XP Power Isolated DC to High Voltage DC Converters FS Series FS Series converters provide a rigid design with enhanced features for long term reliability. Features and Benefits Output proportional and linear to output <0.7V turn on voltage<BR/>Smart features for enhanced reliability<BR/>Over temperature protection with automatic shutdown and error code<BR/>Over voltage protection with automatic shutdown error code output<BR/>Disable pin<BR/>No minimum load current needed<BR/>Quasi-Sinewave Oscillator<BR/>Low conducted emissions<BR/>Low input ripple current<BR/>Operating range with stable operating frequency<BR/>High input to output galvanic isolation<BR/>Leakage current and coupling capacitance low input/output<BR/>Reversible output polarity<BR/>High efficiency<BR/>Robust<BR/>Arc protection<BR/>Short circuit protection<BR/>Internal thermal management<BR/>Anodized aluminium heatsink surface<BR/>Two threaded blind inserts allowing easy heatsinking and/ or chassis mounting options Applications Electrophoresis<BR/>Piezo devices<BR/>Capacitor charging<BR/>Mass spectrometry<BR/>Electrostatic chucks

XP Power - JTE06 Series of Isolated DC-DC Converters The JTE06 series from XP Power offers a highly reliable range of single and dual output, 6 W, isolated DC-DC converters. The series has been designed in an industry standard DIP-24 package, features 1500 VDC in isolation and a high efficiency of up to 84%. These compact DC-DC converters have a 4:1 input range and a wide operating temperature of -40 °C to +100 °C. 6 W, isolated DC-DC converters<BR/>1500 VDC isolation, 3000 VDC option available<BR/>Single and dual outputs<BR/>Wide 4:1 input range<BR/>-40 °C to +100 °C Operating temperature<BR/>High efficiency up to 84%<BR/>Industry standard DIP-24 package<BR/>Board mount<BR/>Optional metal case

XP Power – JCJ08 Series of Isolated DC-DC Converters The JCJ08 series from XP Power offers a highly reliable range of 8 W, isolated DC-DC converters. The series has been designed in a DIP-24 package with an industry standard footprint and features a 2:1 input voltage range. No minimum load is required for any of the DC-DC converters in the range and single and dual output options are available. 8 W, isolated DC-DC converters<BR/>1500 VDC isolation<BR/>2:1 input range<BR/>DIP-24 package<BR/>Single and dual outputs<BR/>-40 °C to +70 °C Operating temperature<BR/>Continuous short circuit protection<BR/>Board mount

XP Power - IM Series of Isolated DC-DC Converters The IM series from XP Power offers a highly reliable range of regulated single and dual output, 2 W, isolated DC-DC converters. The series attributes a wide 4:1 input range, 1500 VDC in isolation and is available in an industry standard SIP package. These compact DC-DC converters also feature a high efficiency of up to 85%, remote on/off settings and continuous short circuit protection. 2 W, isolated DC-DC converters<BR/>1500 VDC in isolation<BR/>Regulated single and dual output<BR/>-40 °C to +85 °C Operating temperature<BR/>Industry standard SIP packaging<BR/>Up to 85% efficiency<BR/>Remote on/off settings<BR/>Continuous short circuit protection

XP Power - IM Series of Isolated DC-DC Converters The IM series from XP Power offers a highly reliable range of regulated single and dual output, 2 W, isolated DC-DC converters. The series attributes a wide 4:1 input range, 1500 VDC in isolation and is available in an industry standard SIP package. These compact DC-DC converters also feature a high efficiency of up to 85%, remote on/off settings and continuous short circuit protection. 2 W, isolated DC-DC converters<BR/>1500 VDC in isolation<BR/>Regulated single and dual output<BR/>-40 °C to +85 °C Operating temperature<BR/>Industry standard SIP packaging<BR/>Up to 85% efficiency<BR/>Remote on/off settings<BR/>Continuous short circuit protection

XP Power - IM Series of Isolated DC-DC Converters The IM series from XP Power offers a highly reliable range of regulated single and dual output, 2 W, isolated DC-DC converters. The series attributes a wide 4:1 input range, 1500 VDC in isolation and is available in an industry standard SIP package. These compact DC-DC converters also feature a high efficiency of up to 85%, remote on/off settings and continuous short circuit protection. 2 W, isolated DC-DC converters<BR/>1500 VDC in isolation<BR/>Regulated single and dual output<BR/>-40 °C to +85 °C Operating temperature<BR/>Industry standard SIP packaging<BR/>Up to 85% efficiency<BR/>Remote on/off settings<BR/>Continuous short circuit protection

