SOCOMEC industrial fuses protect installations and people from overcurrents for any low voltage electrical circuit. High level performances:High breaking capacity - 120 kA at 400/500 V, 80 kA at 690 V. High short-circuit limitation capacity. Simple and reliable discrimination.High reliability:Absolute protection over time guaranteed by the simplicity of manufacture and function (Joule effect). No downgrading of fuse characteristics over time.Improved safety:The energy released whilst eliminating the fault (fuse blowing) is contained within the cartridge (no degassing).

The Socomec ferromagnetic voltmeter measure the AC voltage of any electrical circuit. It can be embedded in the front panel of cabinets, enclosures or other equipment. 90° pointer deflection0 to 250 V rating

Shafts for External Handles Shafts and shaft guides for use with external operation handles on the Socomec Sirco M switch disconnectors. Shaft guides are used to guide the shaft extension into the external handle, enabling the handle to engage the extension shaft with a misalignment of up to 15mm.

The Socomec's ITYS PE series is a 2000 VA UPS true online double conversion technology (VFI) assures high availability and total load protection. Compatible with different applications, operating environments and generator sets and comes with RS232, USB, Dry contact communication options. Embedded dry-contact interfaceInput mains switch breakerConnection for battery extension modulesPower off the UPS remotelyInternal temperature sensorCompact tower UPS system saves space in the operating environment.

DIRIS Digiware D-40, D-50 and D-70 DIRIS Digiware D remote displays allow:• a local view of the data from DIRIS Digiware modules, • a power supply to the DIRIS Digiware modules, • access to this data over Ethernet (D-50/D-70) or RS485 (D-40). DIRIS Digiware D-50 and D-70 displays also act as a gateway, centralising measurements from DIRIS Digiware, DIRIS A, DIRIS B and COUNTIS E devices and making them available over Ethernet.With the DIRIS Digiware D-70 display, data can be visualized on WEBVIEW-M, the "Power & Energy monitoring" embedded web server.DIRIS Digiware screens are 24 VDC powered. Advantages of DIRIS Digiware D • High-resolution graphic screen• Embedded web server (DIRIS Digiware D-70)• Multi-protocols (Modbus, BACnet, SNMP)• 24 VDC SELV (Safety Extra Low Voltage) power supply elimination of hazardous voltage on cabinet doors.• Ergonomic and easy to use with 10 direct access buttons for:- measurement information,- output selection,- equipment configuration.• Centralising measurement points:- circuit selection,- displaying dataIRIS Digiware D

Non-Fusible Disconnect Switches SIRCO M SIRCO M is a range of multipolar, modular and manually operated switch-disconnectors (or load break switches).Available in 3 or 4 poles and from 16 to 125A, they make and break under load conditions and provide safety isolation for any low voltage circuit, particularly for machine control circuits.Through the use of accessories, SIRCO M can be transformed into multipolar load break or 3/4 pole changeover switches. SIRCO M changeover switches provide on load changeover switching between two sources or two low voltage power circuits, as well as their safety isolation. Features & Benefits: - Complies with international standards IEC 60947-3, UL508 and UL98.- Double break per pole.- Mounting options: DIN rail, panel or modular panel with 45 mm front cut out.- IP20 devices and accessories. - Severe utilisation categories (AC-22 and AC-23).- Positive break indication.- Contact point technology.- Product can be mounted directly on the door or panel side, with a specific "Door mounting kit" accessory. *

Fused Switch Disconnectors - External Front and Right Side Operation The fuserbloc series are manually operated multi polar fuse combination switches. These fused switch disconnectors break or switch off on load and provide safety isolation and protection against over current for any low voltage electrical circuit. The fuserbloc series is available in 3 or 4 poles with external front and right side operation from 50 to 400 A. NFC, DIN or BS88 fuseFully visualised breakingDouble break by phase (top and bottom of fuse)Compact designProtection against overcurrent by fuse circuit breakersTest position for testing control circuits

The Socomec Door mounting kit has 6/8P probe and steel support. This kit enables a direct mounting of the switch on the door panel, on the right or left side of the panel. The connection clamps of the switch are always accessible. The external handle is quick and easy to install with the supplied internal locking nut mounted on the inside of the enclosure

The Socomec manually operated multipolar fuse combination switches. They make and break on load and provide safety isolation and protection against overcurrent for any low voltage electrical circuit. Improved safetyHigh breaking capacityPositive break indicationProtection against overloads and short-circuits thanks to high breaking capacity fusesMechanical or electronic fuse melting detection system

FUSERBLOC are manually operated multipolar fuse combination switches. They make and break on load and provide safety isolation and protection against overcurrent for any low voltage electrical circuit. Improved safety:Complete isolation of the fuse with double breaking per pole (top and bottom of fuse).Positive break indication. High breaking capacity:Protection against overloads and short-circuits thanks to high breaking capacity fuses (100 kA rms). Specific functionalities for simplified useTEST position for testing control circuits without energising the power poles using U-type auxiliary contacts. In TEST position, the enclosure door can be opened. Mechanical or electronic fuse melting detection system.

Fused Switch Disconnectors - Direct Operation The fuserbloc series are manually operated multi polar fuse combination switches. These fused switch disconnectors break or switch off on load and provide safety isolation and protection against over current for any low voltage electrical circuit. The fuserbloc series is available in 3 or 4 pole with direct operation from 20 to 32 A. NFC, DIN or BS88 fuseFully visualised breakingDouble break by phase (top and bottom of fuse)Compact designProtection against overcurrent by fuse circuit breakersTest position for testing control circuits

The Socomec 4 pole modular manual transfer switch with visible breaking. It provides on load transfer between two sources for any low voltage power circuit, as well as safety isolation. Other applications include source inversion and grounding or earthing. Enables completely secure isolation owing positive break indication and double visible breakingCurrent rating is 63 ACan be fixed to a DIN rail, a backplate or a modular panel
