Series:
PM8000
Display Type:
LCD
Number of Phases:
3
Pulse Output:
Yes
Depth:
90.8mm
Meter Accuracy:
±0.1 (Current, Voltage) %, ±0.2 (Active Energy) %
Minimum Temperature:
-25°C
Maximum Temperature:
+70°C
Meter Type:
Electromechanical
Better World Verification:
Green Premium
Better World Product:
Yes
Measurement Range:
100 → 690 (Phase) V ac, 42 → 69 Hz, 50 mA → 10 A, 57 → 400 (Phase and Neutral) V ac
Maximum Measurement:
400 (Phase and Neutral) V ac, 690 (Phase) V ac, 10 A, 69 Hz
Approvals:
CE, CSA C22.2 No 61010-1, CULus, EN 61010-1, IEC 60529, IEC 61010-1, IEC 61557-12, IEC 62052-11, IEC 62053-22, IEC 62053-24, N998, UL 61010-1
Minimum Measurement:
100 (Phase) V ac, 57 (Phase and Neutral) V ac, 42 Hz, 50 mA
