Murata 1W SIP Single and Dual Output Isolated DC-DC Converter - MEJ1 Series The Murata Power MEJ1 is a series of isolated 1 Watt DC-DC converters, encapsulated in a 7 pin SIP package. The DC-DC converter complies with the 3rd edition of medical safety standard and provides the following MOOP (means of operator protection): 2 MOOP based upon a working voltage of 200Vrms max - 280Vpkmax, between primary and secondary and 1 MOOP based upon a working voltage of 200Vrms max, between primary and its enclosure. <BR/>Typical energy efficiencies of these DC-DC converters are in the range of 70 to 78%.<BR/>The MEJ1 series is designed for low power applications that require a high degree of isolation such as an agency-approved safety barrier for medical equipment, IGBT drivers, and control systems. Single and dual outputs<BR/>UL 94V-0 package material<BR/>SIP package style<BR/>5.2kVDC isolation<BR/>3.3V, 5V, 12V, 15V & 24V inputs<BR/>3.3V, 5V, 9V, 12V & 15V output<BR/>Internal SMD construction<BR/>Fully encapsulated with toroidal magnetics<BR/>Pin compatible with the MEV, NMV, NMK, MEJ2, & NMJ series

Murata 1W SIP Dual Output Unregulated Isolated DC-DC Converter - MEA Series 1 W dual output SIP7 unregulated DC to DC converters with standard industry pinout and efficiency rating of up to 89.5%. These SIP7 DC to DC converters have an improved regulation performance of ≤5% making them suitable for applications where a wide output voltage variation can not be tolerated. An ideal application for these DC to DC converters is the provision of dual rail supplies with the additional benefit of having galvanic isolation to reduce any switching noise. All of the rated power can be drawn from a single output providing the total load does not exceed 1watt. SIP7 package with industry standard pinout<BR/>Efficiency of up to 89.5%<BR/>Wide temperature performance of -40 to + 85°C at full 1W load <BR/>Power density to 0.85W/cm³<BR/>Power sharing on output<BR/>No heatsink or external components required<BR/>Fully encapsulated with toroidal magnetics<BR/>No electrolytic or tantalum capacitors<BR/>UL94V-0 package material

Murata 22R Series Radial Inductor Resin coated miniature general purpose radial wire ended RF inductors<BR/>Their small size makes them particularly suitable for d.c. supply line filtering and low power switching regulator applications<BR/>Operating temperature: -25 → +70°C<BR/>Height 45mm, Dia. 7.2mm, Lead Dia. 0.6mm

Murata 22R Series Radial Inductor Resin coated miniature general purpose radial wire ended RF inductors<BR/>Their small size makes them particularly suitable for d.c. supply line filtering and low power switching regulator applications<BR/>Operating temperature: -25 → +70°C<BR/>Height 45mm, Dia. 7.2mm, Lead Dia. 0.6mm

10.2mm 3-Digit, Two-wire AC Line Frequency Monitor Self-powered; no external supply required<BR/>Large easily readable LED display<BR/>Reads true line frequency to ±0.1Hz<BR/>Screw terminal connection<BR/>Epoxy encapsulated for harsh environments<BR/>Dimensions: H22.4 x W35.1 x D25.4mm<BR/>Panel cut-out: 33.9 x 21.3mm

Murata Power Solutions Multi-Function Meter The Murata power solutions self-powered, process indicator has a super-low loop drop that keeps its nominal loop resistance (burden) less than 100Ohms. All operating power is derived solely from the 4mA to 20mA loop current. This eliminates the need for a separate power source. The simple 2-wire hook-up allows the device to be connected anywhere in the loop. Features and Benefits Unipolar, bipolar and positive reading models<BR/>Sub miniature package with less than 0.90in behind-the-panel depth<BR/>Large, 0.37in/9.4mm high, sunlight-viewable LCD display<BR/>Non-interacting gain (span) and offset (zero) 20-turn potentiometers<BR/>DIP-switch selectable range and decimal points<BR/>Hundreds of different input/readout combinations<BR/>Vibration-resistant package reliable screw-terminal input connections<BR/>Cut-out height of 21.29mm, width of 33.93mm and depth of 21.29mm<BR/>Number of digits are 3.5<BR/>Digit height is 9.4 mm<BR/>Operating temperature ranges between 0°C and 60°C Certifications ANSI/ESD S20.20:2014 <BR/>BS EN 61340-5-1:2007<BR/>IP65 rated

13.2mm, 4.5 Digit LED Meter DIP switch selectable range, offset and decimal points<BR/>Non-interacting span (gain) and zero (offset) 20 turn potentiometers<BR/>Screw terminal connections

Murata 3W SIP Single Output Regulated Isolated DC-DC Converter - NCS3 Series The Murata PS NCS3 series of DC/DC converters offers single output voltage from input voltage ranges of 9-36V and 18-75V. This power converter is housed in an industry standard package with a standard pinout. The DC/DC converter is encapsulated for superior thermal performance. Applications of the NCS3 isolated DC-DC power supplies include telecommunications, battery powered systems, process control and distributed power systems. 4:1 Wide range voltage input<BR/>Operating temperature range -40°C to 85°C with derating<BR/>1.5 k Vdc Isolation<BR/>3.3V, 5V, 12 and 15V outputs<BR/>No electrolytic capacitors<BR/>Continuous short circuit protection

Murata 22R Series Radial Inductor Resin coated miniature general purpose radial wire ended RF inductors<BR/>Their small size makes them particularly suitable for d.c. supply line filtering and low power switching regulator applications<BR/>Operating temperature: -25 → +70°C<BR/>Height 45mm, Dia. 7.2mm, Lead Dia. 0.6mm

Murata 1400 Series High Current Radial Inductors Designed for use in power line applications such as switching regulators, filters and suppression circuits<BR/>Constructed from high saturation flux density material enabling use in high current applications<BR/>Suitable for PCB or chassis mounting using a non-magnetic fastener via the central fixing hole<BR/>Terminated with easy-strip pre-tinned enamelled copper leads<BR/>Lead length 10mm<BR/>Operating temperature: -40 → +85°C<BR/>Inductance Tolerance: ±10%

Murata 22R Series Radial Inductor Resin coated miniature general purpose radial wire ended RF inductors<BR/>Their small size makes them particularly suitable for d.c. supply line filtering and low power switching regulator applications<BR/>Operating temperature: -25 → +70°C<BR/>Height 45mm, Dia. 7.2mm, Lead Dia. 0.6mm

Murata 1400 Series High Current Radial Inductors Designed for use in power line applications such as switching regulators, filters and suppression circuits<BR/>Constructed from high saturation flux density material enabling use in high current applications<BR/>Suitable for PCB or chassis mounting using a non-magnetic fastener via the central fixing hole<BR/>Terminated with easy-strip pre-tinned enamelled copper leads<BR/>Lead length 10mm<BR/>Operating temperature: -40 → +85°C<BR/>Inductance Tolerance: ±10%
