FME Male to FME Female LLC200A Coaxial Cables, Siretta
Available in two cable lengths with an FME Male connector and an FME Female connector:
ASME300F058L13 - 3 m cable (140-8010)
ASME500F058L13 - 5 m cable (124-8848)
ASME1000F058L13 - 10 m cable (124-8849)
ASME1500F058L13 - 15 m cable (140-8008)
ASME2000F058L13 - 20 m cable (140-8009)
Cable Specifications
Impedance: 50 Ω
Loss dB/M @ 1.8 GHz: 0.52, @ 2.1 GHz: 0.64
Cable: LLC200A
Operating Frequencies: Up to 6 GHz
Dimensions
Core: 0.94 mm copper wire
Insulator: 2.79 mm GAS-FPE
Shield: tinned copper braid
Jacket: 4.95 mm PVC
ASME300F058L13 - 3 m cable (140-8010)
ASME500F058L13 - 5 m cable (124-8848)
ASME1000F058L13 - 10 m cable (124-8849)
ASME1500F058L13 - 15 m cable (140-8008)
ASME2000F058L13 - 20 m cable (140-8009)
Cable Specifications
Impedance: 50 Ω
Loss dB/M @ 1.8 GHz: 0.52, @ 2.1 GHz: 0.64
Cable: LLC200A
Operating Frequencies: Up to 6 GHz
Dimensions
Core: 0.94 mm copper wire
Insulator: 2.79 mm GAS-FPE
Shield: tinned copper braid
Jacket: 4.95 mm PVC
ASM Series Male FME to Female FME, 3m, LLC200A Coaxial, Terminated50 Ω
Manufacturer:
Siretta
Manufacturer Part No:
ASME300F058L13
Enrgtech Part No:
ET16798590
Warranty:
Manufacturer
£ 30.10
Checking for live stock
Connector 1:
FME
Terminated/Unterminated:
Terminated
Connector 2:
FME
Coaxial Type:
LLC200A
Connector 1 Gender:
Male
Connector 2 Gender:
Female
Outer Diameter:
5mm
Characteristic Impedance:
50 Ω
Attenuation:
0.15 dB
Length:
3m
Sheath Colour:
Black
Conductor Strand Type:
Solid
