Phoenix Contact Earth Terminal Block, 1.02W Maximum Power Dissipation, Open Side Panel - PT 4-TWIN-PE - 3211780
Get ground cables and your DIN rail quickly linked up with this earth terminal block from Phoenix Contact. Thanks to its three-way design, you can connect multiple wires simultaneously, making it your versatile workmate for multi-circuit protection. The terminal block has a clamping foot that transforms the rail into a busbar, preventing damage from excess feedback current. Thanks to this, you don't have to worry about electric shocks or the risk of fire outbreaks.
The block's durable PA housing provides reliable impact protection, so it shrugs off bumps and scrapes in harsh environments. As it's DIN rail mounted, you don't need any installation tools, so that's one less thing to worry about. What's more, with its open side panel, you can easily integrate the unit with other terminal blocks on your circuit. You'll find it used in the process and packaging industry. Features & Benefits • Low power loss of 1.2W makes it an energy-efficient solution
• Can accommodate wire sizes between 24 and 10AWG for versatility
• ATEX certified for use in potentially explosive settings
• UL 94-V0 flammability rating indicates that it stops burning in 10 seconds or less in the event of a fire
The block's durable PA housing provides reliable impact protection, so it shrugs off bumps and scrapes in harsh environments. As it's DIN rail mounted, you don't need any installation tools, so that's one less thing to worry about. What's more, with its open side panel, you can easily integrate the unit with other terminal blocks on your circuit. You'll find it used in the process and packaging industry. Features & Benefits • Low power loss of 1.2W makes it an energy-efficient solution
• Can accommodate wire sizes between 24 and 10AWG for versatility
• ATEX certified for use in potentially explosive settings
• UL 94-V0 flammability rating indicates that it stops burning in 10 seconds or less in the event of a fire
3-Way PT 4-TWIN-PE Earth Terminal Block, 0.2 → 6mm², 24 → 10 AWG Wire, Push In, Polyamide
Manufacturer:
Phoenix Contact
Manufacturer Part No:
3211780
Enrgtech Part No:
ET11956514
Warranty:
Manufacturer
£ 4.15
Checking for live stock
Earth Block Type:
PT 4-TWIN-PE
Wire Size:
24 → 10 AWG
Cable CSA:
0.2 → 6mm²
Colour:
Green/Yellow
Number of Ways:
3
Termination Method:
Push In
Housing Material:
Polyamide
Length:
66.5mm
Width:
6.2mm
Height:
44mm
Maximum Operating Temperature:
+130°C
Minimum Operating Temperature:
-60°C
