The Rohde & Schwarz NGU-K106 option allows users to simulate the behaviour of batteries under different charging conditions, e.g. when powering a DUT. To define a battery model, the data of the battery can be entered easily using the integrated battery model editor. Data sets for the common battery types (Pb, lithium-ion, NiCd and NiMH) are available as preconfigured files. These can be easily modified according to the needs of a specific application. Additional battery model data sets can be loaded from a USB device and stored on the R&S®NGU201 source measure unit. Easy operation
Minimum residual ripple an low noise
Readings with up to 6 digit resolution
High speed data acquisition (FastLog function)
