Width:
35mm
Height:
53mm
Length:
210mm
Weight:
163.7g
True RMS:
Yes
Battery Type:
AA
Display Type:
LCD
Model Number:
VT8
Power Source:
Battery
Product Type:
Clamp Meter
Clamp Meter Type:
AC, DC
Functions Measured:
DC Current, Capacitance, Data Hold, DC Voltage, NCV (Non-contact Voltage), Resistance, Relative Mode, AC Current, True RMS, AC Voltage, Continuity, Auto Ranging
AC Current Accuracy:
±2.5 %
AC Voltage Accuracy:
±1 %
DC Current Accuracy:
±2.5 %
DC Voltage Accuracy:
±1 %
Maximum Jaw Opening:
15.5mm
Standards/Approvals:
No
AC Current Resolution:
100mA
AC Voltage Resolution:
100mV ac
DC Current Resolution:
100mA
DC Voltage Resolution:
100 mV dc
Safety Category Level:
CAT III, CAT IV
Safety Category Voltage:
1000V
Non-Contact Voltage Detector:
Yes
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
-10°C
Maximum AC Current Measurement:
200A
Maximum AC Voltage Measurement:
1000V ac
Maximum DC Current Measurement:
200A
Maximum DC Voltage Measurement:
1000V dc
Maximum Resistance Measurement:
60MΩ
Maximum Temperature Measurement:
50°C
Resistance Measurement Accuracy:
±1.5 %
