Murata 0603 LQW18AN Series Wire Wound Inductors High quality coil inductors designed for VHF and UHF applications.High resonance frequency.Low tolerance of inductance values.Models with the suffix '10D' have lower DC resistance values. Applications: High frequency circuits for wireless telecommunications equipment: Bluetooth, GSM, W-LAN.

Murata 0402 LQW15AN_00D Series Wire Wound Inductors (0.051μH - 0.12μH) High quality coil inductors designed for VHF and UHF applications.High resonance frequency.Low tolerance of inductance values.Applications: High frequency circuits for wireless telecommunications equipment such as Bluetooth, GSM, W-LAN.

The Murata Encapsulated isolated wide input bipolar 15 watt DC/DC converter offers efficient regulated DC power for printed circuit board mounting. The rugged mechanical, thermal and electrical design of this product is intended for high reliability and harsh environment. Five-sided shielded metal package reduces radiated emissionsUp to 15 watts or greater total output power with over temperature shutdownIsolation up to 1600 Vdc(basic)High efficiency flyback topology

Murata 2220 LQH55D Series Wire Wound Chokes LQH55D series wirewound inductors for choke applications using high performance thick wire wound technology. Low direct current resistance, large current capacity and large inductanceFor DC-DC converters and DC power supply circuits

Murata 0402 LQW15A_10 Series Wire Wound Inductors High quality coil inductors designed for VHF and UHF applications.High resonance frequency.Low tolerance of inductance values.Lower DC resistance values than the _00 series. Applications: High frequency circuits for wireless telecommunications equipment such as Bluetooth, GSM, W-LAN.

This is Murata primary products renowned for both small size and large capacitance value with latest advanced technology. Achieves large-capacity and small size in a multilayer structureSn plating is applied to the external electrodes excellent solderabilityHigh reliability with no polarityApplicationsRated voltage 100V MaxHigh Dielectric Constant Type・・・For decoupling and smoothing circuitsTemperature Compensating Type・・・For tuning circuits,oscillating circuits,and high frequency filter circuitsRated voltage 200V minHigh Dielectric Constant Type・・・For clamp snubber circuits and smoothing circuitsTemperature Compensating Type・・・Power supply damper snubber

Multilayer ceramic capacitors or as they are often referred to as MLCC's are specially designed capacitors and are engineered to consist of a 'multilayer' structure. This structure includes a ceramic material and also metal conducting layers. The ceramic layers insulate the capacitor, this helps to reduce heat loss which in turn improves the efficiency of the product. Multilayer capacitors have high thermal stability, high ripple current capability and also extremely low ESR (Equivalent Series Resistance) and ESL (Equivalent Series Inductance) which helps make these products perfect for a multitude of applications.

This is Murata primary products renowned for both small size and large capacitance value with latest advanced technology. Achieves large-capacity and small size in a multilayer structureSn plating is applied to the external electrodes excellent solderabilityHigh reliability with no polarityApplicationsRated voltage 100V MaxHigh Dielectric Constant Type・・・For decoupling and smoothing circuitsTemperature Compensating Type・・・For tuning circuits,oscillating circuits,and high frequency filter circuitsRated voltage 200V minHigh Dielectric Constant Type・・・For clamp snubber circuits and smoothing circuitsTemperature Compensating Type・・・Power supply damper snubber

RDE series Murata RDE radial leaded capacitors are designed for commercial applications. The multilayer ceramic capacitors are small but have a large capacitance, low ESR characteristics for high frequency. Coated with epoxy resin with tin/copper radial leads. Applications Commercial ElectronicsConsumer electronicsWhite goods

Murata GCM Automotive 0805 Series The Murata GCM Automotive Series Ceramic Capacitors feature excellent pulse responsibility and noise reduction due to the low impedance at high frequencyHigh dielectric constant type, in a smaller size with a higher capacitance valueHigh reliability with no polarityExcellent solderability is achieved by the Tin plating at the external electrodesNow available with new low pF values and additional values in the 1206 case size

Murata 2220 LQH55D Series Wire Wound Chokes LQH55D series wirewound inductors for choke applications using high performance thick wire wound technology. Low direct current resistance, large current capacity and large inductanceFor DC-DC converters and DC power supply circuits

The Murata ceramic resonator has high reliability and available for a wide temperature range. Piezoelectric ceramic resonator is used for time base oscillator in a microcomputer for automotive application. Oscillation circuits do not require external load capacitorsAvailable for a wide frequency rangeExtremely small and have a low profileNo adjustment is necessary for oscillation circuitsStable supply is ensured
