Series:
PM5000
Display Type:
LCD
Number of Phases:
3
Depth:
72mm
Meter Accuracy:
±0.005 (Power Factor) %, ±0.05 (Frequency) %, ±0.5 (Active Energy) %, ±0.5 (Active Power) %, ±0.5 (Apparent Power) %, ±0.5 (Current) %, ±0.5 (Voltage) %, ±2 (Reactive Energy) %
Minimum Temperature:
-25°C
Maximum Temperature:
+70°C
Better World Verification:
Green Premium
Meter Type:
Electromechanical
Better World Product:
Yes
Measurement Range:
10 mA → 9 A, 20 → 400 (Phase and Neutral) V ac, 35 → 690 (Phase) V ac, 45 → 65Hz
Maximum Measurement:
400 (Phase and Neutral) V ac, 690 (Phase) V ac, 9 A, 65 Hz
Approvals:
CE Conforming to IEC 61010-1c, CULus Conforming to UL 61010-1, EN 50470-1, EN 50470-3, EN 55022, IEC 60529, IEC 61000-4-2, IEC 61000-4-8, IEC 61557-12, IEC 62053-22, IEC 62053-24
Minimum Measurement:
20 (Phase and Neutral) V ac, 35 (Phase) V ac, 10 mA, 45 Hz
