Sanyo Denki Axial Fan, 63.6m³/h Air Flow, 44dB Noise Level - San Ace 109R Series - 109R0624J402
Prevent your machines from overheating during operation with this axial fan from Sanyo Denki. This device has a low sound output of 44dB, so it will generate minimal noise in your workplace. The fan rotates at a high speed of 7600rpm and has an airflow rate of 63.6m³/h to ensure efficient cooling. A voltage rating of 24V DC makes this fan suitable for use in low-voltage applications.
Features & Benefits
• Flame-retardant frame and impeller for safety in the event of a fire
• Compact dimensions of 60 (H) x 60 (W) x 25mm (D) for installation in areas with limited space
• Ball bearing design for minimal friction and smooth operation
• Plastic body is resistant to corrosion and impact for durability in harsh environments
• Wide operating temperature range of -20°C to +60°C for use in demanding conditions Applications • Medical equipment
• Server rooms Does this fan consume a lot of power? No, this fan has a low power consumption of just 5.76W and a current rating of 240mA, making it an energy-efficient choice.
• Compact dimensions of 60 (H) x 60 (W) x 25mm (D) for installation in areas with limited space
• Ball bearing design for minimal friction and smooth operation
• Plastic body is resistant to corrosion and impact for durability in harsh environments
• Wide operating temperature range of -20°C to +60°C for use in demanding conditions Applications • Medical equipment
• Server rooms Does this fan consume a lot of power? No, this fan has a low power consumption of just 5.76W and a current rating of 240mA, making it an energy-efficient choice.

San Ace 109R Series Axial Fan, 24 V dc, DC Operation, 63m³/h, 5.76W, 240mA Max, 60 x 60 x 25mm
Manufacturer:
Sanyo Denki
Manufacturer Part No:
109R0624J402
Enrgtech Part No:
ET16961098
Warranty:
Manufacturer
£ 15.21
Checking for live stock
Supply Voltage:
24 V dc
AC or DC Operation:
DC
Height:
25mm
Width:
60mm
Power Consumption:
5.76W
Maximum Current:
240mA
Depth:
60mm
Dimensions:
60 x 60 x 25mm
Termination Type:
Lead Wire
Air Flow:
63m³/h
Noise Level:
44dB(A)
Bearing Type:
Ball
