Coaxial Type:
RG316/D
Core Strands:
7
Product Type:
Coaxial Cable
Fire Behaviour:
Low Smoke Zero Halogen, LSZH, Flame Retardant to IEC 60332-1-2, Flame resistance to UL1581 VW-1 and IEC60332-1
Outside Diameter:
2.9mm
Conductor Material:
Silver Plated Steel
Standards/Approvals:
HD 361, HAR, IEC 60228 Css 5, BS4109, VD0281-5, BS4808, UL1581 VW-1, VD0295, TS 9760 HD 21.5.S3, IEC 60227-5, VD2050, BASEC, REACH, CENELEC HD21.5, BS EN13062, DIN VD0292, RoHS, DEF STAN 61-12 Part 6, IEC60332-1
Terminated/Unterminated:
Unterminated
Characteristic Impedance:
50Ω
Maximum Operating Temperature:
200°C
Minimum Operating Temperature:
-55°C
