SEGGER Microcontroller J-Trace The SEGGER Microcontroller KG J-Trace is an isolator. It can be connected between a J-Trace Pro V2 or any ARM-board that uses the standard 19-pin Cortex-M connector to provide electrical isolation while keeping high-speed peed trace capabilities. This is essential when the development tools are not connected to the same ground. It is useful to protect the development tools from electrical spikes that often occur in some applications. Features and Benefits: &#149; 1 kV DC isolation<BR/>&#149; 3 LEDs to indicate emulator power, target power and target RESET<BR/>&#149; ETM trace pins fully supported up to 75MHz trace clock<BR/>&#149; JTAG frequency: up to 50MHz<BR/>&#149; JTAG standard 19-pin connection supporting TDI, TMS, TCK, TDO, RESET and SWD/SWO signals<BR/>&#149; Powered from an emulator, a few microamps (<25μA) drawn from a target<BR/>&#149; SWD frequency: up to 4MHz

SEGGER Microcontroller Adapter The SEGGER Microcontroller adapter is J-Trace MICTOR 38 adapter that connects to the 38-pin MICTOR connector. It connects the GND, JTAG and some trace pins to their counterparts on the 19-pin Cortex-M connector. This side of the adapter can be plugged either directly into the target side or via trace cable. It connects to J-Trace via half-pitch flat cable. This is applicable for Cortex-M Connector, MICTOR connector.

SEGGER J-Trace Pro Cortex The SEGGER J-Trace pro cortex is a high-speed hardware trace probes for use with Cortex-A/M/R based microcontrollers. The super-speed USB 3.0 interface of J-trace pro cortex allows continuous streaming trace via USB with the full trace clock, lifting the limitations by internal buffers. Features and Benefits: &#149; Full J-link debug functionality<BR/>&#149; Isolate and identify hard-to-find code defects with unlimited trace<BR/>&#149; No power supply required (powered through USB)<BR/>&#149; Real-time streaming at a full system clock<BR/>&#149; Satisfy regulatory requirements with instruction-level code coverage<BR/>&#149; Tune your application with live profiling<BR/>&#149; Unlimited flash breakpoints information Applications: &#149; Electronics industry<BR/>&#149; Embedded programming Certifications: &#149; ANSI/ESD S20.20:2014<BR/>&#149; BS EN 61340-5-1:2007

J-Link BASE Probe <B>J-Link BASE</B> is a JTAG programming and debug probe supporting a large number of processor cores. J-Link is supported by all major IDEs such as IAR EWARM, Keil MDK, Rowley CrossWorks, Atollic TrueSTUDIO, IAR EWRX, Renesas HEW, Renesas e2studio, and many others. Supported Processors • ARM7/9/11, Cortex-A5/A7/A8/A9, Cortex-M0/M1/M3/M4/M7, Cortex-R4/R5<BR/>• Microchip PIC32<BR/>• Renesas RX100/RX200/RX610/RX621/RX62N/RX62T/RX630/RX631/RX63N Features • Direct download into Flash memory of most microcontrollers supported<BR/>• Download speed up to 1MB/second<BR/>• Supports unlimited breakpoints in Flash memory<BR/>• Supports breakpoints in external Flash memory of Cortex-M systems<BR/>• Supports concurrent access to CPU by multiple applications<BR/>• GDB Server included: allows using J-Link remotely via TCP/IP<BR/>• Supports multiple target interfaces: JTAG, SWD<BR/>• Supports SWV/SWO (Serial Wire Viewer / Serial Wire Output)<BR/>• Wide target voltage range: +1.2V to +3.3V, +5V tolerant<BR/>• Supports JTAG chains with multiple devices<BR/>• Embedded Trace Buffer (ETB) support<BR/>• Various target adapters and optical isolation adapters available<BR/>• Powered via USB connector<BR/>• Support for adaptive clocking<BR/>• All JTAG signals can be monitored, target voltage can be measured<BR/>• Target power supply: 300mA with overload protection<BR/>• Target interface: JTAG 20-pin<BR/>• PC interface: USB 2.0<BR/>• Dimensions: 100 x 53 x 27mm<BR/>• Cross-platform support (runs on Windows, Linux, Mac OS X)<BR/>• Supported by all major IDEs<BR/>• Software Developer Kit (SDK) available<BR/>• Free software updates, 1 year of support Target Adapters & Adapter Cables • <a href="/web/p/products/1311325">131-1325</a> J-Link Target Power Supply Adapter<BR/>• <a href="/web/p/products/1311326">131-1326</a> J-Link 10-pin Needle Adapter<BR/>• <a href="/web/p/products/1311327">131-1327</a> J-Link RX100/200/600 MCU Adapter<BR/>• <a href="/web/p/products/1311328">131-1328</a> J-Link 19-pin ARM Cortex-M MCU Adapter<BR/>• <a href="/web/p/products/1311329">131-1329</a> J-Link 9-pin ARM Cortex-M MCU Adapter<BR/>• <a href="/web/p/products/1311330">131-1330</a> J-Link 14-pin ARM 7/9/11 MCU Adapter Link Isolator Boards • <a href="/web/p/products/1311335">131-1335</a> J-Link ARM JTAG Isolator Board<BR/>• <a href="/web/p/products/1311336">131-1336</a> J-Link ARM SWD Isolator Board<BR/>• <a href="/web/p/products/1311337">131-1337</a> J-Link USB Isolator Board

