Multi Contact Panel Mount Socket – SLB4-G The Multi Contact black, female socket is a 4mm connector for joining wires to electronic equipment. It is equipped with spring-loaded plugs with a rigid insulating sleeve. The socket is screwed into predrilled panels of plastic, metal, and other materials. It has a voltage rating of 1kV and current rating of 32A. Features and Benefits Solder termination<BR/>Gold contact plating and brass contact material<BR/>Compatible with shrouded plugs and leads<BR/>Termination style: M4 15mm stud with soldering hole<BR/>Length is 38.5mm<BR/>Includes nuts and washers for clamping wire or ring terminals<BR/>Panel mounting hole diameter is 12mm<BR/>1000 V, CAT III, 32 A Applications These 4 mm connectors are popular as they can be connected and disconnected quickly and provide a high-quality connection in many applications such as:<BR/>Automotive (car manufacturing plant equipment)<BR/>Motorsports<BR/>Aeronautics (plant equipment) Certifications ANSI/ESD S20.20:2014<BR/>BS EN 61340-5-1:2007<BR/>UL approved Colours available in this SLB4-G series include:<BR/><a href="/web/p/products/404200">404-200</a> – black<BR/><a href="/web/p/products/404244">404-244</a> – red<BR/><a href="/web/p/products/404216">404-216</a> – blue<BR/><a href="/web/p/products/404266">404-266</a> – yellow<BR/><a href="/web/p/products/404222">404-222</a> – green<BR/><a href="/web/p/products/1229695">122-9695</a> – brown<BR/><a href="/web/p/products/1229696">122-9696</a> – grey<BR/><a href="/web/p/products/404250">404-250</a> – white

2 mm test leads Leads featuring a stackable 2 mm banana plug at each end.<BR/>Made of extra-flexible silicone wire.

Multi Contact Socket – Red Female Banana Socket SLB4-F This Multi Contact red, female socket is a 4mm connector and is used for joining wires to electronic equipment. This multi contact socket is equipped with spring-loaded plugs with a rigid insulating sleeve. The female socket can be screwed into predrilled panels of plastic, metal and other materials and it has a voltage rating of 1kV and current rating of 24A Features and Benefits Tab termination<BR/>Gold contact plating and brass contact material<BR/>Length is 31.5 mm<BR/>1000 V, CAT III, 24 A<BR/>Flat connecting tab 4.8 mm x 0.8 mm<BR/>Panel Mount socket Applications These 4 mm cylindrical connectors are popular as they can be connected and disconnected quickly and provide a high-quality connection in many applications such as:<BR/>Automotive (car manufacturing plant equipment)<BR/>Motorsports<BR/>Aeronautics (plant equipment) Certifications ANSI/ESD S20.20:2014<BR/>BS EN 61340-5-1:2007 Colours available in this series include:<BR/><a href="/web/p/products/404137">404-137</a> – Black 23.3000-21<BR/><a href="/web/p/products/404171">404-171</a> – Red 23.3000-22<BR/><a href="/web/p/products/404143">404-143</a> – Blue 23.3000-23<BR/><a href="/web/p/products/2306316">230-6316</a> – Yellow 23.3000-24<BR/><a href="/web/p/products/404159">404-159</a> - Green 23.3000-25<BR/><a href="/web/p/products/8935743">893-5743</a> - Violet 23.3000-26<BR/><a href="/web/p/products/163192">163-192</a> - Brown 23.3000-27<BR/><a href="/web/p/products/163198">163-198</a> - Grey 23.3000-28<BR/><a href="/web/p/products/404187">404-187</a> - White 23.3000-29

Multi-Contact XELW-4 Series 4 mm Angled Socket Connectors, PCB mount Multi-Contact 4 mm right angled socket connectors are pcb mount connectors complete with a rigid socket, designed to accept spring loaded (multilam) plugs with a rigid insulating sleeve, available in red or black and featuring a 2 mm central pcb contact and 4 x 0.8 mm board mount pins. 1000V ,CAT III 24 A

