Depth:
143mm
Width:
45mm
Length:
81mm
Series:
100S-C
Function:
Motor Control, Reversing
Mount Type:
Panel
Coil Voltage:
24V dc
Power Rating:
7.5kW
Product Type:
Contactor
Terminal Type:
Screw
Contact Current:
30A
Contact Voltage:
690V ac
Number of Poles:
3
Standards/Approvals:
EAC, IEC, RoHS, UL, CCC, CE, CSA, cULus
Contactor Application:
Direct-on-Line (DoL)
Operational Current Ie:
30A
Control Circuit Voltage Uc:
24V dc
Normal State Configuration:
2 NO/2 NC
Number of Auxiliary Contacts:
4
Pole and Throw Configuration:
3P
Maximum Operating Temperature:
60°C
Minimum Operating Temperature:
-25°C
Auxiliary Contact Configuration:
2 NO/2 NC
Depth:
143mm
Width:
45mm
Length:
81mm
Series:
100S-C
Function:
Safety
Coil Voltage:
24 V dc
Number of Poles:
3
Contact Current Rating:
30 A
Contact Voltage Rating:
690 V ac
Normal State Configuration:
2NO + 2NC
Number Of Auxiliary Contacts:
4
Pole and Throw Configuration:
3P
Maximum Operating Temperature:
+60°C
Minimum Operating Temperature:
-25°C
Auxiliary Contact Configuration:
2NO + 2NC