Flasher ARM Programmer The<B> Flasher ARM</B> is a programming tool for microcontrollers with on-chip or external Flash memory and an ARM core. Flasher ARM is designed for programming Flash targets with the J-Flash software or stand-alone. In addition, Flasher ARM has all of the J-Link functionality. Supported Processors • ARM Cortex-A: A5/A7/A8/A9/A12/A15/A17<BR/>• ARM Cortex-M: M0/M0+/M1/M3/M4/M7<BR/>• ARM Legacy: ARM7, ARM9, ARM11 Features • Stand-alone JTAG/SWD programmer (Once set up, Flasher can be controlled without the use of PC program)<BR/>• 10/100 Ethernet via RJ45 connector<BR/>• Supports internal and external Flash memory devices<BR/>• 64MB memory for storage of target program<BR/>• Serial in target programming supported<BR/>• Data files can be updated as mass storage or via J-Flash<BR/>• Host interface: USB 2.0 or RS-232 DE9 connector<BR/>• Target interface: JTAG/SWD 20-pin<BR/>• Powered through USB connection<BR/>• Can be used as J-Link (JTAG emulator) with download speed up to 1MB/sec<BR/>• Programming speed typically between 30KB/sec and 1MB/sec<BR/>• Max programming speed depends on target hardware and max programming speed of the Flash memory<BR/>• ASCII command interface to control Flasher without use of PC program<BR/>• Authorized Flashing allows limit to number of Flash programming cycles and to protect the Flasher against non-authorized access in case of external production<BR/>• Dimensions: 121 x 66 x 30mm<BR/>• Free software updates, 2 years of support

