Depth:
45.7mm
Current Type:
DC
Cutout Width:
74mm
Product Type:
Analogue Panel Ammeter
Cutout Height:
76mm
Meter Accuracy:
±1.5 %
Moving Element:
High Torque Pivot and Jewel Moving Coil and Moving Iron
Maximum Measurement:
600 V
Standards/Approvals:
VDE 0110-1:2008-01, EN 61010-1, VDE/VDI 3540, DIN 46200/46282, 2014/30/EC, ANSI C39.1, IEC 529, IS: 9000, BS EN 61326, IEC 1010, DIN 43701, DIN 43807, UL3111-1, 93/68/EEC, EN 60664-1, 2014/35/EC, IS 1248/IEC 51 IS 9000, IS 2419, ISO 20653:2006-08, IS 1248, IS9249, UL 94 V-O, part 5, DIN 43802, IEC61010-1
Maximum Ampere Value:
50 A
Maximum Operating Temperature:
60°C
Minimum Operating Temperature:
0°C
