The Samtec FTM-103-02-F-DV is a FTM series micro terminal strip. It has flexible positions up to 100 I/O's. This strip has a Micro low profile header. Terminal material: phosphor bronzeCurrent rating :2.8A per pinOperating temp range:-55°C to +125°C

.100" (2.54 mm) pitchIndividually shrouded contactsSingle or double rowVertical, right-angle and right-angle elevated through-holeVertical and horizontal surface mountCurrent rating to 3.8A @ 95°C

Rugged Edge Rate® contactSingle-ended and differential pairsCard slot: .062" (1.60 mm)Pass-through option available (HSEC8-PE)Optional board locks and cable latching featuresOptional weld tab for mechanical strengthSamtec 28+ Gbps SolutionExtended Life Product™ (E.L.P.™)

The Samtec offers cable connectors with bayonet, threaded, and push-on coupling features available for a wide variety of industry standard cables. The high-frequency cable connectors are manufactured with a precise tolerance interface to ensure superior repeatability and high mechanical stability. 2.92 mm precision RF cable connectors

The Samtec 160 position connector with center strip contacts surface mount gold. Number of Positions 160 Pitch 0.020" (0.50mm) Number of Rows 2 Mounting Type Surface Mount Features Pick and Place

The Samtec connector header is through hole mount with 20 position. Pitch: .100" (2.54 mm)Contact System: .025" (0.635 mm) square postOrientation: Vertical, right-angleTermination: Through-holeApplication: Industry's largest variety of standard pin counts, terminal lengths and optionsSpecial Features: Many options fo

The Samtec SSQ series PCB through hole board-to-board has solder tailed socket strip with a 2.54mm pitch, a black, liquid crystal polymer insulator and phosphor bronze Tiger Buy contact. It has 40 contact with current rating 4.7 A per pin. Standard and low insertion force contact with standard solder tailVoltage rating 465 VAC / 655 VDC

The Samtec SSQ series PCB through hole board-to-board has solder tailed socket strip with a 2.54mm pitch, a black, liquid crystal polymer insulator and phosphor bronze Tiger Buy contact. It has 6 contact with current rating 4.7 A per pin. Standard and low insertion force contact with standard solder tailVoltage rating 465 VAC / 655 VDC

The Samtec SSQ series PCB through hole board-to-board square post has square tailed socket strip with a 2.54mm pitch, a black, liquid crystal polymer insulator and phosphor bronze Tiger Buy contact with matte tin plating on the contact. It has 40 contact Standard and low insertion force contact with .025" (0.635 mm) square tail for self-nesting applicationVoltage rating 465 VAC / 655 VDC

The Samtec SSW series consist of through hole SQ post socket. It has Tiger Buy™ contact system whereas it is having phosphor bronze contact material. Current rating:4.7A per pin(2 pins powered)Normal force: standard= 125grams (4.4N)Max cycles:100 with 10μ" (0.25μm) Voltage rating:465VAC/655VDC

The Samtec SSW series consist of through hole SQ post socket. It has Tiger Buy™ contact system whereas it is having phosphor bronze contact material. Current rating:4.7A per pin(2 pins powered)Normal force: standard= 125grams (4.4N)Max cycles:100 with 10μ" (0.25μm) Voltage rating:465VAC/655VDC

Through Hole 2.54mm Square Post Socket Strips with Solder Tail - SSW Series SSW series PCB through hole board-to-board square post, solder tailed socket strips with a 2.54mm pitch and a black, liquid crystal polymer insulator. The Tiger Buy contacts of these 2.54mm PCB through hole sockets are made from phosphor bronze with 0.51μm gold plating on the contact and gold flash on the tail (apart from stock numbers 765-5739 and 765-5786 which have matte tin contacts). These PCB board to board 2.54mm through hole square post socket strips are available in a variety of configurations including single and double row, straight and right angle and an option of post lengths. The operating temperature range for these SSW series PCB through hole sockets is -55 to 125°C for gold plated versions and -55 to 105°C for matte tin versions.SSW PCB sockets with part number TSW-xxx-01-x-x have a tail length of 2.64mm.SSW PCB sockets with part number TSW-xxx-02-x-x have a tail length of 4.93mm.