J-Link PRO Probe <B>J-Link PRO</B> is a JTAG/SWD programming and debug probe supporting a large number of processor cores and comes with integrated licenses for unlimited breakpoints in Flash memory, RDI/RDDI, GDB Server and J-Flash. An Ethernet connection allows use of the debug probe far away from the PC, over a hard-wired or wireless network. Supported Processors • ARM7/9/11, Cortex-A5/A8/A9, Cortex-M0/M1/M3/M4/M7, Cortex-R4/R5<BR/>• Microchip PIC32<BR/>• Renesas RX100/RX200/RX610/RX621/RX62N/RX62T/RX630/RX631/RX63N Features • Direct download into Flash memory of most microcontrollers supported<BR/>• Download speed up to 3MB/sec<BR/>• 10/100 Ethernet via RJ45 socket<BR/>• Web interface for easy TCP/IP configuration (built-in webserver)<BR/>• Supports concurrent access to CPU by multiple applications<BR/>• Automatic core recognition<BR/>• Supports multiple target interfaces: JTAG, SWD<BR/>• Supports SWD/SWV (Serial Wire Debug / Serial Wire Viewer)<BR/>• Supports J-Flash Production Flash programming<BR/>• Maximum target interface speed: 50MHz<BR/>• Maximum SWO sampling speed: 100MHz<BR/>• Wide target voltage range: +1.2V to +5Vdc<BR/>• Embedded Trace Buffer (ETB) support<BR/>• Various target adapters and optical isolation adapters available<BR/>• RDI / RDDI interface<BR/>• Powered via USB connector<BR/>• Support for adaptive clocking<BR/>• All JTAG signals can be monitored, target voltage can be measured<BR/>• Target power supply: 300mA with overload protection<BR/>• Target interface: JTAG/SWD 20-pin<BR/>• PC interface: USB 2.0 HS or Ethernet RJ45 socket<BR/>• Galvanic isolation from host system via Ethernet<BR/>• Power and RESET LEDs<BR/>• Dimensions: 100 x 53 x 27mm<BR/>• Cross-platform support (runs on Windows, Linux, Mac OS X)<BR/>• Memory viewer (J-Mem) included<BR/>• Software Developer Kit (SDK) available<BR/>• Free software updates, 2 years of support Target Adapters & Adapter Cables • <a href="/web/p/products/1311325">131-1325</a> J-Link Target Power Supply Adapter • <a href="/web/p/products/1311326">131-1326</a> J-Link 10-pin Needle Adapter • <a href="/web/p/products/1311327">131-1327</a> J-Link RX100/200/600 MCU Adapter • <a href="/web/p/products/1311328">131-1328</a> J-Link 19-pin ARM Cortex-M MCU Adapter • <a href="/web/p/products/1311329">131-1329</a> J-Link 9-pin ARM Cortex-M MCU Adapter • <a href="/web/p/products/1311330">131-1330</a> J-Link 14-pin ARM 7/9/11 MCU Adapter • <a href="/web/p/products/1311331">131-1331</a> J-Link Microchip PIC32 MCU Adapter Link Isolator Boards • <a href="/web/p/products/1311335">131-1335</a> J-Link ARM JTAG Isolator Board • <a href="/web/p/products/1311336">131-1336</a> J-Link ARM SWD Isolator Board • <a href="/web/p/products/1311337">131-1337</a> J-Link USB Isolator Board

J-Link PLUS Probe <B>J-Link PLUS</B> is a JTAG programming and debug probe supporting a large number of processor cores. J-Link is supported by all major IDEs such as IAR EWARM, Keil MDK, Rowley CrossWorks, Atollic TrueSTUDIO, IAR EWRX, Renesas HEW, Renesas e2studio, and many others. Comes with integrated licenses for unlimited breakpoints in Flash memory, RDI / RDDI and J-Flash. Supported Processors • ARM7/9/11, Cortex-A5/A8/A9, Cortex-M0/M1/M3/M4/M7, Cortex-R4/R5<BR/>• Microchip PIC32<BR/>• Renesas RX100/RX200/RX610/RX621/RX62N/RX62T/RX630/RX631/RX63N Features • Direct download into Flash memory of most microcontrollers supported<BR/>• Download speed up to 1MB/second<BR/>• Supports unlimited breakpoints in Flash memory<BR/>• Supports breakpoints in external Flash memory of Cortex-M systems<BR/>• Supports concurrent access to CPU by multiple applications<BR/>• Remote Server included. Allows using J-Link remotely via TCP/IP<BR/>• GDB Server included<BR/>• Supports J-Flash Production Flash programming<BR/>• Supports multiple target interfaces: JTAG, SWD<BR/>• Supports SWV/SWO (Serial Wire Viewer / Serial Wire Output)<BR/>• Wide target voltage range: +1.2V to +3.3V, +5V tolerant<BR/>• Supports JTAG chains with multiple devices<BR/>• Embedded Trace Buffer (ETB) support<BR/>• Various target adapters and optical isolation adapters available<BR/>• RDI / RDDI interface DLL available<BR/>• Powered via USB connector<BR/>• Support for adaptive clocking<BR/>• All JTAG signals can be monitored, target voltage can be measured<BR/>• Target power supply: 300mA with overload protection<BR/>• Target interface: JTAG 20-pin<BR/>• PC interface: USB 2.0<BR/>• Dimensions: 100 x 53 x 27mm<BR/>• Cross-platform support (runs on Windows, Linux, Mac OS X)<BR/>• Supported by all major IDEs<BR/>• Software Developer Kit (SDK) available<BR/>• Free software updates, 1 year of support Target Adapters & Adapter Cables • <a href="/web/p/products/1311325">131-1325</a> J-Link Target Power Supply Adapter • <a href="/web/p/products/1311326">131-1326</a> J-Link 10-pin Needle Adapter • <a href="/web/p/products/1311327">131-1327</a> J-Link RX100/200/600 MCU Adapter • <a href="/web/p/products/1311328">131-1328</a> J-Link 19-pin ARM Cortex-M MCU Adapter • <a href="/web/p/products/1311329">131-1329</a> J-Link 9-pin ARM Cortex-M MCU Adapter • <a href="/web/p/products/1311330">131-1330</a> J-Link 14-pin ARM 7/9/11 MCU Adapter • <a href="/web/p/products/1311331">131-1331</a> J-Link Microchip PIC32 MCU Adapter Link Isolator Boards • <a href="/web/p/products/1311335">131-1335</a> J-Link ARM JTAG Isolator Board • <a href="/web/p/products/1311336">131-1336</a> J-Link ARM SWD Isolator Board • <a href="/web/p/products/1311337">131-1337</a> J-Link USB Isolator Board

