The Wurth Elektronik WR-SMA is a straight oriented, Jack SMA connector having 4-Hole flange round post. RoHS compliantOperating temperature ranges between -65°C up to +165°C500 mating cyclesBrass body material

Wurth Elektronik WR-TBL are available in different connection types and offer large and modular terminal block possibilities in order to fulfil most of the requirements which can be found in the industrial marketplace.

Wurth Elektronik WR-TBL are available in different connection types and offer large and modular terminal block possibilities in order to fulfil most of the requirements which can be found in the industrial marketplace.

Wurth Elektronik WR-TBL are available in different connection types and offer large and modular terminal block possibilities in order to fulfil most of the requirements which can be found in the industrial marketplace.

The Wurth Elektroniks male box header is an electromechanical component used in wire-to-board systems and PCBs with an operating temperature range of -40°C to +105 °C. Also, the box header has gold over nickel contact plating with nylon 9T insulator material of black color. Through hole mountingBrass contact material

Product series with high absorbtion of mechanical stressMounting style: SMT-ChipCapacitance range: 220 pF - 2.2 μFTemperature Coefficient: ± 15 %Voltage range (UR): 16 V(DC) - 2 kV(DC)Operating temperature: -55 °C up to + 125 °CSizes: 0603 / 0805 / 1206 / 1210Termination: Ag-Polymer/Ni/SnRecommended soldering: Reflow solderingWave soldering (only valid for the thickness ≤0.85 mm)ApplicationsApplication with high mechanical stressPower supplyLighting

WP-SMRT REDCUBE SMT ApplicationsHigh current Wire-to-Board & Board-to-Board connectionsMounting of copper bars on PCBAngled assembling of cable of PCBsAngled assembling of PCBs on housings

The Wurth Elektronik Crystal clock oscillator is a standard 7 x 5 mm crystal oscillator in a ceramic package with a seam sealed metal lid. It operates at a frequency of 10.0 MHz. It requires a supply voltage of 3.3 V and draws a current of 7.000 mA. This crystal clock oscillator has a drive capability of 15pF, with a maximum rise and fall time of 10.0 ns. The oscillator meets environmental standards MIL STD 202 for shock and MIL STD 883 vibration respectively. RoHS compliantREACh compliantHermetically sealed metal lidOutput is compatible with HCMOS

Stable leakage inductance for differential mode filteringHigh current capabilitiesLow profileClimatic Category 40/115/21AC/DC converterHigh frequency DC/DC converterMains LED DriversSwitch Mode Power Supply

Wurth Elektronik WCAP-AI3H Series Aluminium Electrolytic Capacitors Wurth Elektronik WCAP- AI3H Series aluminium electrolytic capacitors feature an operating temperature of up to +105°C. This general purpose capacitor family WCAP- AI3H Series offer a capacitance value from 68uF to 150uF.

Wurth Elektronik WCAP-AIL5 Series Aluminium Electrolytic Capacitors Wurth Elektronik WCAP- AIL5 Series aluminium electrolytic capacitors feature an operating temperature of up to +105°C. This general purpose capacitor family WCAP- AIL5 Series offer a capacitance value from 33uF to 330uF.