XP Power - JHL03 Series of Isolated DC-DC Converters The JHL03 series offers a highly reliable range of single and dual output, 3 W, isolated DC-DC converters. The series features 4000 V ac reinforced insulation, 2 μA patient leakage current and is available in an industry standard DIP24 package. These compact DC-DC converters are internationally medical approved, meet IEC60601-1, 3rd Edition and EN55011 level A with no external components. The range has an efficiency of up to 87% and a wide -40 °C to +80 °C operating temperature range, making them the perfect choice for a host of commercial and industrial applications. 3 W, isolated DC-DC converters<BR/>Wide -40 °C to +80 °C operating temperature range<BR/>Internationally medical approved<BR/>Industry standard DIP24 package<BR/>4000 V ac reinforced insulation<BR/>2 μA patient leakage current<BR/>Meets IEC60601-1, 3rd Edition

XP Power JCM30 Series of Isolated DC-DC Converters <B>Features and Benefits</B><BR/>1600 V dc in isolation.<BR/>2:1 Input range.<BR/>Single and dual outputs.<BR/>Wide -40 °C to +105°C operating range.<BR/>MTBF of 370 kHrs.<BR/>Full load of 55°C ambient.<BR/>Compact 1&#148; x 1&#148; footprint.

XP Power - JCE03 Series of Isolated DC-DC Converters The JCE03 series from XP Power offers a highly reliable range of fully regulated single and dual output, 3 W, isolated DC-DC converters. The series features 1500 VDC in isolation (3000 VDC option available) and is available in an industry standard DIP24 package. These compact DC-DC converters feature a 2:1 input range, no minimum load requirements and a wide -40 °C to +90 °C operating temperature range, making them the perfect choice for a host of commercial and industrial applications. 3 W, Isolated DC-DC converters<BR/>1500 VDC in isolation, 3000 VDC option available<BR/>Regulated single and dual output<BR/>Industry standard DIP24 package<BR/>No minimum load requirement<BR/>Wide -40 °C to +90 °C operating temperature range

XP Power - JCD Series of 4 W to 6 W Isolated DC-DC Converters The JCD series from XP Power offers a highly reliable range of single and dual output, 4 W to 6 W, isolated DC-DC converters. The range attributes 1600 VDC in isolation, continuous short circuit protection and a high efficiency of up to 85%. The series also has a 2:1 input range and is available in a compact, industry standard package. 4 W to 6 W, isolated DC-DC converters<BR/>Compact, industry standard package<BR/>2:1 input range<BR/>1600 VDC in isolation<BR/>Single and dual output<BR/>High efficiency up to 85%<BR/>Continuous short circuit protection<BR/>Board mount<BR/>-40 °C to +100 °C Operating temperature

XP Power - JTK30 Series of Isolated DC-DC Converters The JTK30 series from XP Power offers a highly reliable range of single and dual output, 30 W, isolated DC-DC converters. The series has been designed in a small 1&#148; x 1&#148; package, features 1600 VDC in isolation and has a high efficiency of up to 91%. These compact DC-DC converters also attribute remote on/off settings and a wide -40 °C to +100 °C operating temperature range. 30 W, isolated DC-DC converters<BR/>Up to 91% high efficiency<BR/>Single and dual outputs<BR/>1600 VDC in isolation<BR/>Remote on/off settings<BR/>Wide -40 °C to +100 °C operating temperature range

XP Power - ISC03 Series of Isolated DC-DC Converters The ISC03 series from XP Power offers a highly reliable range of regulated single and dual output, 3 W, isolated DC-DC converters. The series features 1500 VDC in isolation and has been designed in a compact SMD package, with a tape and reel option also available. These compact DC-DC converters have a wide 4:1 input range, feature remote on/off settings and have an operating temperature from -40 °C to +100 °C. 1 W, isolated DC-DC converters<BR/>1500 VDC in isolation<BR/>Wide 4:1 input range<BR/>Regulated single and dual output<BR/>-40 °C to +95 °C Operating temperature<BR/>Remote on/off<BR/>Compact SMD package<BR/>Tape and reel package also available<BR/>Up to 80% efficiency<BR/>Board mount