J-Link Target Supply Adapter The <B>J-Link Target Supply Adapter</B> provides an adjustable power supply to a target board. Compatible Probes Segger J-Link BASE Emulator (<a href="/web/p/products/1311319">131-1319)</a>, J-Link PRO, J-Link ULTRA+, J-Link PLUS , Flasher Portable, Flasher ARM Features • MCP1826T LDO voltage regulator<BR/>• Input from J-Link probe via 20-pin 0.1in socket<BR/>• Output to Target via 20-pin 0.1in header<BR/>• Default output: +3.3V @ 400mA<BR/>• Output voltage adjustable from +1.0V @ 150mA to +3.6V @ 400mA by changing resistor<BR/>• Power On LED

J-Link 19-Pin Cortex-M Adapter The <B>J-Link 19-pin Cortex-M Adapter</B> allows JTAG, SWD and SWO connections between J-Link and ARM Cortex-M based target hardware systems. Supported Probes • J-Link BASE <a href="/web/p/products/1311319">131-1319</a>, J-Link PLUS, J-Link PRO, J-Link ULTRA+, J-Link EDU, Flasher ARM, Flasher Portable Features • Input from J-Link probe via 20-pin 0.1in socket<BR/>• Output to Target via 19-pin 0.05in Samtec FTSH connector<BR/>• TRST can be connected to pin 9 of the Cortex-M adapter if required

J-Trace PRO Probe <B>J-Trace PRO for Cortex-M</B> enables continuous streaming trace via its Gigabit Ethernet interface, lifting the limitations of internal buffers and slow data transmission. J-Trace PRO can capture complete traces over long periods - thereby enabling the recording of infrequent, hard-to-reproduce bugs. It also offers extended trace features, such as code coverage and execution profiling. Supported Processors • ARM Cortex-M0/M0+/M1/M3/M4/M7 Features • Supports Streaming Trace (trace data sent to PC/debugger in real time, unlimited trace buffer)<BR/>• Full J-Link functionality<BR/>• Gigabit Ethernet interface via RJ45 socket<BR/>• USB 2.0 HS interface (480MBit/s)<BR/>• Target interface: JTAG/SWD 20-pin, JTAG/SWD + Trace 19-pin<BR/>• JTAG speed: 50MHz<BR/>• Supports Cortex-M devices up to 150MHz ETM trace clock (300MHz CPU clock)<BR/>• Supports ARM Embedded Trace Macrocell (ETM)<BR/>• Supports ARM Embedded Trace Buffer (ETB)<BR/>• Supports ARM Micro Trace Buffer (MTB)<BR/>• 64MB on-board trace buffer for legacy one-shot tracing mode<BR/>• Dimensions: 123 x 68 x 30mm<BR/>• Free software updates, 2 years of support

