3RT2 Overload Relay 1NO + 1NC, 14 A @ 480 V, 17 A @ 600 V F.L.C, 10 A @ 230 V (Auxiliary AC-15), 10 A @ 24 V

FLC Motor Rating:

14 A @ 480 V, 17 A @ 600 V

Contact Current Rating:

10 A @ 230 V (Auxiliary AC-15), 10 A @ 24 V (Auxiliary DC-12), 10 A @ 24 V (Auxillary DC-13), 10 A @ Maximum (Auxiliary AC-12), 17 A @ 400 V (Main AC-2), 17 A @ 400 V (Main AC-3), 35 A @ 24 V (Main DC-1), 40 A @ 690 V (Main AC-1)

Range:

SIRIUS

Pole Configuration:

3P

Series:

3RT2

Mounting Style:

DIN Rail Mount

Power Rating:

7.5 kW

Normal State Configuration:

1NO + 1NC

Terminal Type:

Screw

Width:

85mm

Number Of Auxiliary Contacts:

5

Depth:

107mm

Length:

45mm

Minimum Operating Temperature:

-25°C

Maximum Operating Temperature:

+60°C

Better World Claim:

Low carbon manufacture

Better World Product:

Yes

Operating Temperature Range:

-25 → +60 °C

Contact Voltage Rating:

400 (Main AC-2) V, 600 (Auxiliary DC-12) V dc, 600 (Auxillary DC-13) V dc, 600 (DC-3 at DC-5) V, 600 (Main DC-1) V, 690 (Auxiliary AC-15) V ac, 690 (Main AC-3) V

Control Voltage:

24 Vdc

Supply Voltage:

24 V dc

3D Model:

https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=1369685&DisplayLogo=False
