The Renesas Electronics 5 V powered RS-485 transceivers features high output drive and high EFT and ESD protection. It possess less than 125 μA bus input currents therefore represent a true 1/8 unit load. It includes half and full-duplex transceivers with active high driver which enable pins and active low receiver enable pins. Hot plug capability<BR/>115 kbps supported data rate<BR/>1 Mbps supported data rate<BR/>20Mbps supported data rate

The Renesas Electronics 2-output very low-power clock generator for PCIe gen 1, 2, 3 and 4 common clocked applications. The device has 2 output enables for clock management and supports 2 different spread spectrum levels in addition to spread off. Programmable slew rate for each output<BR/>Allows tuning for various line lengths<BR/>LP-HCSL differential clock outputs

The Renesas Electronics zero-delay buffer supports PCIe Gen1 and Gen2 clocking requirements. It is driven by a differential SRC output pair from an IDT main clock generator. It attenuates jitter on the input clock and has a selectable PLL bandwidth to maximize performance in systems with or without spread-spectrum clocking. SMBus Interface<BR/>Cycle-to-cycle jitter < 50ps<BR/>Output-to-output skew < 50 ps

The Renesas Electronics eight output differential buffer for PCIE gen1 and gen2 is compatible with intel differential buffer specification. This buffer provides 8 PCI-Express Gen2 clocks. It is driven by a differential output pair of main clock generator. Supports zero delay buffer mode and fan out mode<BR/>Bandwidth programming available

The Renesas Electronics clock buffer is a low skew, single input to ten output, clock buffer. It has best in class additive phase jitter of sub 50 fsec. Advanced, low power CMOS process<BR/>Extended temperature range -40°C to +105°C

The Renesas Electronics octal transceiver with non-inverting open drain bus compatible outputs in both send and receive directions. The B bus outputs are capable of sinking 64mA providing very good capacitive drive characteristics. These octal bus transceivers are designed for asynchronous two-way communication between data buses. The control function implementation allows for maximum flexibility in timing. Low input and output leakage ≤1μA<BR/>CMOS power levels<BR/>Power off disable outputs permit live insertion

The Renesas Electronics a 1-to-1 differential-to-LVCMOS/ LVTTL translator of high performance clock solutions from IDT. The differential input is highly flexible and can accept the following input types like LVPECL, LVDS, LVHSTL, SSTL, and HCSL. The small 8-lead SOIC footprint makes this device ideal for use in applications with limited board space. Differential CLK/nCLK input pair<BR/>-40°C to 85°C ambient operating temperature

The Renesas Electronics a low-cost buffer designed to distribute high-speed clocks in mobile PC systems and desktop PC systems. . It is designed for low EMI and power optimization and consumes less than 32mA at 66.6MHz, making it ideal for the low power requirements of mobile systems. One input to five output buffer/driver<BR/>Output-output skew < 250ps<BR/>High drive capability<BR/>Available in SOIC package

The Renesas Electronics high-performance LVCMOS clock buffer supports a synchronous glitch-free output enable function to eliminate any potential intermediate incorrect output clock cycles when enabling or disabling outputs. It has industry-leading low jitter and extremely low current consumption, making it ideal for smart mobile devices. Industrial -40 °C to +105 °C temperature range<BR/>Small 10-pin, 16-pin and 20-pin packages available<BR/>One input

The Renesas Electronics high-performance LVCMOS clock buffer supports a synchronous glitch-free output enable (OE) function to eliminate any potential intermediate incorrect output clock cycles when enabling or disabling outputs. Integrated serial termination for 50Ω channel<BR/>Very low pin-to-pin skew < 50ps<BR/>Very low additive jitter < 50fs<BR/>Industrial (-40°C to +85°C) and extended (-40°C to +105°C) temperature ranges

The Renesas Electronics high-performance LVCMOS clock buffer supports a synchronous glitch-free output enable (OE) function to eliminate any potential intermediate incorrect output clock cycles when enabling or disabling outputs. Integrated serial termination for 50Ω channel<BR/>Very low pin-to-pin skew < 50ps<BR/>Very low additive jitter < 50fs<BR/>Industrial (-40°C to +85°C) and extended (-40°C to +105°C) temperature ranges

The Renesas Electronics Unity-Gain stable operational amplifier is a high speed, low power, low cost monolithic operational amplifier. High slew rate 300V/μs<BR/>Low cost, enhanced replacement for the EL2044<BR/>Pb-free