J-Link 10-Pin Needle Adapter The <B>J-Link 10-pin Needle Adapter</B> has been designed to connect a J-Link Probe to a PCB which does not have a mating connector or programming header. Compatible Probes • J-Link BASE Emulator (<a href="/web/p/products/1311319">131-1319)</a> , J-Link PLUS, J-Link PRO, J-Link ULTRA+, J-Link EDU, Flasher ARM, Flasher Portable Features • No additional connector required on target PCB<BR/>• Very small footprint<BR/>• High-reliability spring pins for secure connections<BR/>• 3 locating pins, so adapter cannot be connected the wrong way round<BR/>• Plugs into probe 20-pin 0.1in J-Link connector<BR/>• No external power supply required<BR/>• Option to power the target hardware via J-Link

J-Link ULTRA+ Probe <B>J-Link ULTRA+</B> is a JTAG/SWD programming and debug probe supporting a large number of processor cores. It features seamless integration into the IAR Embedded Workbench IDE and comes with integrated licenses for unlimited breakpoints in Flash memory, RDI / RDDI and J-Flash. Supported Processors • ARM7/9/11, Cortex-A5/A8/A9, Cortex-M0/M1/M3/M4/M7, Cortex-R4/R5<BR/>• Microchip PIC32<BR/>• Renesas RX100/RX200/RX610/RX621/RX62N/RX62T/RX630/RX631/RX63N Features • Direct download into Flash memory of most microcontrollers supported<BR/>• Download speed up to 3MB/sec<BR/>• Supports unlimited breakpoints in Flash memory<BR/>• Supports breakpoints in external Flash memory of Cortex-M systems<BR/>• Supports concurrent access to CPU by multiple applications<BR/>• Remote Server included. Allows using J-Link remotely via TCP/IP<BR/>• Automatic core recognition<BR/>• Supports SWD/SWV (Serial Wire Debug / Serial Wire Viewer)<BR/>• Supports J-Flash Production Flash programming<BR/>• Maximum target interface speed: 50MHz<BR/>• Maximum SWO sampling speed: 100MHz<BR/>• Wide target voltage range: +1.2V to +3.3V, +5V tolerant<BR/>• Embedded Trace Buffer (ETB) support<BR/>• Various target adapters and optical isolation adapters available<BR/>• RDI / RDDI interface<BR/>• Powered via USB connector<BR/>• Support for adaptive clocking<BR/>• All JTAG signals can be monitored, target voltage can be measured<BR/>• Target power supply: 300mA with overload protection<BR/>• Target interface: JTAG/SWD 20-pin<BR/>• PC interface: USB 2.0 HS<BR/>• Dimensions: 100 x 53 x 27mm<BR/>• Cross-platform support (runs on Windows, Linux, Mac OS X)<BR/>• Flash DLL available<BR/>• Software Developer Kit (SDK) available<BR/>• Free software updates, 1 year of support Target Adapters & Adapter Cables • <a href="/web/p/products/1311325">131-1325</a> J-Link Target Power Supply Adapter • <a href="/web/p/products/1311326">131-1326</a> J-Link 10-pin Needle Adapter • <a href="/web/p/products/1311327">131-1327</a> J-Link RX100/200/600 MCU Adapter • <a href="/web/p/products/1311328">131-1328</a> J-Link 19-pin ARM Cortex-M MCU Adapter • <a href="/web/p/products/1311329">131-1329</a> J-Link 9-pin ARM Cortex-M MCU Adapter • <a href="/web/p/products/1311330">131-1330</a> J-Link 14-pin ARM 7/9/11 MCU Adapter • <a href="/web/p/products/1311331">131-1331</a> J-Link Microchip PIC32 MCU Adapter Link Isolator Boards • <a href="/web/p/products/1311335">131-1335</a> J-Link ARM JTAG Isolator Board • <a href="/web/p/products/1311336">131-1336</a> J-Link ARM SWD Isolator Board • <a href="/web/p/products/1311337">131-1337</a> J-Link USB Isolator Board
