BC Series Plastic Threaded Barrel Turck Banner BC series capacitive sensors with a cylindrical plastic threaded body feature high switching distances. Sensors are available in M12, M18 or M30 with a connection cable or an M12x1 male connector. Excellent reliability<BR/>Automatic wetting compensation<BR/>Excellent EMC properties<BR/>ESD immunity<BR/>Mounting flexibility

BC Series Plastic Threaded Barrel Turck Banner BC series capacitive sensors with a cylindrical plastic threaded body feature high switching distances. Sensors are available in M12, M18 or M30 with a connection cable or an M12x1 male connector. Excellent reliability<BR/>Automatic wetting compensation<BR/>Excellent EMC properties<BR/>ESD immunity<BR/>Mounting flexibility

BC Series Plastic Threaded Barrel Turck Banner BC series capacitive sensors with a cylindrical plastic threaded body feature high switching distances. Sensors are available in M12, M18 or M30 with a connection cable or an M12x1 male connector. Excellent reliability<BR/>Automatic wetting compensation<BR/>Excellent EMC properties<BR/>ESD immunity<BR/>Mounting flexibility

BC Series Smooth Plastic Barrel Turck Banner BC series capacitive sensors with a smooth plastic cylindrical design. Sensors are available in M12, M18 or M30 with a connection cable or an M12x1 male connector. Excellent reliability<BR/>Automatic wetting compensation<BR/>Excellent EMC properties<BR/>ESD immunity<BR/>Mounting flexibility

BC Series Rectangular Body Turck Banner BC series capacitive sensors rectangular design are a compact solution for a wide variety of applications. The rugged housing and high quality components offer simplified assembly and enhance the operability. Stable and resistant housings<BR/>Large switching distances<BR/>Excellent EMC properties<BR/>Easy to mount<BR/>Connector and cable versions

<strong>Turck Proximity Sensor, 10mm Detection Range, 20.3mm Width - BC10 Series - BC10-QF5.5-AP6X2</strong> Keen for a way to detect the presence of objects in your work environment? Turn to this proximity sensor from Turck. It's a capacitive sensor, so it uses an electrical field to detect conductive materials, including metals, non-metals and liquids. When it senses an object in its 10mm detection range, it produces a positive voltage signal and alerts you to the object's presence. LED indicators display the operating status of the sensor, so you can troubleshoot it in a flash. <B>Features & Benefits</B> • IP67 rating indicates that it's dust-tight and protected against submersion in 1m of water for up to 30 minutes<BR/>• Short circuit protection minimises the chance of electrical damage to your equipment<BR/>• Wide operating temperature range between -25°C and +70°C to withstand harsh conditions<BR/>• Compact dimensions of 54 (L) x 20.3 (W) x 5.5mm (D) for installation in tight spaces<BR/>• Cable length of 2m for a flexible connection <strong>Applications</strong> • Avionics<BR/>• Manufacturing plants<BR/>• Process control <strong>What's the housing made from?</strong> The housing is made from PP, which is resistant to heat, wear and chemicals for durability in harsh environments.

<B>Turck Proximity Sensor, PBT Housing Material, ≤10m/s Pass Speed - BIM Series - BIM-PST-AP6X-V1131 W/KLP-80</B> Stay tuned in to the position of objects in your industrial environment with this proximity sensor from Turck. Its magnetic-inductive technology means it emits an electromagnetic field that responds to metals like aluminium, copper and iron for versatile detection. As it's made from tough PBT that withstands heat and chemicals, this unit can stand up to the rigours of harsh environments. It's protected against overload, short circuits and reverse polarity, so it's safe and sound in the event of a fault. <B>Features & Benefits</B> • Shielded to prevent signal disruption from EMI<BR/>• Performs reliably in extreme conditions, thanks to a wide operating temperature range between -25°C and +70°C<BR/>• Pass speed of ≤10m/s for rapid object detection<BR/>• Repeatability rating of ≤± 0.1mm for reduced risk of errors <B>Applications</B> • Food and beverage production<BR/>• Process control systems<BR/>• Industrial tanks <B>How durable is this sensor?</B> As it has an MTTF of 2,283 years, you can use this sensor for a long time without it breaking down. <B>How do I monitor the status of this sensor?</B> Thanks to the built-in LED indicators that show its operating status, it's a breeze to monitor this sensor.

