NISSEI Polyester Capacitor The NISSEI MMT series, 2.2μF is a through-hole mount polyester capacitor. It has a voltage rating of 63VDC. Features and Benefits • Auto insertion<BR/>• Insulation resistance is 1000mohm<BR/>• Lead pitch is 5mm<BR/>• Miniature size<BR/>• Operating temperature ranges between -40°C and 85°C<BR/>• Tolerance is ±5% Applications • General-purpose<BR/>• Substitution for ECQV Certifications • ANSI/ESD S20.20:2014<BR/>• BS EN 61340-5-1:2007

NISSEI Polyester Capacitor The NISSEI MMT series, 220nF is a through-hole mount polyester capacitor. It has a voltage rating of 63VDC. Features and Benefits • Auto insertion<BR/>• Insulation resistance is 3000mohm<BR/>• Lead pitch is 5mm<BR/>• Miniature size<BR/>• Operating temperature ranges between -40°C and 85°C<BR/>• Tolerance is ±5% Applications • General-purpose<BR/>• Substitution for ECQV Certifications • ANSI/ESD S20.20:2014<BR/>• BS EN 61340-5-1:2007

Smaller version of MMC type.<BR/>Highly reliable because of its self-healing performance.<BR/>Uniform flame-retardant epoxy resin coating through the latest resin technology. This provides miniature size and light weight.<BR/>Miniature size<BR/>General purpose application

NISSEI Polyester Capacitor The NISSEI AMZ series, 2.2nF is a through-hole mount polyester capacitor. It has a voltage rating of 50VDC. Features and Benefits • Auto insertion<BR/>• Insulation resistance is 30000mohm<BR/>• Lead pitch is 3.5mm<BR/>• Operating temperature ranges between -40°C and 85°C<BR/>• Small allowance in the lead pitch dimensions<BR/>• Small size, in H dimension that is advantageous to save space of PCB<BR/>• Tolerance is ±5% Applications • general-purpose<BR/>• Industrial<BR/>• Snubber circuits Certifications • ANSI/ESD S20.20:2014<BR/>• BS EN 61340-5-1:2007

NISSEI Polyester Capacitor The NISSEI MMT series, 330nF is a through-hole mount polyester capacitor. It has a voltage rating of 50VDC. Features and Benefits • Auto insertion<BR/>• Insulation resistance is 3000mohm<BR/>• Lead pitch is 5mm<BR/>• Miniature size<BR/>• Operating temperature ranges between -40°C and 85°C<BR/>• Tolerance is ±5% Applications • General applications<BR/>• Substitution for ECQV Certifications • ANSI/ESD S20.20:2014<BR/>• BS EN 61340-5-1:2007

Smaller version of MMC type.<BR/>Highly reliable because of its self-healing performance.<BR/>Uniform flame-retardant epoxy resin coating through the latest resin technology. This provides miniature size and light weight.<BR/>Miniature size<BR/>General purpose application

Standardized 5.0 mm lead spacing from 0.01 to 1.0 μF and available both in lead formed type and straight lead type for auto insertion<BR/>Miniature size<BR/>General purpose application<BR/>Substitution for ECQV

Very small size, especially in H dimension, which is advantageous to save space of PC Board.<BR/>Good reputations for use in general and industrial application.<BR/>Small allowance in the lead pitch dimensions.<BR/>Suitable for automatic insertion due to their small size and light weight.<BR/>General purpose application<BR/>Snubber circuits

NISSEI Polyester Capacitor The NISSEI MMT series, 470nF is a through-hole mount polyester capacitor. It has a voltage rating of 50VDC. Features and Benefits • Auto insertion<BR/>• Insulation resistance is 1000ohm<BR/>• Lead pitch is 5mm<BR/>• Miniature size<BR/>• Operating temperature ranges between -40°C and 85°C<BR/>• Tolerance is ±5% Applications • General applications<BR/>• Substitution for ECQV Certifications • ANSI/ESD S20.20:2014<BR/>• BS EN 61340-5-1:2007

NISSEI Polyester Capacitor The NISSEI MMT series, 10nF is a through-hole mount polyester capacitor. It has a voltage rating of 63VDC. Features and Benefits • Auto insertion<BR/>• Insulation resistance is 3000mohm<BR/>• Lead pitch is 5mm<BR/>• Miniature size<BR/>• Operating temperature ranges between -40°C and 85°C<BR/>• Tolerance is ±5% Applications • General-purpose<BR/>• Substitution for ECQV Certifications • ANSI/ESD S20.20:2014<BR/>• BS EN 61340-5-1:2007

Smaller version of MMC type.<BR/>Highly reliable because of its self-healing performance.<BR/>Uniform flame-retardant epoxy resin coating through the latest resin technology. This provides miniature size and light weight.<BR/>Miniature size<BR/>General purpose application

NISSEI Polyester Capacitor The NISSEI AMZ series, 150pF is a through-hole mount polyester capacitor. It has a voltage rating of 50VDC. Features and Benefits • Auto insertion<BR/>• Insulation resistance is 30000mohm<BR/>• Lead pitch is 3.5mm<BR/>• Operating temperature ranges between -40°C and 85°C<BR/>• Small allowance in the lead pitch dimensions<BR/>• Small size, in H dimension that is advantageous to save space of PCB<BR/>• Tolerance is ±5% Applications • general-purpose<BR/>• Industrial<BR/>• Snubber circuits Certifications • ANSI/ESD S20.20:2014<BR/>• BS EN 61340-5-1:2007
