3 Pole Contactors with Screw Clamp or Solder Termination Contactors have a switching voltage of 440Vac and a coil consumption (ac coils 50 / 60Hz rated) of 4.5VA (Hold in) and 30VA (inrush). Utilisation category AC3 DIN rail or screw mounting Ambient air temperature range -25 to +50°C Approvals CSA, UL, NEMKO, DEMKO, SEMKO, FIMKO Standards BS5424 Part 1/IEC 947, VDE 0660, NFC63 110

Schneider Electric TeSys K LC1K 3 Pole Contactor, 3NO (Main), NO (Auxiliary), 9 A, 400 V ac, 415 V ac Coil

Manufacturer:
Manufacturer Part No:
LC1K0910N7
Enrgtech Part No:
ET13863959
Warranty:
Manufacturer
£ 49.67
Checking for live stock
Better World Verification:
Green Premium
Better World Product:
Yes
Normal State Configuration:
3NO
Contact Current Rating:
9 A
Series:
LC1K
Coil Voltage:
400 V ac
Length:
58mm
Width:
45mm
Depth:
57mm
Number Of Auxiliary Contacts:
1
Range:
TeSys K
Auxiliary Contact Configuration:
1NO
Contact Voltage Rating:
690 V ac
Number of Poles:
3
Terminal Type:
Screw
pdf icon
Datasheet - LC1K0910N7(Technical Reference)
pdf icon
Product Environmental Profile(Technical Reference)