<B>Turck Proximity Sensor, 1kHz Switching Frequency, Metal Housing Material - BIM-IKT Series - BIM-IKT-AP6X-H1141 W/KLI3</B> Need a trusty guide to make sure your pneumatic cylinders are moving with pinpoint accuracy? This proximity sensor from Turck is the tool for the job. It uses magnetic-inductive technology to detect the piston's precise position, ensuring consistent operation in automation processes. The device's die-cast zinc housing stands up to corrosion and impact, so you can rest assured of reliable performance in harsh environments. Thanks to integrated protection against wire breakage and reverse polarity, the unit keeps electrical hazards at bay for safe operation. <B>Features & Benefits</B> • Performs reliably in challenging settings, thanks to a wide operating temperature range between -25°C and +70°C<BR/>• Compact dimensions of 30 (L) x 14.6 (W) x 28mm (H) make it a space-efficient choice for most setups<BR/>• MTTF of 2,883 years at +40°C assures you of long-term service <B>Applications </B> • Food manufacturing industry<BR/>• Wind turbines<BR/>• Material handling equipment <B>Is this sensor waterproof?</B> Yes, its IP67 rating tells you that it's fully protected against dust and immersion in up to 1m of water for 30 minutes.

Turck BIM-AKT Series Magnetic Field Sensors The BIM-AKT series are activated by magnetic fields making them ideally suited for detecting piston positions in pneumatic cylinders. As magnetic fields can permeate non-magnetized metals, these units can detect the position of a piston with a permanently mounted magnet through the aluminium wall of the cylinder. They are made even more versatile thanks to having a wide voltage range of 10 to 65 Vdc. A yellow LED indicates the switching state making it easier to monitor. Rectangular, height 15mm <BR/>Concentric active face <BR/>Increased sensitivity <BR/>DC 2-wire, 10 to 65 Vdc<BR/>Non-contact<BR/>Cable connection<BR/>IP67

Turck Extruded Tie Rod and Profile Cylinder Sensors Features and benefits Zinc die-cast housing protected to IP67 Designed for use with double rail, tie rod, profile and extruded with external dovetail guide cylinders using Turck Mounting Brackets Isolation barriers are available separately Overload, short circuit and reverse polarity protection LED Status Display

Turck BIM-IKM Series Magnetic Field Sensors (AC Magnetic-field Immune) The BIM-IKM series are activated by magnetic fields making them ideally suited for detecting piston positions in pneumatic cylinders. As magnetic fields can permeate non-magnetized metals, these units can detect the position of a piston with a permanently mounted magnet through the aluminium wall of the cylinder. They are made even more versatile thanks to having a wide voltage range of 10 to 65 Vdc. A yellow LED indicates the switching state making it easier to monitor.<BR/><BR/>Weld-field immune permaprox sensors "freeze" the switching status when detecting a magnetic AC field (50 to 60 Hz). This prevents false switching operations during the welding process. The sensor will resume normal operation when the AC field disappears. Rectangular, height 34 mm<BR/>Front active face<BR/>Magnetic-inductive sensor<BR/>Weld resistant to AC fields of 50 to 60 Hz<BR/>DC 3-wire, 10 to 30 Vdc<BR/>NO contact, PNP output Male connector, M12 x 1

<B>Turck Proximity Sensor, 8.2V DC Nominal Voltage, 90mm Switching Distance - BIM Series - BIM-M12E-Y1X</B> When you need to detect objects in your industrial system, let this Turck proximity sensor keep you in the loop. Its magnetic inductive sensing properties are ideal for detecting cylinder pistons, which helps to keep automated positioning processes moving along with spot-on accuracy. As it doesn't make physical contact with an object, you benefit from less noise and a reduced risk of wear for a longer service life. Its MTTF of 6,198 years at +40°C means you can rely on it for long-term performance. <B>Features & Benefits</B> • Chrome-plated brass housing for resistance to corrosion and wear<BR/>• IP67 rating means it's dust-tight and protected against immersion in 1m of water for up to 30 minutes<BR/>• Broad operating temperature range of -25°C to +70°C for use in demanding environments<BR/>• Repeat accuracy of &lt 0.3% of full scale for reliable results <B>Applications</B> • Automated assembly lines<BR/>• Packaging facilities<BR/>• Airports<BR/>• Breweries <B>How can I check on this proximity sensor's switching state?</B> The unit includes a handy yellow LED that lets you know its switching state in a flash.
