to 20kA<BR/>Voltage and frequency measurement<BR/>110Vac systems including 110V centre tap to earth (55V phase to earth) can be tested on the secondary winding.<BR/>IP54 Weatherproof case<BR/>Optional 10A fused 2 wired test leads and crocodile clip set<BR/>Complies with IEC61010-1 300V CATIV safety standard and meets EN61557

<B>Megger Loop Impedance and RCD Combined Tester, AA Battery Type, 1kg Weight - </B><B>LTW300 Series</B><B> - LTW325-EU-BS</B> Hone in on electrical faults and safety hazards in your circuitry with this loop impedance and RCD combined tester from Megger. You can use it to get the lowdown on the state of breakers and fuses in your setup to ensure it's safe to rely on them. It examines your system live, meaning there's no need to power down and disturb your workflow. A backlit LCD means data is a breeze to read, even in dimly lit conditions. <B>Features & Benefits</B> • Performs reliably in a wide operating temperature range between -10°C and +50°C for use in harsh conditions<BR/>• Light weight of 1kg means it's easy to transport<BR/>• Long battery life of up to 2000 tests for efficient use<BR/>• Loop test accuracy of ±10% for reliable results<BR/>• Compact dimensions of 203 (L) x 148 (W) x 78mm (H) for ease of storage <B>Applications</B> • Electrical services<BR/>• Industrial power supplies<BR/>• Factory automation<BR/>• Domestic appliances <B>What's supplied with this tester?</B> It includes instructions, a robust carry case, a mains socket test lead, a test lead set with crocodile clips and eight AA alkaline batteries. This means you'll have everything you need to begin your measurements at once.

Megger Insulation and Continuity Testers The Megger MIT410/2 200Gohm insulation and continuity testers have a redesigned case, back-stand and 6-cell battery compartment with separate fuse access. Insulation testing has been enhanced with feedback controlled test voltages to limit over-voltage to 2%, rather than the industry-standard 10-20%. All primary results are displayed in the larger digital display and repeated on the analogue arc. Auxiliary test information such as frequency, leakage current, insulation or circuit voltage is displayed in the smaller secondary digital display. A variable range has been added to allow any intermediate voltage from 50 V to 1000 V in 10 V steps. Where application-specific test voltages are required that do not appear in the standard ranges.<BR/>Supplied with<BR/>Hard carry case complete with red/black silicone test lead set with probes, 1 red & 1 black crocodile clip, 1 SP5 Remote Switch Probe, information CD and 6 x AA Alkaline Batteries Features and Benefits Insulation testing up to 1000V<BR/>Polarisation Index, Dielectric Absorption Ratio, Variable Test Voltage and result storage<BR/>Stabilised insulation test voltage (New)<BR/>Single range, faster continuity testing from 0.01ohm to 1Mohm (New)<BR/>600V TRMS AC and DC voltage measurement<BR/>Live circuit detection and protection<BR/>User variable insulation test voltage from 100V to 1000V (New) depending on model<BR/>Test result storage and Bluetooth® downloading depending on model<BR/>Rechargeable options for mains and car charging (New) depending on model Applications Industrial <BR/>Cable Testing<BR/>Motor Testing<BR/>Automotive<BR/>ESD<BR/>Panel Building<BR/>Avionics<BR/>Maintenance Certifications CAT IV 600 V <BR/>IP54 rated

Megger MIT 400 mk2 Series Insulation & Continuity Testers Meggers MIT400/2 Series of insulation and continuity testers are designed for testing electrical installation and specialist applications where accurate, reliable and safe testing is essential. Combining the latest range of measurement techniques with new instrument design to provide a state-of-the-art tester that is compact and comfortable to hold. Featuring a redesigned case, back-stand and 6 cell battery compartment with separate fuse access. All instruments are over-moulded for increased protection and achieve an IP54 weatherproof rating, providing an almost indestructible case.<BR/><BR/>All primary results are displayed in the larger digital display and repeated on the analogue arc. Auxiliary test information such as frequency, leakage current, insulation or circuit voltage is displayed in the smaller secondary digital display. A variable range has been added to allow any intermediate voltage from 50 V to 1000 V in 10 V steps. Where application- specific test voltages are required that do not appear in the standard ranges.<BR/>Continuity testing is now faster, a single auto-ranging 0.01 Ω to 1.0 MΩ function replaces the "ohms" and "k ohms" ranges. Retained are the 200 mA and 20 mA test options.<BR/><BR/>Typical Applications include:- Manufacturing/production line goods, electrostatic measurement, component testing, battery powered traction and letting equipment, commercial avionics and military land, marine and air communications. Stabilised insulation test voltage<BR/>600 V TRMS AC and DC voltage measurement<BR/>Live circuit detection and protection<BR/>CAT IV 600 V & IP54<BR/>Weatherproof, rated to IP54<BR/>Battery Requirements: 6 AA Alkaline or Nickel Metal Hydride (NIMH)