Multi Contact Socket The Multi Contact blue, female socket is a 4mm connector. It is equipped with spring-loaded plugs with a rigid insulating sleeve. The socket is screwed into predrilled panels of plastic, metal and more. It has a voltage rating of 1kV and current rating of 32A. Features and Benefits Solder termination<BR/>Gold contact plating and brass contact material<BR/>Compatible with shrouded plugs and leads<BR/>Termination style: M4'15mm stud with soldering hole<BR/>Length is 38.5mm<BR/>Includes nuts and washers for clamping wire or ring terminals panel mounting hole diameter is 12mm Applications Automotive (car manufacturing plant equipment)<BR/>Motorsports<BR/>Aeronautics (plant equipment) Certifications ANSI/ESD S20.20:2014<BR/>BS EN 61340-5-1:2007<BR/>UL approved

Socket - Studded, CAT III - SLB4-G Series Compatible with shrouded plugs and leads<BR/>Termination style: M4x15mm stud with soldering hole<BR/>Includes nuts and washers for clamping wire or ring terminals; Panel mounting hole dia. 12mm<BR/>32A Current rating<BR/>Panel cut out M12 x 0.75mm

Socket - Studded, CAT III - SLB4-G Series Compatible with shrouded plugs and leads<BR/>Termination style: M4x15mm stud with soldering hole<BR/>Includes nuts and washers for clamping wire or ring terminals; Panel mounting hole dia. 12mm<BR/>32A Current rating<BR/>Panel cut out M12 x 0.75mm

Multi Contact Socket The Multi Contact white, female socket is a 4mm connector. It is equipped with spring-loaded plugs with a rigid insulating sleeve. The socket is screwed into predrilled panels of plastic, metal and more. It has a voltage rating of 1kV and current rating of 32A. Features and Benefits Solder termination<BR/>Gold contact plating and brass contact material<BR/>Compatible with shrouded plugs and leads<BR/>Termination style: M4'15mm stud with soldering hole<BR/>Length is 38.5mm<BR/>Includes nuts and washers for clamping wire or ring terminals panel mounting hole diameter is 12mm Applications Automotive (car manufacturing plant equipment)<BR/>Motorsports<BR/>Aeronautics (plant equipment) Certifications ANSI/ESD S20.20:2014<BR/>BS EN 61340-5-1:2007<BR/>UL approved

Multi Contact Socket The Multi Contact red, female socket is a 4mm connector. It is equipped with spring-loaded plugs with a rigid insulating sleeve. The socket is screwed into predrilled panels of plastic, metal and more. It has a voltage rating of 1kV and current rating of 32A. Features and Benefits Solder termination<BR/>Gold contact plating and brass contact material<BR/>Compatible with shrouded plugs and leads<BR/>Termination style: M4'15mm stud with soldering hole<BR/>Length is 38.5mm<BR/>Includes nuts and washers for clamping wire or ring terminals panel mounting hole diameter is 12mm Applications Automotive (car manufacturing plant equipment)<BR/>Motorsports<BR/>Aeronautics (plant equipment) Certifications ANSI/ESD S20.20:2014<BR/>BS EN 61340-5-1:2007<BR/>UL approved

Flexible Plug and Socket Solder termination, gold plated brass with a flexible insulator. 3.5mm Diameter

Flexible Plug and Socket Solder termination, gold plated brass with a flexible insulator. 3.5mm Diameter

Multi Contact Female Banana Plug The Multi Contact black, female banana plug is a 1mm rigid connector. This plug has spring-loaded Multilam for self-assembly of test leads. It has a voltage rating of 30VAC, 60VDC and current rating of 6A. Features and Benefits Solder termination<BR/>Gold plated copper alloy contact material<BR/>Length is 12mm<BR/>Insulation material TPE Applications Automotive (car manufacturing plant equipment)<BR/>Motorsports<BR/>Aeronautics (plant equipment) Certifications ANSI/ESD S20.20:2014 <BR/>BS EN 61340-5-1:2007
